Note: The method of manual override can either be selected to operate from the valet switch or operate as custom
code. Be certain to place a check mark indicating the method used in the box located on the last page of
the owner's manual.
Note: When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin
switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Headlights
5th Passive Locks
6th Passive/Active Arm
7th Voltage Sense
8th Siren/Horn
9th Horn Chirp
10th Override Method
11th Two Step Unlock
12th Chirp Delete From Tx
To program these selectable features;
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Second
Press and release the valet switch
Press transmitter Lock button to change
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
SELECTABLE FEATURES
1 Chirp
2 Chirps
1 Sec.
3.5 Sec.
Auto Lock On
Auto Lock Off
Auto UL Dr.
Auto UL All
On Arm
On Disarm
Passive
Active
Passive Arm
Active Arm
Voltage Sense
Hardwire
Siren/Horn
Siren Only
10mS
16mS
Custom Code
Valet
On
Off
On
Off
Action
or
or
or
Model PRO-9649b
Installation Manual
3 Chirps
4 Chirps
1 Sec L, Dbl. U/L
Auto UL Off
On Both
Off
Horn Only
30mS
System Response
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock drivers door only
2 chirps = auto unlock all doors
Default
1 Sec.
Auto Lock Off
Auto UL Off
Both
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
Off
128-8191
1 of 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-9649b and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PURSUIT PRO-9649b

  • Page 1 Model PRO-9649b Installation Manual SELECTABLE FEATURES Note: The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
  • Page 2 Fourth Press and release the valet switch 3 chirps = headlight output when arming and disarming Press transmitter Lock button to change 4 chirps = headlight output off Press transmitter Lock button to change 1 chirp = headlight output when arming Press transmitter Lock button to change 2 chirps = headlight output when disarming Fifth...
  • Page 3: Wiring The System

    If during the program sequence receiver channel 1 is programmed, and received channel 2 is skipped over, as indicated in the transmitted program guide, then the unit will operate as a single button lock/unlock unit from that transmitter. It is possible to have one transmitter programmed for single button lock/unlock, and one transmitter programmed for separate button lock/unlock if the customer so desires.
  • Page 4 cases will trigger the alarm when a thermostatically controlled electronic radiator cooling fan switches on. When installing this system into vehicles with electronic “after fans“, it is recommended you disable the voltage sense circuit. In voltage sensing applications, the closer to the battery that the red wire is connected, the less sensitive the voltage sense circuitry will be.
  • Page 5 Note: This is a normally closed starter cut arrangement, and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.
  • Page 6 Brown Wire: - DOOR TRIGGER If the vehicle’s courtesy light switches have a ( - ) ground output when the door is opened (GM and most Imports), you must connect this wire to the negative output from one of the door switches. WARNING: Do not use the brown wire if the vehicle has +12 volt output type door switches.
  • Page 7 Normal Door Lock Operation 6 Pin Door Lock Output Connector: The orange, blue w/ white tracer, yellow, white, green, and blue wires in the 6 conductor connector are the contacts of the on board door lock relays. The function of each of these wires is listed below; Lock Relay Unlock Relay Blue w/ White Trace = N.O.
  • Page 8: Completing The Installation

    unlock connector to terminal 85 of a VF45F11 P&B relay or equivalent automotive 12 volt relay. Connect Red/Black to terminal 86. Connect terminal 87 to a fused +12 volt source, and connect terminal 30 to the low current +12 volt switched wire from the door unlock switch. 5 Wire Alternating Door Lock Circuits: In this application, it is necessary to cut the existing door lock by - pass wires.
  • Page 9 The unit will monitor the door trigger input Positive, (Purple), and Negative, (Brown) when active. When the dome light turns off, the unit will add 2 seconds then exit the learn mode. (3) The LED will begin flashing the Armed indication indicating the unit has exited the learn mode and is armed Antenna Wire: Be sure to extend the thin black antenna wire to it’s full length, and cable tie into place where it cannot be damaged.
  • Page 10 128-8191 10 of 10...
