- Page 1 AXI00002T1/T2 INSTRUCTION MANUAL BEDIENUNGSANLEITUNG MANUEL D’UTILISATION MANUALE DI ISTRUZIONI...
- Page 2 This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance.
-
Page 3: Table Of Contents
WATER-RESISTANT VEHICLE WITH WATERPROOF ELECTRONICS Your new Horizon Hobby vehicle has been designed and built with a combination of waterproof and water-resistant components to allow you to operate the product in many “wet conditions,” including puddles, creeks, wet grass, snow and even rain. -
Page 4: Box Contents
WET CONDITIONS MAINTENANCE • Drain any water that has collected in the tires by spinning them at high speed. With the body removed, place the vehicle upside down and pull full throttle for a few short bursts until the water has been removed. CAUTION: Always keep hands, fi... -
Page 5: Usb Charging Warnings
• Always disconnect the battery after charging, and let the charger cool between charges. • Always charge in a well-ventilated area. • Always terminate all processes and contact Horizon Hobby if the product malfunctions. • Charge only rechargeable batteries. Charging non-rechargeable batteries may cause the batteries to burst, resulting in injury to persons and/or damage to property. -
Page 6: Transmitter Layout
TRANSMITTER LAYOUT Use the diagram below to familiarize yourself with the different parts of your transmitter. The transmitter antenna is mounted internally and is located in the front portion of the transmitter. When you are driving your model, hold the transmitter so it is oriented as close to vertical as possible. Do not try to follow your model with the transmitter. -
Page 7: Install The Transmitter Batteries
INSTALL THE TRANSMITTER BATTERIES 1. Press the battery compartment latch and rotate the batter cover to open. 2. Install 4 AA alkaline batteries (or Ni-Cd or Ni-MH), verifying correct polarity. 3. Close the battery cover until it latches. CAUTION: NEVER remove the transmitter batteries while the vehicle is powered ON. -
Page 8: Install The Vehicle Battery
INSTALL THE VEHICLE BATTERY POWER ON THE TRANSMITTER... -
Page 9: Power On The Vehicle
POWER ON THE VEHICLE TEST THE CONTROLS With the vehicle wheels off the ground, test the throttle and steering controls. Ensure the wheels spin in the proper direction and the front wheels turn in the proper direction with steering input. After checking for proper direction of controls, start driving slowly. -
Page 10: After Driving
AFTER DRIVING When you are fi nished driving your vehicle: 1. Power off the vehicle. 2. Power off the transmitter. 3. Remove the vehicle battery and charge if necessary. BINDING THE TRANSMITTER AND RECEIVER Binding is the process of programming the receiver to recognize a specifi c transmitter signal, thus preventing interference from other transmitters. -
Page 11: Troubleshooting
Product, (iv) attempted exclusive remedy shall be that Horizon will, at its option, service by anyone other than a Horizon Hobby authorized either (i) service, or (ii) replace, any Product determined service center, (v) Product not purchased from an authorized by Horizon to be defective. - Page 12 Limitation of Liability is available at http://www.horizonhobby.com/content/ service-center_render-service-center. If you do not have HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, internet access, please contact Horizon Product Support INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF to obtain a RMA number along with instructions for PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN submitting your product for service.
-
Page 13: Warranty And Service Contact Information
Hanskampring 9 Horizon Technischer Service service@horizonhobby.eu European D 22885 Barsbüttel, Union Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 Germany FCC INFORMATION FCC ID: XJ6MT-203 This device complies with part 15 of the FCC rules. NOTE: This equipment has been tested and found... -
Page 14: Compliance Information For The European Union
COMPLIANCE INFORMATION FOR THE EUROPEAN UNION EU Compliance Statement: Axial Jeep Wrangler JL 1/24 Scale Electric 4WD RTR (AXI00002T1/T2) Horizon Hobby, LLC hereby declares that this A copy of the EU Declaration of Conformity is available product is in compliance with the essential requirements online at: http://www.horizonhobby.com/content/support-... -
Page 15: Exploded Views
EXPLODED VIEWS // EXPLOSIONSZEICHNUNGEN // VUES ÉCLATÉES // VISTE ESPLOSE AXI31612 AXI31611 and AXI204000 SCX24 Shock Set (assembled) SCX24 Driveshaft Set (short, medium, long) SCX24 Stoßdämpfersatz (montiert) SCX24 Antriebswellensatz (kurz, mittel, lang) Ensemble d’amortisseurs SCX24 (assemblés) Ensemble d’arbre SCX24 Set ammortizzatori (assemblati) de transmission SCX24 (court, moyen, long) SCX24 Set albero di trasmissione (corto, medio, lungo) - Page 16 AXI31609 SCX24 Front Axle (assembled) SCX24 Vorderachse (montiert) Essieu avant SCX24 (assemblé) SCX24 Assale anteriore (assemblato) AXI31610 SCX24 Rear Axle (assembled) SCX24 Hinterachse (montiert) Essieu arrière SCX24 (assemblé) SCX24 Assale posteriore (assemblato)
- Page 17 AXI204000 SCX24 Suspension Links (short, medium, long) SCX24 Aufhängeglieder (kurz, mittel, lang) Bras de suspension SCX24 (court, moyen, long) SCX24 Bielle sospensioni (corte, medie, lunghe)
- Page 18 AXI31614 SCX24 Chassis Set SCX24 Karosseriesatz Ensemble de carrosserie SCX24 AXI31614 SCX24 Set telaio AXI201001 DYNS1217 AXI31608 AXI201000 AXI31614 AXI201002 AXI31609 AXI204000 AXI31611 AXI31619 DYNB0012 AXI31620 AXI31612...
- Page 19 AXI200000 2019 Jeep JLUCRC Body Set (clear and cut) 2019 Jeep JLUCRC Karosseriesatz (durchsichtig und zugeschnitten) Ensemble carrosserie Jeep 2019 JLUCRC (transparente et coupée) Set carrozzeria Jeep JLUCRC 2019 (trasparente e pretagliato) AXI31615 AXI31567...
- Page 20 OFFICIALLY LICENSED BY: facebook.com/axialinc | instagram.com/axialracing | twitter.com/axialrc youtube.com/axialvideos | fl ickr.com/axialrc ©2019 Horizon Hobby, LLC. Axial, the Axial logo and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. ® ® Nitto and Trail Grappler are registered trademarks of Nitto Tire U.S.A., Inc.
