System Specifications

CPU ■
Chipset ■
Memory ■
■
■
LAN ■
■
■
Storage
Audio ■
■
Graphics ■
■
■
Left Panel
■
Input/
■
Output
■
■
■
■
■
Right
■
Panel
■
Input/
■
Output
■
■
■
Intel Ivy Bridge mobile processor
Intel HM76/ QM77 PCH
2 unbuffered non-ECC DDR3 800/ 1066/ 1333/ 1600
SO-DIMM slots
Supports the maximum of 16GB
Supports Dual Channel
1 Intel Ethernet Controller I210-AT
1 Intel 82579LM GbE controller
2 SATA 3Gb/s ports by Intel HM76/ QM77 PCH
HDA Codec by Realtek ALC888
Compliant with Azalia 1.0 specs
1 HDMI port
1 DVI-I port
1 wireless LAN antenna connector (optional)
2 serial ports
1 power button
1 HDD LED
2 USB 3.0 ports
1 DC power jack
1 security lock port
1 HDMI port
1 DVI-I port
4 USB 2.0 ports
2 RJ-45 LAN jacks
1 microphone audio jack
1 Line-Out audio jack
1 wireless LAN antenna connector
MS-9A55 MS-9A55
1-7
