Icom IC-V82 Service Manual page 9

Oct. 2010
[MAIN UNIT]
REF PARTS
NO. NO.
J6 6510021901 S.CON BM02B-ASRS-TF(LF)(SN)
J7 6510024580 S.CON HSJ1621-019011
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
DS4 5030002801 LCD A01B001A 2826 LCD
MC1 7700002700 MIC EM9445P-45-LF <HOR>
S3 2260002840 SWI SKHLLFA010
S801 7600000210 ENC TP70N00E20-15F-1903
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP6 6910012350 S.BEA MMZ1608Y 102BT
EP7 6910012350 S.BEA MMZ1608Y 102BT
EP9 6910012350 S.BEA MMZ1608Y 102BT
EP10 6910012350 S.BEA MMZ1608Y 102BT
EP11 6910012350 S.BEA MMZ1608Y 102BT
EP12 8930064900 LCD SRCN-2826-SP-N-W (SHJ)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T
B
T
T
T
B
B
B
B
B
S.=Surface mount
H/V
71.5/4.0
12.6/1.9
64.1/38.9
64.1/7.1
101.2/9.4
20.8/42.4
22.1/42.4
5.2/9.1
7.2/12.0
5.2/6.4
6
