GENERAL BEST PRACTICES FOR ASSEMBLY: * Please read the assembly instructions prior to assembling this product. * Determine you have adequate space for assembly. * Assembly by two adults is recommended. * Assemble on soft surfaces to prevent damage to product finish. * Keep children away during assembly. -
Page 3: Parts List
PARTS LIST CHAIR BACK x 2 pcs FRONT LEG SEAT BOX W/SEAT CUSHION x 4 pcs x 2 pcs HARDWARE LIST LONG BOLT x 8 pcs SHORT BOLT x 6 pcs SPRING WASHER x 22 pcs Ø '' x 75 mm Ø... - Page 4 STEP 1 Place the Chair Back (A) facing up on a soft smooth surface. Attach the Seat Box W/Seat Cushion (B) to the HARDWARE NEEDED: Chair Back (A) by inserting Flat Washer (4), Spring Washer (3), Long Bolt (1) into the holes at the corner block of the Seat Cushion (B).
-
Page 5: Hardware Needed
STEP 2 HARDWARE NEEDED: Attach the Front Leg (C) to the Seat Box W/Seat Cushion (B) with Flat Washer (4), Spring Washer (3) and Medium Bolt (5) using Allen Key (6). BOTTOM ASSEMBLED VIEW... - Page 6 STEP 3 HARDWARE NEEDED: BOTTOM Carefully turn the assembled chair upright. Make sure the chair is level and fully tighten all bolts at this time using Allen Key (6). Repeat steps 1 through 3 to assemble any remaining chairs. Assembly is now complete. PRINTED IN VIETNAM...
