Step 3
Attach the VESA Plate to the Monitor
q
For Monitor with Flat Back
Step 4
Slide the Monitor to the Head of Swivel Arm
d
Install the security Nut(h). Make
Slide the monitor onto the head of
Swivel Arm(d) as the above diagram.
sure the security nut is installed
before you rotate the monitor.
Step 5
s
r
Adjust and tighten the bolt with the
For Monitor with Curved or
supplied Allen Key(o)to fix the tilt
angle
Recessed Back
Step 6
Adjust the four monitors to horizontal by moving the head
sleeve up and down & adjusting the level of the faceplate
by screws.
h
Use the provided Allen Key(o)to make the necessary adjustment
Make the Necessary Adjustments
o
By adjusting the tightness of the screws,
the height of the monitor can be adjusted.
Manage the Wires and Store the Allen Keys on Wire Clip
o
n1
The wire is held in place with a cable clip (n1)
Thank you for choosing our products!
o
UNPACKING INSTRUCTIONS
Carefully open the carton, remove contents and lay out on cardboard or other protective
surface to avoid damage.
Check package contents against the Supplied Parts List in the next page to assure that
all components wete received undamaged. Do not use damaged or defective parts.
Carefully read all instructions before attempting installation.
IMPORTANT SAFETY INFORMATION
Install and operate this device with care. Please read this instruction before installation,
and carefully follow all instructions contained herein. Use proper safety equipment during
installation.
Please call a qualified installation contractor for help if you don't understand these
directions or have any doubts about the safety of the installation.
Do not use this product for any purpose or in any configuration not explicitly specified in
this instruction. We hereby disclaims any and all liability for injury or damage arising from
incorrect assembly, incorrect mounting, or incorrect use of this product.
MD6864
INSTALLATION MANUAL
