4.3 Digital input – DI13
DI13 substitutes AI1.
DI
+
+
Switch
The external resistor must be mounted to get the correct functionality.

4.3.1 Terminals

DI13 11 (+)
12 (-)

4.3.2 Electrical specifications

DI – Switch
Type
Cable length
Val Controls A/S • Sallingsundvej 5 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-003
Revision: 6
-
-
vc@valcontrols.com • www.valcontrols.com
Switch
1000 meters
13/13
