MSI WindBOX III Plus Manual page 13

Right Side View
1
1
HDMI Port
The High-Definition Multimedia Interface (HDMI) is an all-digi-
tal audio/video interface capable of transmitting uncompressed
streams. HDMI supports all TV format, including standard, en-
hanced, or high-definition video, plus multi-channel digital audio
on a single cable.
DVI-I Port
2
The DVI-I (Digital Visual Interface-Integrated) connector allows
you to connect an LCD monitor. It provides a high-speed digital
interconnection between the computer and its display device. To
connect an LCD monitor, simply plug your monitor cable into the
DVI connector, and make sure that the other end of the cable
is properly connected to your monitor (refer to your monitor
manual for more information.)
USB 2.0 Port
3
The USB (Universal Serial Bus) port is for attaching USB devices
such as keyboard, mouse, or other USB-compatible devices.
2 3 4 5 6 7
MS-9A55 MS-9A55
1-5
