- Page 1 Yealink WH62 Headset Revision History Revision Date Description Initials 3/14/22 First published version. Version 1.0...
- Page 2 Overview Guide to help assist with using The Yealink WH62 Headset. How to Connect WH62 To PC 1: Connect one end of the USB cable to the PC port (2 on diagram) of the base. 2: Connect other end of USB cable to USB port on PC (3 on diagram).
- Page 3 How to Connect WH62 To Phone (Optional) 1: Connect one end of the USB cable to the phone port of the base. 2: Connect to USB port on Phone. (Only compatible with USB headset enabled phones). v1.0...
- Page 4 WH62 Buttons and Controls Name Description Base Alerts you to the audio status between base and headset. Solid green: the audio connection between base and headset is • Audio Status LED normal Flash orange: the headset is disconnected with base •...
- Page 5 Headset Mute Button Toggle the microphone on and off. Volume Up Button Adjust the volume on your headset. Volume Down Button Status and Busylight Indicates the charging, Teams, or call status. Use to power the headset on and off. Hold for 3 seconds to power the headset on. •...
- Page 6 WH62 Base Status LEDs Base State PC/desk phone button PC/desk phone device is not connected Glows white PC/desk phone device is connected and in the idle status Glows green In the call Fast flashes green Ringing Flashes green in double...
- Page 7 WH62 Headset Status LEDs Headset State Power off / idle (not on the base) Slowly flashes red Battery < 5% (low battery) Flashes red and green alternatively Firmware update Slowly flashes orange Out of range Situations related to Charging Flashes red...
- Page 8 WH62 Adjust Playback Volume On the WH62 headset, press the Volume Up/Volume Down button. WH62 Mute/ Unmute Microphone Press the Mute button. Or you can also move the microphone boom-arm up/down to mute/ unmute. v1.0...
- Page 9 Yealink USB Connect (Recommended) Yealink USB Connect is a computer software designed to manage Yealink USB devices. With Yealink USB Connect you can: Get an overview of connected Yealink USB devices • Manage your Yealink USB devices (for example, change basic/advanced settings, BT50 pair •...
- Page 10 If the prompt box disappears, you can double-click the CD drive: USB Connect in the devices and drives list. Download the Yealink USB Connect on the web page. Note: If it detects that Yealink USB Connect has been installed after connecting, Yealink USB Connect will automatically run. Yealink Update Firmware 1.
- Page 11 Important: You need to connect the PC to the micro-USB port of the headset marked with the text "PC". Note: Do not undock the headset or power off the base during the upgrade, otherwise the headset upgrade will fail. You can dock the headset in a base to upgrade again. v1.0...
- Page 12 Selecting WH62 from newVoice Desktop Click on Tools Then Select Options Click On Audio Options Select Yealink WH62 from drop down menus for Microphone and In-call Audio Select a source from the drop down list you wish the notification and ringing to play.
