Your safety, and the safety of others, is very important. To help you make informed decisions about safety, we have provided installation
and operating instructions and other information on labels and in this guide. This information alerts you to potential hazards that could
hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good
judgment.
CARELESS INSTALLATION AND OPERATION CAN RESULT IN SERIOUS INJURY OR EQUIPMENT DAMAGE.
READ AND UNDERSTAND ALL SAFETY PRECAUTIONS AND OPERATING INSTRUCTIONS BEFORE INSTALLING
AND OPERATING THIS PRODUCT.
This guide identifies potential hazards and has important safety messages that help you and others avoid personal injury or death.
WARNING and CAUTION are signal words that identify the level of hazard. These signal words mean:
WARNING signals a hazard that could cause serious injury or death, if you do not follow recommendations.
CAUTION signals a hazard that may cause minor to moderate injury, if you do not follow recommendations.
This guide uses NOTICE to call attention to important mechanical information, and Note: to emphasize general information worthy of
special attention.
SEVERE INJURY OR DEATH MAY RESULT IF YOU IGNORE ANY
OF THE FOLLOWING.
• Read the Winch Operator's Manual, ATV Operator's Manual, and all
warning labels before operating the winch and ATV.
• Stay clear of moving parts and cable. Keep others away when
operating the winch.
• Inspect the winch mechanism, fasteners, and cable, before operating.
Replace all worn or damaged parts before operating.
• Make sure the winch is deactivated when leaving the ATV unattended.
PART NO.
INSTALLATION INSTRUCTION
ATV WINCH MOUNT
Mount Kit: PN 38581
Application:
39032
38639
37205
1402
1322
1321
21331
2079
711092
7352
YAMAHA WOLVERINE 4 x 4, 97-00+
WARNING
PARTS LIST:
QUANTITY
1
2
4
4
8
8
2
2
2
2
PAGE 1
DESCRIPTION
Mounting plate
Support strap
u-bolt, ¼-20
5/16 lock washer
¼-20, hex nut
¼ lock washer
5/16-18, hex cap screw
5/16-18, hex nut
Spacer
M8 x 1.25 x 25mm, hex cap screw
38640D0
Advertisement
Related Manuals for Warn 38581
Summary of Contents for Warn 38581
- Page 1 This information alerts you to potential hazards that could hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good judgment.
- Page 2 INSTRUCTIONS: 1. Place the winch mounting plate into position on the two fame tubes see figure 1. Place the u-bolts around the frame tubes and through the mounting plate as shown in figure 2. Attach the mounting plate with eight 1\4-20 hex nuts, and lock washers. Only tighten finger tight at this time.
- Page 3 Figure 3 Figure 4 8. Refer to winch manual for electrical connection instructions. PAGE 3 38640D0...
