- Page 1 Remove bar if no collection name Min. clearance Min. clearance 44/47 type...
-
Page 2: Maintenance
GENERAL BEST PRACTICES FOR ASSEMBLY: MAINTENANCE: Read all instructions before starting. Wipe clean with a dry cloth for the upholstery and Separate all parts before starting. frame. Do not use bleach, acid or other abrasive Clear a flat covered space to assemble. cleaners. -
Page 3: Parts List
PARTS LIST x1 (Right) Castor Base Armrest Gas Lift Seat Plate x1 (Left) Seat Cushion Armrest Back Cushion HARDWARE LIST 5/16x20mm Screw 1/4x25mm Screw Allen Wrench... -
Page 4: Helpful Hints
HELPFUL HINTS NOTE: To avoid damage, ensure screws are hand tightened. DO NOT USE POWER TOOLS TO ASSEMBLE YOUR UNIT. 1person... - Page 5 STEP 1 Insert the five castors (A) into the base (B) as shown in the diagram, make sure all castors are firmly inserted.
- Page 6 STEP 2 Turn the base (B) right side up, insert gas lift (C) into the centre hole of base (B) as shown in the diagram.
- Page 7 STEP 3 x x 4 4 Attach the seat plate (D) to the base of the seat cushion (G) using screws (1) and tighten with allen wrench (3). Do not full tighten the screws until all screws are in place.
- Page 8 STEP 4 Carefully lower the seat plate (D) onto the gas lift (C) as shown in the diagram.
- Page 9 STEP 5 x1 (Right) Attach the right armrest (E) to the seat cushion (G) with screws (2) and tighten 70% with allen wrench (3). DO NOT fully tighten.
- Page 10 STEP 6 x1 (Left) Attach the left armrest (F) to the seat cushion (G) with screws (2) and tighten 70% with allen wrench (3). DO NOT fully tighten.
- Page 11 STEP 7 Attach the back cushion (H) to the armrests (E) and (F), insert the screws (2) into each upper hole of armrests (E) and (F) into the back cushion (H) as shown in the diagram. Tighten 70% with allen wrench (3). DO NOT fully tighten.
- Page 12 STEP 8 Lift the back cushion (H) up as shown in the diagram. Insert screws (2) into each bottom hole of armrests (E) and (F) into the back cushion (H). Do not tighten screws before all parts are in the right place.
- Page 13 STEP 9 Assembled View: Tighten all screws using allen wrench (3). Place the caps (I) over the screws holes in the armrests (E) and (F) — four caps per side. The assembly is complete, ensure all screws are tightened before use.
