Icom IC-V82 Service Manual page 12

Jul. 2009
SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGES . . . . . . . . . . . . . . . . . . . . . . 1-1, 5-2
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 8
[VERSION LIST]
Model Version
[EUR]
IC-V82 [EXP]
[USA]
IC-V82-T [THA]
[CSA]
[EUR-1]
[EXP-1]
[USA-1]
[CHN]
[CSA-1]
[EUR-2]
[EXP-2]
[USA-2]
IC-V82
[KOR]
[CHN-01]
[CSA-2]
[EXP-3]
[CHN-02]
[CSA-3]
[EUR-3]
[EXP-4]
[USA-3]
Battery Pack
-
BP-208
BP-222N
-
BP-209N
