Replacement - Icom IC-V82 Service Manual

Jul. 2009
SECTION 1
GENERAL
• Frequency range
• Operating temperature range
• Operating mode
• Frequency stability
• Antenna impedance
• Power supply requirement
• Number of memory channels
• Scan types
• Tuning steps
• Current drain (At 7.2 V DC; approx.) : TX
• Dimensions (Projections not included) : 54.0 (W) × 139.0 (H) × 36.7 (D) mm; 2
• Weight (Except antenna, battery pack) : Approx. 200 g (7
• Data connector
TRANSMITTER
• Output power (At 7.2 V DC)
• Modulation system
• Maximum deviation
• Spurious emissions
• Ext. microphone connector
RECEIVER
• Receiving system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity (At threshold)
• Selectivity
• Intermodulation
• Spurious image rejection
• Audio output
• Ext. speaker connector
All stated specifications are subject to change without notice or obligation.
(Replacement page)
SPECIFICATIONS
: TX 144.000–148.000 MHz
144.000–146.000 MHz
136.000–174.000 MHz*
:
RX 136.000–174.000 MHz*
144.000–146.000 MHz
*Specifi cations are guaranteed within 144.000 to 148.000 MHz range only.
: –10°C to 60°C; +14°F to +140°F
: F2D, F3E, F7W* (*With optional digital unit UT-118)
: ±2.5 ppm (–10°C to +60°C; +14°F to +140°F)
: 50 Ω (BNC type)
: Specified Icom's battery pack only (Operating voltage range; 6.0–10.3 V)
: 207 channels (Including 6 scan edges and 1 call channel)
: Program/Memory/Skip/Priority/Tone scans
: 5, 10, 12.5, 15, 20, 25, 30 and 50 kHz
High
Middle
Low
RX Max. audio
Stand-by
Power save
: 3-conductor 2.5 (d) mm (
: 7.0 W (High), 4.0 W (Middle), 0.5 W (Low) Other than [IC-V82-T]
5.5 W (High), 4.0 W (Middle), 0.5 W (Low) [IC-V82-T]
: Variable reactance frequency modulation
: ±2.5 kHz (Narrow), ±5.0 kHz (Wide)
: Less than –60 dBc
: 3-conductor 2.5 (d) mm (
: Double conversion superheterodyne system
: 1st; 46.35 MHz, 2nd; 450 kHz
: Less than –14 dBμ at 12 dB SINAD (0.16 μV typ.)
: Less than –16 dBμ (0.11 μV typ.)
: More than 55 dB (Wide; 65 dB typ.)
More than 50 dB (Narrow)
: More than 55 dB (65 dB typ.)
: More than 60 dB (80 dB typ.)
: More than 300 mW at 10% distortion with an 8 Ω load
: 3-conductor 3.5 (d) mm (
1 - 1
[USA], [USA-1], [USA-2], [USA-3]
[EUR], [EUR-1], [EUR-2], [EUR-3], [KOR], [THA]
[EXP], [EXP-1], [EXP-2], [EXP-3], [EXP-4],
[CHN], [CHN-01], [CHN-02],
[CSA], [CSA-1], [CSA-2], [CSA-3]
[USA], [USA-1], [USA-2], [USA-3],
[EXP], [EXP-1], [EXP-2], [EXP-3], [EXP-4],
[CHN], [CHN-01], [CHN-02],
[CSA], [CSA-1], [CSA-2], [CSA-3]
[EUR], [EUR-1], [EUR-2], [EUR-3], [KOR], [THA]
2.6 A
2.0 A
1.0 A
Less than 250 mA
Less than 80 mA
Less than 30 mA
1
/ (W) × 5
8
5
/ oz)
32
1
/ ")
10
1
/ ")/2.2 kΩ
10
")/8 Ω
1
/
8
9
15
/ (H) × 1 / (D) in.
32 32
