DBBS Brakes
57
28
A
58
8
12 16
2 34
6
31 14
29
Table 1
Item Description
ITEM DESCRIPTION
2 Mounting Flange
6 Stud
8 Friction Disc
12 Clamp Tube
14 Pressure Plate
16 Spring Housing
17 Flat Washer
18 Locknut
19 Cylinder
20 Hex Head Screw
21 Inner Lip Seal
22 Spring
27 20 17
21
22
19
53
52
23
18
17
Figure 1 (2 Disc DBBS)
Item Description
ITEM
23
27
28
29
31
34
52
53
57
58
105
Airflex DBB 8110 Brake Assembly E-CLCL-TT001-E
®
105
DESCRIPTION
Outer Lip Seal
Spacer Tube
Gear
Wear Spacer
Reaction Plate
Release Spring
Inner Spring
Spring Retainer
Flat Head Screw
Disc
Brass Pipe Plug
