Appendix
Technical data – Domestic hot water
Specific flow rate (D) (ΔT = 30 K)
in accordance with EN 13203
Continuous flow rate (ΔT = 35 K)
Specific flow rate (ΔT = 35 K)
Minimum permissible pressure
Maximum permissible pressure
Temperature range
Flow rate limiter
Technical data – General
Diameter of the gas pipe
Diameter of the heating pipe
Expansion relief valve connector
(min.)
Condensed water discharge pipe
(min.)
G20 gas supply pressure
Gas flow at P max. – hot water
(G20)
CE number (PIN)
Smoke mass flow in heating mode
at P min.
Smoke mass flow in heating mode
at P max.
Smoke mass flow in hot water
handling mode at P max.
Nominal efficiency at 80/60 °C
Nominal efficiency at 50/30 °C
Nominal efficiency in partial load
operation (30%) at 40/30 °C
NOx class
Product dimensions, width
Product dimensions, depth
Product dimensions, height
Net weight
Weight when filled with water
Technical data – Electrics
Electric connection
Built-in fuse (slow-blow)
Max. power consumption
Standby electrical power con-
sumption
Level of protection
Note
The lowest nominal heat output may be higher than the value in the technical data, depending on the design of the
system and the current operating status.
46
EASICOM 3 24c EASICOM 3 28c
11.7 l/min 13.6 l/min
602 l/h 699 l/h
10.0 l/min 11.7 l/min
0.03 MPa 0.03 MPa
(0.30 bar) (0.30 bar)
1 MPa 1 MPa
(10 bar) (10 bar)
35 ... 60 ℃ 35 ... 60 ℃
8 l/min 10 l/min
EASICOM 3 24c EASICOM 3 28c
1/2 inch 1/2 inch
3/4 inch 3/4 inch
15 mm 15 mm
21.5 mm 21.5 mm
20 mbar 20 mbar
2.6 m³/h 3.0 m³/h
CE-0063CP3646 CE-0063CP3646
2.34 g/s 2.80 g/s
9.2 g/s 11.1 g/s
11.1 g/s 12.9 g/s
98.9 % 99 %
104 % 104 %
109.8 % 108.5 %
5 5
418 mm 418 mm
300 mm 300 mm
740 mm 740 mm
32 kg 32.6 kg
36 kg 37.1 kg
EASICOM 3 24c EASICOM 3 28c
230 V / 50 Hz 230 V / 50 Hz
T2/2A, 250V T2/2A, 250V
105 W 110 W
2 W 2 W
IPX4D IPX4D
Installation and maintenance instructions EASICOM 3 0020239562_02
