  • Page 1 MS-98M3 Industrial Computer Board User Guide...

  • Page 2: Table Of Contents

    Contents Copyright and Trademarks Notice ................ 4 Technical Support....................4 Green Product Features ..................4 Environmental Policy .................... 4 Safety Information ....................5 WEEE Statement ....................6 Chemical Substances Information ................ 6 Battery ........................6 CE Conformity ......................7 FCC-B Radio Frequency Interference Statement ..........7 Specifications ......................
  • Page 3 Graphics ....................... 17 JLVDS1_EDP1, JLVDS2_EDP2: LVDS+eDP Box Header ........17 JINV1: LVDS Inverter Box Header ................ 18 Connector ......................19 SYSFAN1: System Fan Header ................19 JUSB1~2: USB 2.0 Box Header ................20 JFP1: Front Panel Box Header ................20 JCOM1_2, 3_4: COM Port Box Header(RS232/ 422/ 485)........

  • Page 4: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

  • Page 5: Safety Information

    Safety Information ∙ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ∙ Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start.

  • Page 6: Weee Statement

    Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: https://csr.msi.com/global/index Battery Please take special precautions if this product comes with a battery.

  • Page 7: Ce Conformity

    CE Conformity Hereby, Micro-Star International CO., LTD declares that this device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Specifications

    Specifications Model MS-98M3 Processor ∙ Embedded SKUs - 11th Gen Intel® IoTG Mobile Tiger Lake-UP3 Core™ i7-1185G7E/ i5-1145G7E, QC, 28W - 11th Gen Intel® IoTG Mobile Tiger Lake-UP3 Core™ i3-1115G4E, DC, 28W - 11th Gen Intel® IoTG Mobile Tiger Lake-UP3 Celeron®...
  • Page 9 Model MS-98M3 Graphics Within processor ∙ 2 x LVDS up to 1920x1200 @60Hz (Co-lay eDP) ∙ 2 x eDP up to 4096×2160 @60 Hz (Co-lay LVDS) ∙ 1 x DP 1.4a up to 7680 x 4320 @60Hz ∙ 1 x HDMI™ 1.4 up to 4096x2160 @30Hz ∙...
  • Page 10 Model MS-98M3 Onboard I/O ∙ 1 x SATA power connector ∙ 1 x System fan connector ∙ 1 x Front panel connector ∙ 2 x Dual COM port box headers (RS232/ 422/ 485) ∙ 1 x Audio/ Amplifier/ SMbus box header ∙...

  • Page 11: Rear I/O Panel

    Rear I/O Panel RJ-45 LAN Ports USB 3.2 Gen 2 Ports DisplayPort DisplayPort DisplayPort is a digital display interface standard. This connector is used to connect a monitor with DisplayPort inputs. Connector The High-Definition Multimedia Interface (HDMI™) is an all-digital audio/ video interface capable of transmitting uncompressed streams.

  • Page 12: Overview Of Components

    Overview of Components JLVDS1_EDP1 JLVDS2_EDP2 JINV1 JVDD2 JVDD1 SYSFAN1 DIMM2 DIMM1 JME_DIS1 JCOMS1 JATX1 Rear Panel I/O USIM1 M2_M1 M2_B1 JPW1 SATA1 JUSB2 JUSB1 JFP1 JPWR1 JAUD1 JGPIO1 JCOM1_2 JCOMP1 JCOMP2 JCOM3_4 M2_E1 Overview of Components...
  • Page 13 Component Contents Component page Memory DDR4 SO DIMM Slot: DIMM1, DIMM2 Power Supply JPWR1: 12V~24V DC-in Power Connector JPW1: SATA Power Connector Storage SATA1: SATA 3.0 6Gb/s Port M2_M1: M.2 Slot (M Key, 2280) Graphics JLVDS1_EDP1, JLVDS2_EDP2: LVDS+eDP Box Header JINV1: LVDS Inverter Box Header Connector SYSFAN1: System Fan Header...

  • Page 14: Memory

    Memory DDR4 SO DIMM Slot: DIMM1, DIMM2 The SO-DIMM slots is intended for memory modules. DIMM2 DIMM1 1. Locate the SO-DIMM slot. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot. 2.

  • Page 15: Power Supply

    Power Supply JPWR1: 12V~24V DC-in Power Connector This connector allows you to connect a power supply. To connect to the power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. Then push down the power supply firmly into the connector. JPWR1 DC_IN DC_IN...

  • Page 16: Storage

    Storage SATA1: SATA 3.0 6Gb/s Port This connector is SATA 6Gb/s interface port, it can connect to one SATA device. SATA1 ⚠ Important This SATA port supports hot plug. ∙ Please do not fold the SATA cable at a 90-degree angle. Data loss may result during ∙...

  • Page 17: Graphics

    Graphics JLVDS1_EDP1, JLVDS2_EDP2: LVDS+eDP Box Header These connectors are provided for LVDS/ eDP interface flat panels. After connecting an LVDS/ eDP interface flat panel to this connector, be sure to check the panel datasheet and set the JVDD1/ JVDD2 LVDS jumper to proper power voltage. JLVDS1_EDP1 JLVDS2_EDP2 EDP_LINE3_DP...

  • Page 18: Jinv1: Lvds Inverter Box Header

    JINV1: LVDS Inverter Box Header The connector is provided for LCD backlight options. JINV1 VCC5 VCC5 +12V +12V INV_ON#1 INV_ON#2 L_BKLT_CTRL#1 L_BKLT_CTRL#2 Graphics...

  • Page 19: Connector

    Connector SYSFAN1: System Fan Header The fan power connector supports system cooling fans with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND. If the motherboard has a System Hardware Monitor chipset onboard, you must use a specially designed fan with speed sensor to take advantage of the fan control.

  • Page 20: Jusb1~2: Usb 2.0 Box Header

    JUSB1~2: USB 2.0 Box Header These connectors are ideal for connecting USB devices such as keyboard, mouse, or other USB-compatible devices. JUSB1~2 USB_D1- USB_D2+ USB_D1+ USB_D2- ⚠ Important Note that the VCC and GND pins must be connected correctly to avoid possible damage.

  • Page 21: Jcom1_2, 3_4: Com Port Box Header(Rs232/ 422/ 485)

    JCOM1_2, 3_4: COM Port Box Header(RS232/ 422/ 485) This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach a serial device to it. JCOM1_2 / JCOM3_4 RS232 RS422 RS485 TXD- TXD+ RXD+ RXD- POWER Connector...

  • Page 22: Jaud1: Audio/ Amplifier/ Smbus Connector

    JAUD1: Audio/ Amplifier/ SMbus Connector This connector allows you to connect audio. It also supports amplifier function to enhance audio performance and SMBus, known as I2C, for connecting System Management Bus (SMBus) interface. JAUD1 LINE_IN_RA MIC1_RA LINE_IN_LA MIC1_LA LOUT_RA MIC1_JD LOUT_LA LINE1_JD FRONT_JD...

  • Page 23: Jgpio1: Gpio (Dio) Connector

    JGPIO1: GPIO (DIO) Connector This connector is provided for the General-Purpose Input/Output (GPIO) peripheral module. JGPIO1 GPO0 GPI0 GPO1 GPI1 GPO2 GPI2 GPO3 GPI3 GPO4 GPI4 GPO5 GPI5 GPO6 GPI6 GPO7 GPI7 VCC5 VCC5 Connector...

  • Page 24: Jumper

    Jumper ⚠ Important Avoid adjusting jumpers when the system is on; it will damage the motherboard. JVDD1 JVDD2 JME_DIS1 JCOMS1 JATX1 JCOMP1 JCOMP2 Jumper Name Default Setting Description JVDD1 1-2: 3V 2-3: 5V JVDD2 JME_DIS1 1-2: Normal 2-3: ME Disable JCMOS1 1-2: Normal 2-3: Clear CMOS...

  • Page 25: Expansion Slot

    Expansion Slot USIM1 M2_B1 M2_E1 USIM1: Nano SIM Holder This holder is provided for 3G, 4G, LTE, 5G Nano SIM cards. Expansion Slot...

  • Page 26: M2_E1: M.2 Slot (E Key, 2230)

    M2_E1: M.2 Slot (E Key, 2230) Please install the Wi-Fi/ Bluetooch card into the M.2 slot as shown below. Feature M2_E1 slot supports PCIe x 1 & USB 2.0 signal. M2_B1: M.2 Slot (B Key, 2242/ 3042) Please install the WWAN Card/ solid-state drive (SSD) into the M.2 slot as shown below.

  • Page 27: Bios Setup

    Bios Setup This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. Users may need to run the Setup program when: ∙ An error message appears on the screen at system startup and requests users to run SETUP.

  • Page 28: Control Keys

    Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Value Exit General Help Previous Values Optimized Defaults Save & Reset* Screenshot capture Scroll help area upwards <K> <M> Scroll help area downwards * When you press F10, a confirmation window appears and it provides the modification information.
  • Page 29 BIOS Item Contents Item Page The Menu Bar Main System Date System Time SATA Mode Selection Advanced Full Screen Logo Display Bootup NumLock State Configurable TDP Boot Mode CPU Configuration ■ Intel (VMX) Virtualization Technology ■ Active Processor Cores ■ Hyper-Threading ■...
  • Page 30 Item Page Boot Boot Option Priorities Security Administrator Password User Password Intel BIOS Guard Support PCH-FW Configuration ■ ME State ■ ME Unconfig on RTC Clear ■ Comms Hub Support ■ JHI Support ■ Core BIOS Done Message ■ Firmware Update Configuration ■...
  • Page 31 Item Page ■ Console Redirection Settings (Out-of-Band Management) Chipset DVMT Total Gfx Mem Panel 1/ 2 Function ■ Type Select Panel 1/ 2 Backlight Control Power Restore AC Power Loss Deep Sleep Mode OnChip USB PCIE PME Save & Exit Save Changes and Reset Discard Changes and Exit Discard Changes...

  • Page 32: The Menu Bar

    The Menu Bar ▶ Main Use this menu for basic system configurations, such as time, date, etc. ▶ Advanced Use this menu to set up the items of special enhanced features. ▶ Boot Use this menu to specify the priority of boot devices. ▶...

  • Page 33: Main

    Main HDD Information ∙ RAID (VMD) Disabled: Display HDD information as plugging in status. ∙ RAID (VMD) Enabled: Display "Not Present" only. ▶ System Date This setting allows you to set the system date. Format: <Day> <Month> <Date> <Year>. ▶ System Time This setting allows you to set the system time.

  • Page 34: Advanced

    Advanced ▶ Full Screen Logo Display This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. [Enabled] BIOS will display the full-screen logo during the boot-up sequence, hiding normal POST messages. [Disabled] BIOS will display the normal POST messages, instead of the full- screen logo.
  • Page 35 ▶ CPU Configuration ▶ Intel (VMX) Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With Virtualization, one computer system can function as multiple “virtual” systems. ▶ Active Processor Cores This setting specifies the number of active processor cores.
  • Page 36 ▶ Turbo Mode Enables or disables the Turbo Mode. This feature only display when Intel(R) SpeedStep(TM) is enabled. [Enabled] Enables this function to boost CPU performance automatically over specification when system request the highest performance state. [Disabled] Disables this function. ▶...
  • Page 37 ▶ Memory Configuration ▶ In-Band ECC Support Enables or disables In-Band ECC(Error-Correcting Code) Support. [Enabled] When enabled this function, a portion(1/32) of memory space will be reserved to store ECC data. [Disabled] Disables this function. » In-Band ECC Error Injection Enables or disables In-Band ECC Error Injection.
  • Page 38 ▶ Super IO Configuration ▶ Serial Port 1/ 2/ 3/ 4 This setting enables/disables the specified serial port. » Change Settings This setting is used to change the address & IRQ settings of the specified serial port. » Mode Select Select an operation mode for Serial Port 1/ 2/ 3/ 4.
  • Page 39 ▶ H/W Monitor (PC Health Status) These items display the current status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds. ▶ Thermal Shutdown This setting enables/disables the Thermal Shutdown function. It will automatically shuts down when the internal temperature reaches the critical level.
  • Page 40 ▶ Smart Fan Configuration ▶ SYSFAN This setting enables/ disables the Smart Fan function. Smart Fan is an excellent feature which will adjust the System fan speed automatically depending on the current system temperature, avoiding the overheating to damage your system. ▶...
  • Page 41 ▶ GPIO Group Configuration ▶ GPO0 ~ GPO7 These settings control the operation mode of the specified GPIO. BIOS Item Contents...

  • Page 42: Boot

    Boot ▶ Boot Option Priorities This setting allows users to set the sequence of boot devices where BIOS attempts to load the disk operating system. BIOS Item Contents...

  • Page 43: Security

    Security ▶ Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ▶ Intel BIOS Guard Support Intel BIOS Guard Support ensures that updates to system BIOS flash are secure. BIOS Item Contents...
  • Page 44 ▶ PCH-FW Configuration Firmware Information These settings show the ME Firmware Version System Integrity Value firmware information of the ME Firmware Mode ME Firmware Status 1 Intel ME (Management Engine). ME Firmware SKU ME Firmware Status 2 ▶ ME State This setting specifies the Intel Management Engine state.
  • Page 45 ▶ Firmware Update Configuration » ME FW Image Re-Flash This setting enables/ disables the ME FW (Firmware) image re-flash. » FW Update This setting enables/ disables the FW (Firmware) update. ▶ PTT Configuration Intel Platform Trust Technology (PTT) is a platform functionality for credential storage and key management used by Microsoft Windows.
  • Page 46 » HECI Message Check Disable This setting disables message check for BIOS boot path when sending messages. » MBP HOB Skip Setting this option will skip MBP HOB. » HECI2 Interface Communication This setting Adds/ Removes HECI2 device from PCI space. »...
  • Page 47 ▶ AMT Configuration Intel Active Management Technology (AMT) is hardware-based technology for remotely managing and securing PCs out-of-band. ▶ USB Provisioning of AMT Enables or disable USB Provisioning of AMT. ▶ CIRA Configuration » Activate Remote Assistance Process Setting this option enables will trigger CIRA boot. »...
  • Page 48 ▶ ASF Configuration » PET Progress Setting this option enables/ disables to receive PET Events. » WatchDog This setting enables/ disables the watchdog timer. » OS Timer This item displays OS Timer. » BIOS Timer This item displays BIOS Timer. »...
  • Page 49 ▶ OEM Flag Setting » MEBx hotkey Pressed This setting enables/ disables the management Engine BIOS Extension(MEBx) hotkey Pressed. » MEBx Selection Screen This setting enables/ disables the MEBx Selection Screen. » Hide Unconfigure ME Confirmation Prompt This setting enables/ disables the Hide Unconfigure ME Confirmation Prompt. »...
  • Page 50 ▶ Trusted Computing ▶ Security Device Support This setting enables/disables BIOS support for security device. When set to [Disable], the OS will not show security device. TCG EFI protocol and INT1A interface will not be available. ▶ SHA256 PCR Bank These settings enable/disable the SHA-1 PCR Bank and SHA256 PCR Bank.
  • Page 51 ▶ Serial Port Console Redirection ▶ Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables/disables the operation of console redirection. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
  • Page 52 ▶ Console Redirection Settings (COM1) » Terminal Type To operate the system’s console redirection, you need a terminal supporting ANSI terminal protocol and a RS-232 null modem cable connected between the host system and terminal(s). You can select emulation for the terminal from this setting. [ANSI] Extended ASCII character set.
  • Page 53 ▶ Console Redirection Settings (Out-of-Band Management) » Out-of-Band Mgmt Port This setting specifies the Out-of-Band Management Port. Terminal Type EMS (Windows Emergency Management Service) » You can select the type of terminal device for console redirection from this setting. [VT-UTF8] is the preferred terminal type for the out-of-band management. The next best choice is [VT100+] and then [VT100].

  • Page 54: Chipset

    Chipset ▶ DVMT Total Gfx Mem This setting specifies the memory size for DVMT. ▶ Panel 1/ 2 Function This setting enables/disables Panel 1 Function. ▶ Type Select Set your video signal interface as LVDs or eDP. This item will display when Panel 1 Function is enabled.

  • Page 55: Power

    Power ▶ Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: [Power Off] Leaves the computer in the power off state. [Power On] Leaves the computer in the power on state. [Last State] Restores the system to the previous status before power failure or interrupt occurred.

  • Page 56: Save & Exit

    Save & Exit ▶ Save Changes and Reset Save changes to CMOS and reset the system. ▶ Discard Changes and Exit Abandon all changes and exit the Setup Utility. ▶ Discard Changes Abandon all changes. ▶ Load Optimized Defaults Use this menu to load the default values set by the motherboard manufacturer specifically for optimal performance of the motherboard.
