PURSUIT PRO-9642 Installation Manual

Advertisement

Note: When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door
pin switch in order to begin the passive arming sequence.

RF Programmable Features :

Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Passive Locks
5th Passive/Active Arm
6th Voltage Sense
7th Siren/Horn
8th Horn Chirp
9th Override Method
10th Chirp Delete From Tx On
To program these selectable features;
Action
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Second
Press and release the valet switch
Press transmitter Lock button to change
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Fifth
Press and release the valet switch
Press transmitter Lock button to change
Released 11-27-01.
1 Chirp
2 Chirps
1 Sec.
3.5 Sec.
Auto Lock On
Auto Lock Off
Auto UL Dr.
Auto UL All
Passive
Active
Passive Arm
Active Arm
Voltage Sense
Hardwire
Siren/Horn
Siren Only
10mS
16mS
Custom Code
Valet
Off
or
or
or
or
or
Model PRO-9642
Installation Manual
3 Chirps
4 Chirps
1 Sec L, Dbl. U/L
Auto UL Off
Horn Only
30mS
System Response
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock drivers door only
2 chirps = auto unlock all doors
2 chirps = active locks
1 chirp = passive locks
2 chirps = active arming
1 chirp = passive arming
Default
1 Sec.
Auto Lock Off
Auto UL Off
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
