Operating Guide
AFQM 2, AFQMP 2 (PN 16/25/40)
AFQM 2 PN16/25/40
AFQMP 2 PN16/25
DN 65-250
DN 65-250
ENGLISH
© Danfoss | 2019.04
AFQM 2
PN 16/25/40
DN 65-125 +
AMV(E) 55/56
Flow Controller with integrated control valve AFQM 2, AFQMP 2
AFQM 2
AFQMP 2
PN 16/25/40
PN 16/25
DN 65-250 +
DN 65-125 +
AMV(E) 65x
AMV(E) 55/56
AFQMP 2
AFQMP 2 /
PN 16/25
AMEi 6 iSET
DN 65-250 +
PN 16/25
AMV(E) 65x
DN 65-125 +
AMV(E) 55/56
www.danfoss.com
AFQMP 2 /
AMEi 6 iSET
PN 16/25
DN 65-250 +
AMV(E) 65x
Page 8
VI.LI.K1.02 | 1
Advertisement
Related Manuals for Danfoss AFQM 2 PN16
Summary of Contents for Danfoss AFQM 2 PN16
- Page 1 Operating Guide AFQM 2, AFQMP 2 (PN 16/25/40) AFQM 2 PN16/25/40 AFQMP 2 PN16/25 AFQM 2 AFQM 2 AFQMP 2 AFQMP 2 AFQMP 2 / AFQMP 2 / DN 65-250 DN 65-250 PN 16/25/40 PN 16/25/40 PN 16/25 PN 16/25...
- Page 2 AFQM 2, AFQMP 2 AUTO MAINTENANCE 5-95 % RH 2 / 4 mm no condensing FREE ❶ ❷ ① ② ❸ ② ③ ① ❹ T < 100 °C T > 100 °C ① 2 | © Danfoss | 2019.04 VI.LI.K1.02...
- Page 3 AFQM 2, AFQMP 2 ❺ AMV(E) 65x AMV(E) 55/56 ① ① ② ② ❻ AMV(E) 55/56 AMV(E) 65x ⑨ AMV(E) 55/65x ⑧ ⑩ VI.LI.K1.02 © Danfoss | 2019.04 | 3...
- Page 4 ~ 30 turns Release Hold for ½ turn ① Δp = 0.1-0.7 bar ② SW36 ④ ⑤ ③ SW36 ❾ ② ① Note: setting can be done by hand or using allen key. 4 | © Danfoss | 2019.04 VI.LI.K1.02...
- Page 5 No. of revolutions DN 80 DN 100 DN 125 No. of revolutions No. of revolutions No. of revolutions DN 150 DN 250 DN 200 No. of revolutions No. of revolutions No. of revolutions VI.LI.K1.02 © Danfoss | 2019.04 | 5...
- Page 6 DN 100 DN 80 DN 125 No. of revolutions No. of revolutions No. of revolutions DN 250 DN 150 DN 200 No. of revolutions No. of revolutions No. of revolutions ⓬ ② ① 6 | © Danfoss | 2019.04 VI.LI.K1.02...
- Page 7 AMV(E) 55, 56/ AMEi 6 iSET/ AMV(E) 65X/ AMEi 6 iSET/ AMV(E) 55, 56/AFQMP 2 AMV(E) 65X/AFQMP 2 AFQMP 2 AFQMP 2 DN 65-125, PN 16/25 DN 65-250, PN 16/25 DN 65-125, PN 16/25 DN 65-250, PN 16/25 VI.LI.K1.02 © Danfoss | 2019.04 | 7...
- Page 8 ❿ and ⓫. Manual adjustment of the valve depend 2. Adjustment with heat meter, see ⓬. on type of the AMV(E) 65x actuator (See instructions for particular type of AMV(E) 65x for manual operation). 8 | © Danfoss | 2019.04 VI.LI.K1.02...
- Page 9 AMV(E) 55/56, AMV(E) 65x, instructions. The adjustment of the valve stroke is completed. 8. The adjusting screw may be sealed (drilling). Dimensions ⓭ VI.LI.K1.02 © Danfoss | 2019.04 | 9...
- Page 10 AFQM 2, AFQMP 2 10 | © Danfoss | 2019.04 VI.LI.K1.02...
- Page 11 AFQM 2, AFQMP 2 VI.LI.K1.02 © Danfoss | 2019.04 | 11...
- Page 12 Heating Segment • heating.danfoss.com • +45 7488 2222 • E-Mail: heating@danfoss.com Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in speci cations already agreed.
