2 Button Remote Security System
FEATURES :
2 Two Button Programmable RF Transmitters
Two Channel Receiver ( capable of accepting 4 transmitters )
Anti-scan Technology
Remote Panic in all modes
Protected Valet
7 Function LED - Lock/Arm / Unlock/Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert with Memory
Audible Lock/Arm /Unlock/Disarm/ Defective Zone / Tamper Confirmation
Instant Siren Activation
Low Current Horn Output
Starter Disable
True Last Door Arming ( hardwire only )
Defective Zone By - Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi - Tone Siren
Additional Negative Trigger Input
RF Inhibit with ignition on
Parking Light Flasher
OPTIONS :
Single or Dual Stage Shock Sensor
Remote Trunk Release
Remote Keyless Entry
Illuminated Entry
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
with Starter Disable
Page 1
Model PRO-9344FT
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-9344FT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PURSUIT PRO-9344FT

Summary of Contents for PURSUIT PRO-9344FT

  • Page 1 Model PRO-9344FT Owner’s Manual 2 Button Remote Security System with Starter Disable FEATURES : 2 Two Button Programmable RF Transmitters Two Channel Receiver ( capable of accepting 4 transmitters ) Anti-scan Technology Remote Panic in all modes Protected Valet 7 Function LED - Lock/Arm / Unlock/Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming...

  • Page 2: Arming The System - Active

    ARMING THE SYSTEM - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid. 2. Press and release the Lock/"Arm" / Unlock/"Disarm" button on the keychain transmitter. Red dash mounted L.E.D. begins to flash slowly. Parking Lights flash one time.

  • Page 3: Disarming The System

    monitor all protected entry points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed and ignore that triggered zone. Whenever the system is armed, the red dash mounted L.E.D. indicator will slowly flash.

  • Page 4: Intrusion Warning Signals

    Red dash mounted L.E.D. turns off. If passive arming was selected during the installation, then the L.E.D. will start flashing rapidly, indicating that the system is re arming automatically. Open any door to suspend the automatic arming. Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence.

  • Page 5: Eliminating The Normal Arm / Disarm Chirps

    In the event that you lose your keychain transmitter, or if the transmitter fails to disarm the system, the valet switch can be used to disarm the alarm. Open the vehicle’s door ( the alarm will sound ). Turn the ignition key on, and move the valet switch to the on position. The alarm will disarm, and the vehicle can now be started.

  • Page 6: System Functions At A Glance

    PRO-9344FT SYSTEM FUNCTIONS AT A GLANCE DASH L.E.D. INDICATORS RAPID FLASHING PASSIVE ARMING SLOW FLASHING ARMED DISARMED ON SOLID VALET MODE 3 FLASH...PAUSE INTRUSION ZONE 3 2 FLASH...PAUSE INTRUSION ZONE 2 1 FLASH...PAUSE INTRUSION ZONE 1 SIREN CHIRP INDICATORS 1 CHIRP *...
