5.4.1.3 External termination into a gulley or hopper
L = 3m max
5.4.1.4 Internal termination into combined sink
waste
5.4.1.5 Internal termination downstream of sink
waste
Ø19mm
min
0020239562_02 EASICOM 3 Installation and maintenance instructions
Ø19mm
min
Ø30mm
Ø19mm
min
Ø30mm
Ø30mm
5.4.1.6 External termination into soakaway
500mm min
L = 3m max
Ø100mm
5.4.1.7 External termination into rain water down
pipe
5.5
Connecting the drain cock
▶
Connect a hose to the drain cock (1) and guide the free
end of the hose to a suitable outflow location.
Installation 5
Ø19mm
min
Ø30mm
Ø19mm
min
Ø30mm
1
13
