  • Page 1 W740SU...
  • Page 3 Preface Notebook Computer W740SU Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W740SU se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup °...
  • Page 11 Preface Contents Introduction ..........1-1 Schematic Diagrams......... B-1 Overview ..................1-1 System Block Diagram ..............B-2 Specifications ..................1-2 TPM ....................B-3 External Locator - Top View with LCD Panel Open ......1-4 Processor 1/7-DMI, FDI, PEG ............B-4 External Locator - Front & Right Side Views .........1-5 Processor 2/7- CLK, MISC .............B-5 External Locator - Left Side &...

  • Page 12: Table Of Contents

    Preface 5VS, 3.3VS, 5V, 3.3V, VCCDDQ ..........B-31 1.05V .................... B-32 VDD3, VDD5, 3.3VM ..............B-33 VDDQ, VDDQ_VTT, 1.5VS ............B-34 VCORE ..................B-35 AC-IN, Charger ................B-36 POWER SWITCH BOARD ............B-37 HDD Board .................. B-38 LED Board ................... B-39 Card Reader ..................
  • Page 13 Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W740SU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.
  • Page 14 Introduction Specifications Processor Options Keyboard Intel® Core™ i7 Processor “WinKey” keyboard (with embedded numeric keypad) i7-4750HQ (2.0GHz) Pointing Device  6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 47W Built-in Touchpad Core Logic Latest Specification Information Interface The specifications listed here are correct at the Intel®...
  • Page 15 Introduction Communication Built-In Gigabit Ethernet LAN 1.0M HD PC Camera Module WLAN/ Bluetooth Half Mini-Card Modules: (Factory Option) Intel® Centrino® Advanced-N 6235 Wireless LAN (802.11a/g/n) + Bluetooth 4.0 (Factory Option) Intel® Centrino® Advanced-N 6205 Wireless LAN (802.11a/g/n) (Factory Option) Third-Party Wireless LAN (802.11b/g/n) (Factory Option) Third-Party Wireless LAN (802.11b/g/n) + Bluetooth 4.0 Environmental Spec...
  • Page 16 Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-in PC Camera (Optional) 2. PC Camera LED 3. Built-In Microphone 4. LCD 5. Power Button 6. Keyboard 7. Touchpad & Buttons 1 - 4 External Locator - Top View with LCD Panel Open...
  • Page 17 Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator FRONT VIEW Figure 3 Right Side View 1. Headphone-Out RIGHT SIDE VIEW Jack 2. Microphone-In Jack 3. USB 3.0 Port 4. 1 * Powered (AC/ DC) USB 3.0 Port 5.
  • Page 18 Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent/Fan Intake/ Outlet 2. DC-In Jack LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. Mini Display Port 5. HDMI-Out Port Figure 5 REAR VIEW Rear View 1.
  • Page 19 Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent/Fan Intake/ Outlet 2. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...
  • Page 20 Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Mini-Card Connector (mSATA Module) 2. Memory Slots DDR3 SO-DIMM x 2 3. Mini-Card Connector (WLAN Module) 4. Intel CPU 5. Platform Controller 6. CMOS Battery 1 - 8 Mainboard Overview - Top (Key Parts)
  • Page 21 Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. KBC-ITE IT8587 Mainboard Overview - Bottom (Key Parts) 1 - 9...
  • Page 22 Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. RJ-45 LAN Jack 3. Mini Display Port 4. HDMI-Out Port 5. EDP Connector 6. Speaker Connector 7. LED Connector 8. TP Connector 9. CCD Connector 10.
  • Page 23 Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Fan 1 Connector 2. Fan 2 Connector 3. Battery Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...
  • Page 25 Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W740SU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.
  • Page 26 Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...
  • Page 27 Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.
  • Page 28 Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the HDD: 1.
  • Page 29 Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove screws from the bottom cover (Figure 1a a. Remove the screws. 3. Lift the bottom cover from point (Figure 1b b. Remove the bottom cov- 4.
  • Page 30 Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal (cont’d.) or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly Removing the Keyboard Figure 3 Keyboard Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. Lift the center cover at point toward the direction of the arrow (Figure 4a). a. Lift the center cover. 3.
  • Page 32 Disassembly 6. Carefully lift up the keyboard off the computer (Figure 5d). Figure 4 7. Remove the keyboard shielding plate up and off the bottom case (Figure 5e). Keyboard Removal 8. Reverse the process to install a new keyboard. (cont’d.) d.
  • Page 33 Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L (Up to 1600 MHz). The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB and 2048MB DDRIII Modules.
  • Page 34 Disassembly Removing the Wireless LAN Module Figure 6 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard and keyboard ribbon cable under the Wire- less LAN module (Figure...
  • Page 35 Disassembly Removing the mSATA Module Figure 7 mSATA Module 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and keyboard (page 2 - Removal 2. The mSATA module will be visible at point on the mainboard (Figure 8a).
  • Page 36 Disassembly 2 - 12...
  • Page 37 Appendix A:Part Lists This appendix breaks down the W740SU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.
  • Page 38 Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Top-Bottom page A - 4 page A - 5 A - 2...
  • Page 39 Top-Bottom Figure A - 1 Top-Bottom Top-Bottom A - 3...
  • Page 40 Figure A - 2 A - 4 HDD...
  • Page 41 Figure A - 3 LCD A - 5...
  • Page 42 A - 6...
  • Page 43 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W740SU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 44: 5Vs,3.3Vs,5V,3.3V,Vccddq

    Schematic Diagrams System Block Diagram POWER SWITCH BOARD 5VS,3.3VS,5V,3.3V,VCCDDQ W740SU Shark Bay System Block Diagram SHEET 37 SHEET 31 HDD BOARD 1.05V series SHEET 38 SHEET 32 LED BOARD Haswell 1333/1600 MHz VDD3,VDD5,3.3VM SHEET 39 <=4.3" SHEET 13 PROCESSOR SHEET 14...
  • Page 45 Schematic Diagrams SLB9635TT & SLB9655TT Co-Layout 3.3VS LPC_AD0 C414 C414 C416 C416 C413 C413 C415 C415 17,30 LPC_AD0 LAD0 VDD1 LPC_AD1 17,30 LPC_AD1 LAD1 VDD2 LPC_AD2 SLB9655 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 17,30 LPC_AD2 LAD2 VDD3 LPC_AD3 R565 R565 17,30...
  • Page 46 Schematic Diagrams Processor 1/7-DMI, FDI, PEG Haswell Processor 1/7 ( DMI,FDI,PEG ) HASWELL_BGA_E HASWELL_BGA_E 12 mil R246 R246 24.9_1%_04 24.9_1%_04 VCCIOA_OUT PEG_RCOMP PEG_RXN0 DMI_TXN0 DMI_RXN0 PEG_RXN1 DMI_TXN0 DMI_TXN1 DMI_TXN1 DMI_RXN1 PEG_RXN2 DMI_TXN2 DMI_TXN2 DMI_RXN2 PEG_RXN3 DMI_TXN3 DMI_TXN3 DMI_RXN3 PEG_RXN4 PEG_RXN5 DMI_TXP0 DMI_TXP0 DMI_RXP0...
  • Page 47 Schematic Diagrams Processor 2/7- CLK, MISC PU/PD for JTAG signals Haswell Processor 2/7 ( MISC,JTAG,CLK ) D03 del J_XDP1, R572, R573, R574, R575 1.05VS XDP_TMS 51_04 51_04 XDP_TDI_R R219 R219 51_04 51_04 XDP_PREQ# *51_04 *51_04 XDP_TDO_R 51_04 51_04 HASWELL_BGA_E HASWELL_BGA_E XDP_TCLK 51_04 51_04...
  • Page 48 Schematic Diagrams Processor 3/7- (DDR3) Haswell Processor 3/7 ( DDR3L ) HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E M_A_DQ[63:0] M_B_DQ[63:0] M_A_DQ0 AH54 BD31 RSVD_BD31 M_B_DQ0 AC54 AY36 RSVD_AY36 SA_DQ0 RSVD SB_DQ0 RSVD M_A_DQ1 AH52 BE25 M_A_CLK_DDR#0 M_B_DQ1 AC52 AW27 M_B_CLK_DDR#0 M_A_CLK_DDR#0 M_B_CLK_DDR#0 SA_DQ1 SA_CKN0 SB_DQ1 SB_CKN0...
  • Page 49 Schematic Diagrams Processor 4/7- Display Haswell Processor 4/7 ( DISPLAY ) VCCIOA_OUT HASWELL_BGA_E HASWELL_BGA_E 10K_04 10K_04 DP_B#0 EDP_AUXN 13 DDIB_TXN0 EDP_AUXN DP_B0 DDIB_TXP0 EDP_AUXP EDP_AUXP 13 DP_B#1 DDIB_TXN1 EDP_HPD DP_B1 DDIB_TXP1 mini DP DP_B#2 DDIB_TXN2 EDP_TXN0 EDP_TXN0 13 DP_B2 DDIB_TXP2 EDP_TXN1 EDP_TXN1 13 Sheet 6 of 42...
  • Page 50 Schematic Diagrams Processor 5/7- Power V_VCCDDQ VDDQ Haswell Processor 5/7 ( POWER ) D02 short PJ18 PJ18 C242 C242 *5mm *5mm *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 47W->85A VCORE VCORE C245 C245 HASWELL_BGA_E HASWELL_BGA_E *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 RSVD C173 C173 C140 C140 C131 C131 C133 C133 C127 C127...
  • Page 51 Schematic Diagrams Processor 6/7- GND VCORE VCORE HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E Haswell Processor 6/7 ( POWER,GND ) AB45 BC10 AB46 BC12 BC15 AC46 BC18 AC47 BC22 HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E BC26 AD46 BC30 AT40 AY50 AJ48 BC33 AT42 AJ51 AE46 BC36 AT43 AJ54...
  • Page 52 Schematic Diagrams Processor 7/7- RSVD Haswell Processor 7/7 ( RESERVED ) CFG STRAPS FOR PROCESSOR HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E HASWELL_BGA_E RSVD_F1 RSVD_TP RSVD_E1 RSVD_TP RSVD_BE4 RSVD_A5 RSVD_TP RSVD_TP PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS RSVD_BD3 RSVD_A6 TP_A3 RSVD_TP RSVD_TP DAISY_CHAIN_NCTF_A3 TP_A4...
  • Page 53 Schematic Diagrams DDR3 SO-DIMM_0 CHA SO-DIMM CHANGE TO STANDARD JDIMM2A JDIMM2A JDIMM2B JDIMM2B M_A_A[15:0] M_A_DQ[63:0] 5 M_A_A0 M_A_DQ0 M_A_A1 M_A_DQ1 VDDQ M_A_A2 M_A_DQ2 M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 VDD1 VSS16 M_A_A5 M_A_DQ5 VDD2 VSS17 M_A_A6 M_A_DQ6 VDD3 VSS18 M_A_A7 M_A_DQ7 VDD4 VSS19 M_A_A8 M_A_DQ8...
  • Page 54 Schematic Diagrams DDR3 SO-DIMM_1 CHB SO-DIMM CHANGE TO STANDARD JDIMM1A JDIMM1A JDIMM1B JDIMM1B M_B_B[15:0] M_B_DQ[63:0] 5 M_B_B0 M_B_DQ0 M_B_B1 M_B_DQ1 VDDQ M_B_B2 M_B_DQ2 M_B_B3 M_B_DQ3 M_B_B4 M_B_DQ4 VDD1 VSS16 M_B_B5 M_B_DQ5 VDD2 VSS17 M_B_B6 M_B_DQ6 VDD3 VSS18 M_B_B7 M_B_DQ7 VDD4 VSS19 M_B_B8 M_B_DQ8...
  • Page 55 Schematic Diagrams PANEL eDP PANEL 3.3VS BAV99N3 BAV99N3 D02A add PJ30 PJ30 FCM1608K-121T06 FCM1608K-121T06 R260 R260 10K_04 10K_04 VLED EDP_HPD 6 C238 C238 220p_50V_NPO_04 220p_50V_NPO_04 VLED OPEN_2A OPEN_2A PLVDD 3.3V C216 C216 J_DP1 J_DP1 R285 R285 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 *P2003EVG *P2003EVG *220_04 *220_04 R292...
  • Page 56 Schematic Diagrams HDMI HDMI CONNECTOR D03 modify add U3 del D13, R525 5VS_HDMI FLG# VOUT1 J_HDMI1 J_HDMI1 VIN1 VOUT2 C106 C106 C105 C105 VIN2 VOUT3 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 4,31,32,34 SUSB HDMI_HPD-C HOT PLUG DETECT SY6288DCAC SY6288DCAC DDC/CEC GND HDMI_SDA-C HDMI_SCL-C RESERVED HDMI_CEC...
  • Page 57 Schematic Diagrams Mini Display Port mini-Display PortI CONNECTOR For Safety LPS. 3.3VS 3.3VS_FUSE R128 R128 0.2R 5% SMD0603 0.2R 5% SMD0603 R127 R127 0.2R 5% SMD0603 0.2R 5% SMD0603 R123 R123 0.2R 5% SMD0603 0.2R 5% SMD0603 R122 R122 0.2R 5% SMD0603 0.2R 5% SMD0603 AO3402L AO3402L...
  • Page 58 Schematic Diagrams PCH 1/10 - RTC, HDA, SATA Lynx Point (RTC,AZALIA,SATA,JTAG) D02 modify 18p -> 12p INTVRMEN- Integrated SUS C100 C100 1.05V VRM Enable 12p_50V_NPO_04 12p_50V_NPO_04 High - Enable Internal VRs RTCVCC Low - Enable External VRs VDD3 R165 R165 LPT_PCH_M_EDS LPT_PCH_M_EDS C102...
  • Page 59 Schematic Diagrams PCH 2/10 - LPC, SMBUS SPI, CL vPRO Lynx Point (LPC,SMBUS SPI,C-LINK) VDD3 RTC-WakeUp PCH_BT_EN# R431 R431 10K_04 10K_04 SMB_CLK R458 R458 2.2K_04 2.2K_04 SMB_DATA R457 R457 2.2K_04 2.2K_04 DRAMRST_CNTRL R432 R432 1K_04 1K_04 LPT_PCH_M_EDS LPT_PCH_M_EDS SML0_DATA R394 R394 2.2K_04 2.2K_04...
  • Page 60 Schematic Diagrams PCH 3/10 - DMI, FDI, PWRGD Lynx Point (DMI,FDI,GPIO) DSWODVREN - On Die DSW VR Enable R1 STUFFED, Enabled (DEFAULT) LPT_PCH_M_EDS LPT_PCH_M_EDS R2 UNSTUFFED DMI_RXN0 AW22 DMI_RXN0 DMI_RXN_0 AR20 DMI_RXN1 DMI_RXN1 DMI_RXN_1 AJ35 R1 STUFFED, Disabled FDI_RXN_0 FDI_TXN0 6 DMI_RXN2 AP17 DMI_RXN2...
  • Page 61 Schematic Diagrams PCH 4/10 - CRT, Display, PCI Lynx Point (CRT,DISPLAY,PCI) Flash Descriptor security override strap R331 R331 2.2K_04 2.2K_04 3.3VS LOW = PCI_GNT#3 swap override LPT_PCH_M_EDS LPT_PCH_M_EDS R332 R332 2.2K_04 2.2K_04 PCI_GNT#3 HIGH = Default VGA_BLUE DDPB_CTRLCLK DP_B_CLK 15 Sheet 18 of 42 VGA_GREEN DDPB_CTRLDATA...
  • Page 62 Schematic Diagrams PCH 5/10 - PCIe, USB Lynx Point (PCIe,USB) LPT_PCH_M_EDS LPT_PCH_M_EDS AW31 USB_PN0 27 USB3_RXN3 PERN1/USB3RN3 USB2N0 AY31 USB3 PORT1 USB3_RXP3 USB_PP0 27 PERP1/USB3RP3 USB2P0 USB3 PORT3 USB2N1 USB_PN1 27 BE32 USB3 PORT2 USB_PP1 27 USB3_TXN3 PETN1/USB3TN3 USB2P1 BC32 USB3_TXP3 USB_PN2 27 PETP1/USB3TP3...
  • Page 63 Schematic Diagrams PCH 6/10 - GPIO, Misc VDD3 D02A stuff Lynx Point (GPIO, MISC, VSS) R470 R470 10K_04 10K_04 PCH_GPIO8 R472 R472 10K_04 10K_04 PCH_GPIO24 R189 R189 10K_04 10K_04 SB_BLON R194 R194 *10K_04 *10K_04 LANW AKE_N 3.3VS SMI# SCI# SATA4GP MFG_MODE LPT_PCH_M_EDS LPT_PCH_M_EDS...
  • Page 64 Schematic Diagrams PCH 7/10 - CLK Lynx Point (CLK) 3.3VS CARDER_PCIECLKRQ1# R171 R171 10K_04 10K_04 PCIECLKRQ2# R183 R183 10K_04 10K_04 LPT_PCH_M_EDS LPT_PCH_M_EDS vPRO AB35 VDD3 CLKOUT_PCIE_N_0 CLKOUT_PEG_A AB36 PCIECLKRQ0# CLKOUT_PCIE_P_0 CLKOUT_PEG_A_P PCIECLKRQ5# PCIECLKRQ0# PEGA_CLKRQ# GLAN_PCIECLKRQ4# PCIECLKRQ0#/GPIO73 PEGA_CLKRQ#/GPIO47 PCIECLKRQ6# CLK_PCIE_CARD# AA44 CLK_PCIE_CARD# CLKOUT_PCIE_N_1 CLKOUT_PEG_B...
  • Page 65 Schematic Diagrams PCH 8/10 - POWER Lynx Point (POWER) D02 del C47, C49, C52, L4 add R373 LPT_PCH_M_EDS LPT_PCH_M_EDS 1.05VS R373 R373 *15mil_short_06 *15mil_short_06 VCCADAC1_5 1.312A AA24 CRT DAC CRT DAC AA26 AD20 R347 R347 *15mil_short_06 *15mil_short_06 VCCADACBG3_3 C271 C271 C296 C296 C270...
  • Page 66 Schematic Diagrams PCH 9/10 - Power Lynx Point (POWER) VDD3 0.1u_10V_X5R_04 0.1u_10V_X5R_04 C283 C283 LPT_PCH_M_EDS LPT_PCH_M_EDS R365 R365 0_04 0_04 VDD3 1.05VS C301 C301 0.1u_10V_X5R_04 0.1u_10V_X5R_04 C295 C295 0.1u_10V_X5R_04 0.1u_10V_X5R_04 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 R121 R121 0_04 0_04 0.015A VDD3 VCCSUS3_3 GPIO/LPC GPIO/LPC...
  • Page 67 Schematic Diagrams PCH 10/10 - GND Lynx Point (GND) LPT_PCH_M_EDS LPT_PCH_M_EDS LPT_PCH_M_EDS LPT_PCH_M_EDS AL34 AA16 AL38 AA20 AA22 AM14 AA28 AM24 AM26 AB12 AM28 AB34 AM30 AB38 BA40 AM32 BD11 AM16 BD15 AN36 AC44 BD19 AN40 AD14 AY36 AN42 AD16 AT43 AD18 BD31...
  • Page 68 Schematic Diagrams WLAN, mSATA mSATA 3.3V 3.3V_mSATA >40 mil R533 R533 *32mil_short *32mil_short C411 C411 C412 C412 J_mSATA1 J_mSATA1 40 mil *10u_10V_Y5V_08 *10u_10V_Y5V_08 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 WAKE# 3.3VAUX_0 3.3V_mSATA 1.5VS_mSATA COEX1 1.5V_0 COEX2 UIM_PWR C400 C400 UIM_DATA CLKREQ# UIM_CLK 1.5VS 1.5VS_mSATA 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 REFCLK-...
  • Page 69 Schematic Diagrams CCD, FAN, CLICK R468 R468 *0_06 *0_06 D02A add 3.3VS_CCD 48 mil 48 mil FON1# 3.3VS VOUT C218 C218 VOUT C220 C220 C217 C217 VSET R296 R296 C215 C215 2.2u_6.3V_X5R_06 2.2u_6.3V_X5R_06 CCD_EN *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *4.7u_6.3V_X5R_06 *4.7u_6.3V_X5R_06 0_04 0_04 *AX995SA *AX995SA 1u_6.3V_X5R_04...
  • Page 70 Schematic Diagrams LAN, RJ-45 GIGA LAN(INTEL LAN I217LM) D02 change to short LMX1- DLMX1- J_RJ1 J_RJ1 LMX1+ DLMX1+ LAN_MDIN0 *W CM2012F2S-161T03-short *W CM2012F2S-161T03-short DLMX1+ GND1 LAN_MDIN0 TD4- MX4- shield LAN_MDIP0 LMX2- DLMX2- DLMX1- GND2 LAN_MDIP0 TD4+ MX4+ shield LAN_MDIN1 DLMX2+ LAN_MDIN1 TD3- MX3-...
  • Page 71 Schematic Diagrams VT1802S EMI Require AUDIO CODEC VT1802S PVDD5V 976 *HCB1005KF-121T20 *HCB1005KF-121T20 R272 R272 0RXQW 5 5 5 5 5 5 5 5 Layout note: 5HPRYH 5 5 5 5 5 5 5 5 AUDG 3.3VS_AUD *15mil_short_06 *15mil_short_06 GND and AUDG space is For 3.3V HDA Link.
  • Page 72 Schematic Diagrams KBC-ITE IT8587E KBC_AVDD VDD3 HCB1005KF-121T20 HCB1005KF-121T20 VDD3 VDD3 MODEL_ID VOLTAGE VDD3 C408 C408 C398 C398 C418 C418 C376 C376 J_80DEBUG1 J_80DEBUG1 C401 C401 C402 C402 C404 C404 P150EM 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_10V_Y5V_08 10u_10V_Y5V_08 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 R520 R520 3IN1 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04...
  • Page 73 Schematic Diagrams 5VS, 3.3VS, 5V, 3.3V, VCCDDQ DD_ON# SUSB 3.3V 3.3VS VDD3 VDD3 NMOS NMOS PQ31A PQ31A PQ32A PQ32A SYS15V VDD3 MTNN20N03Q8 MTNN20N03Q8 3.3V SYS15V MTNN20N03Q8 MTNN20N03Q8 3.3VS PR111 PR111 VDD3 PR95 PR95 10K_04 10K_04 100K_04 100K_04 Power Plane DD_ON# PR120 PR120 PR116...
  • Page 74 Schematic Diagrams 1.05V VDD5 PR67 PR67 280K_1%_04 280K_1%_04 1.05V_LAN_M For CV test VDD3 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 IMAX:10A 4.7u_25V_X5R_08 4.7u_25V_X5R_08 4.7u_25V_X5R_08 4.7u_25V_X5R_08 *CV-40mil *CV-40mil 1u_6.3V_X5R_04 1u_6.3V_X5R_04 PR68 PR68 PR11 PR11 10K_04 10K_04 PR73 PR73 PC99 PC99 10_04 10_04 1.05V_LAN_M 0_06 0_06 PC12 PC12 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06...
  • Page 75 Schematic Diagrams VDD3, VDD5, 3.3VM VREF VDD3/VDD5 *0_04 *0_04 PR60 PR60 *20mil_04 *20mil_04 PC93 PC93 PC158 PC158 PC157 PC157 1u_6.3V_X5R_04 1u_6.3V_X5R_04 PR59 PR59 EN_3V EN_5V PC97 PC97 137K_1%_04 137K_1%_04 120K_04 120K_04 PC96 PC96 1000p_50V_X7R_04 1000p_50V_X7R_04 D02 add 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PC98 PC98 PC24...
  • Page 76 Schematic Diagrams VDDQ, VDDQ_VTT, 1.5VS 1.5V or 1.35V/0.75VS PD11 PD11 PQ10 PQ10 1.5V or 1.35V MDU1516 MDU1516 PC39 PC39 PC36 PC36 PC37 PC37 PC38 PC38 ULTRASO-8 ULTRASO-8 IMAX:23A RB0540S2 RB0540S2 G5616 G5616 VDDQ_VTT PC55 PC55 Z3709 OCP:25A 10u_10V_Y5V_08 10u_10V_Y5V_08 VDDQ_R VDDQ PC50 PC50...
  • Page 77 Schematic Diagrams VCORE PC162 PC162 PC161 PC161 PC160 PC160 PC154 PC154 PC95 PC95 PC16 PC16 PRT1 PRT1 100K_NTC_06_A 100K_NTC_06_A PR78 PR78 SWN3 150K_1%_06 150K_1%_06 PUT COLSE 6-13-15031-28C TO VCORE PR82 PR82 PR74 PR74 SWN1 Phase 1 PR23 PR23 165K_1%_04 165K_1%_04 150K_1%_06 150K_1%_06 APGND...
  • Page 78 Schematic Diagrams AC-IN, Charger Z4110 PR141 PR141 *20mil_04 *20mil_04 D02A no stuff SMART CHARGER PQ20 PQ20 ME4425 ME4425 D02 EMI add V_BAT PC159 PC159 PR140 PR140 *10K_06 *10K_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 6-15-32023-7B0 JBATTA2 VDD3 J_DC_JACK1 J_DC_JACK1 PQ37 PQ37 PQ24A PQ24A HCB4532K-800_18 HCB4532K-800_18 close to J_BAT1 ME4425...
  • Page 79 Schematic Diagrams POWER SWITCH BOARD POWER BUTTON POWER SWITCH LED L1_3.3VS 6-53-3050B-042 L1_SW1 L1_SW1 Connected to the Page[27] TJG-532-V-T/R TJG-532-V-T/R 20mil L1_M_BTN# L1R1 L1R1 L1J_BTN1 L1J_BTN1 220_04 220_04 J_BTN1 L1_3.3VS L1C2 L1C2 D03 unstuffed L1_M_BTN# L1D1 L1D1 20mil *V15AVLC0402 *V15AVLC0402 *0.1u_50V_Y5V_06 *0.1u_50V_Y5V_06 L1GND...
  • Page 80 Schematic Diagrams HDD Board Connected to the Page[27] HDD BOARD HJ_SATA_HDD1 HJ_SATA_HDD1 H_5VS H_3.3VS HSATA_RXP0 HSATA_TXP0 HSATA_RXN0 HSATA_TXN0 D02A add PCBA C1943 C1943 *0_04 *0_04 *0_04 *0_04 *0_04 *0_04 HGND HGND Sheet 37 of 42 HDD Board HJ_HDD1 HJ_HDD1 HSATA_TXP0 HSATA_TXN0 0.01u_16V_X7R_04 0.01u_16V_X7R_04...
  • Page 81 Schematic Diagrams LED Board LID SWITCH IC L2_VDD3 L2_LED_ACIN L2_LED_PWR L2_LED_BAT_CHG L2_LED_BAT_FULL D01A 180 change to 220 L2R1 L2R1 100K_04 100K_04 L2R2 L2R2 L2R4 L2R4 L2R3 L2R3 L2R5 L2R5 L2U1 L2U1 220_04 220_04 220_04 220_04 220_04 220_04 220_04 220_04 L2_LID_SW# L2C2 L2C2 L2C3...

  • Page 82: Card Reader

    Schematic Diagrams Card Reader ASD_WP ASD_CD# 3.3V_IN A_3.3VS 40 mil APLT_RST# CR1_LEDN AR319 AR319 10K_04 10K_04 AR72 AR72 0_06 0_06 3.3V_IN ACARDER_PCIECLKRQ1# AR318 AR318 AU13 AU13 *10K_04 *10K_04 100ohm +/- 15% AGND AR320 AR320 0_04 0_04 ASD_D2 APCIE_TXP2_CARD HSIP AR314 AR314 0_04 0_04...

  • Page 83: Usb

    Schematic Diagrams SLG55583 USB Charging PORT AVDD5 AVDD5 AUSBVCC_CHARGER FLG# VOUT1 AUSB_PW R_EN# 100K_04 100K_04 100 MIL VIN1 VOUT2 AVDD5 VIN2 VOUT3 AUSB_DD_ON# 1M_04 1M_04 AC25 AC25 SY6288DCAC SY6288DCAC Stuff for M-MSOP8 M-MSOP8 AGND 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10K_04 10K_04 APRE#_R AC20 AC20 SLG55583VTR AQ1B...

  • Page 84: Usb, Audio Board

    Schematic Diagrams USB, Audio Board Resistor 68_04 AJ_MIC1 AJ_MIC1 meet WLK Test AJ_HP1 AJ_HP1 AMIC_SENSE MIC1_OUT_R AHP_SENSE AMIC1_R_M AR10 AR10 68_04 68_04 PHONE_R FCM1005KF-121T03 FCM1005KF-121T03 PHONE_OUT_R FCM1005KF-121T03 FCM1005KF-121T03 AHEADPHONE_R MIC1_OUT_L AMIC1_L_M AR12 AR12 68_04 68_04 PHONE_L FCM1005KF-121T03 FCM1005KF-121T03 PHONE_OUT_L FCM1005KF-121T03 FCM1005KF-121T03 NC_MIC1 AHEADPHONE_L...

  • Page 85: Power Diagram

    Schematic Diagrams Power Diagram VCORE PWR SW B'd 0.293A 5.247A 3.3V 1.05VS V_VCCDDQ M_BTN# 0.188A 0.67A 4.2A 3.3VS 1.05VM LynxPoint 0.253A 0.602A 1.5VS 1.05V_LAN_M 3.3VS VDD3 PM_DRAM_PWRGD VDDQ ALL_SYS_PWRGD DRAMPWROK SM_DRAMPWROK RSMRST# SO-DIMM RSMRST#, H_CPUPWRGD VDDQ_VTT PWR_SW# DPWROK PROCPWRGD PWRGOOD IT8587 PWR_BTN# PCH_PLTRST_CPU...
  • Page 86 Schematic Diagrams B - 44...

  • Page 87: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 88: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
