- Page 1 User Manual 540mm Upright Electric Cooker EFF54W / EFF54SS EEF54W / EFF54SS Upright Cooker User Manual Page i...
-
Page 2: Table Of Contents
Always keep this Manual close to hand since you may need to refer to it in the future. Thank you. Page 1 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 3: Conditions Of Use
Do not remove any labels or use abrasive/ corrosive cleaners on. According to the electrical safety regulations the appliance equipment must be properly earthed. Do not use corrosive cleaners e.g. oven cleaners that contain caustic soda. EEF54W / EFF54SS Upright Cooker User Manual Page 2... -
Page 4: Warnings For Use Of Oven And Appliance Hob
Do not use steam cleaners, as this may cause moisture build up. • Always clean the appliance immediately after any food spillage. • Appliances requiring connection to 220-240V and must be earthed. Page 3 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 5: Product Description
Adjusts temperature of hotplate. Programmable Clock (where fitted) • Sets baking/grilling reminder times. • Sets automatic cooking duration and stop time Note: Clock time must be set before oven can operate EEF54W / EFF54SS Upright Cooker User Manual Page 4... -
Page 6: First Time Use Of The Appliance
Do not use the oven door as a shelf. • Do not push down on the open oven door. • Do not place shelves on top of upper most shelf runner as there are no stops for shelf withdrawal. Page 5 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 7: Using The Oven Of Your Electric Cooker
NOTE: For any time below fifteen minutes turn the knob past the fifteen then turn it back to the required number of minutes. When the timer returns to zero, the timer gives a short ring. EEF54W / EFF54SS Upright Cooker User Manual Page 6... -
Page 8: Oven Shelf Location
180-220 1 (3) 170-200 20-30 (10/25) custard tart Cream puffs 25-30 Yeast bread 25-30 15-25 Pizza Shelf position is counted from the bottom shelf position up. Bottom shelf position is 1. Page 7 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 9: Understanding Baking Problems
Don’t open the oven door until at least during baking half the cooking time has passed Baking temperature too high Lower the temperature Oven tray blocking heat (below Use higher shelf position for oven tray thermostat) EEF54W / EFF54SS Upright Cooker User Manual Page 8... -
Page 10: Using The Hotplates Of Your Cooker
Always put dry pots and pans on the hotplates. • Do not use pots and pans which are too large. Pans which overhang the hotplate more than 50mm can damage the hob Page 9 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 11: Using The Hotplates Of Your Electric Cooker
When the hotplates have cooled apply a thin coating of cooking oil to the hotplate to seal and protect the surface. • After switching off, this light will continue to glow until the temperature of the hotplate drops below 60°C EEF54W / EFF54SS Upright Cooker User Manual Page 10... -
Page 12: Cleaning The Cooker
These may damage, scratch or stain the hot plate. Any pitting, staining or scratching will not be covered by warranty. Cleaning the Oven • Open the door fully. • Remove oven shelves and side racks. • Clean with hot soapy water. Page 11 EEF54W / EFF54SS Upright Cooker User Manual... - Page 13 • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass. EEF54W / EFF54SS Upright Cooker User Manual Page 12...
-
Page 14: Information About The Cooling Fan
Remove the lamp and replace with a lamp resistant to high temperatures (300°) with the following characteristics: » Voltage: 220-240V » Wattage: 25W » Type: E 14 • Replace the glass cover. Reconnect the appliance to the mains power supply. Page 13 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 15: Solving Problems
Household fuse blown or power Clock display off Check fuses, power supply supply is off Note: Only Euromaid Authorised service agents should carry out servicing otherwise warranty may be void. EEF54W / EFF54SS Upright Cooker User Manual Page 14... -
Page 16: Installing Cooker - Power Connections
• The electrical capacity of the system and sockets will support the maximum power of the appliance, as indicated on the data plate • Go to section “Installing your new cooker” Page 15 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 17: Installing Your New Cooker
• Position splash back into tabs at rear of cooker and push downwards gently until properly in position. • Screw in splashback from behind to secure in place. EEF54W / EFF54SS Upright Cooker User Manual Page 16... -
Page 18: Installation Sequence
The power supply to the appliance must be turned off before any adjustments or maintenance work is to be carried out on the cooker. Air vents at the rear of the cooker should not be fully covered otherwise ventilation will be restricted and cause possible damage to the cooker. Page 17 EEF54W / EFF54SS Upright Cooker User Manual... -
Page 19: Technical Specifications
Frequency (Hz) Connected Load (W) 7150W Circuit breaker(A) 32amp Oven power (W) 2150W Cooktop power (W) 5000W Product dimension (mm) 540*630*910 Package size (mm) 636*740*976 Gross /net weight (Kg) 53.8 / 44.3 EEF54W / EFF54SS Upright Cooker User Manual Page 18... - Page 20 Distributed by: Home Appliances Pty. Ltd. 20 Carlotta Street, Artarmon NSW 2064 Tel: 02 9958 3111 Fax: 02 9958 3555 Customer Care: 1800 444 357 Email: info@hapl.com.au Website: www.hapl.com.au...
