Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, Power Safety Warning consult your service representative or local power company.
Page 10: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 11: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 12: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 15: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 16 Preface...
Page 17: Table Of Contents
Preface Contents Notice .................I Hot Key Buttons ............1-11 FCC Statement .............II Keyboard - Model A ............1-12 FCC RF Radiation Exposure Statement: ....III Keyboard - Model B ............1-13 Instructions for Care and Operation ......V Function/Hot Key Indicators ........1-14 Power Safety .............VII System Map: Front &...
Page 18 Preface TouchPad and Buttons/Mouse ........2-8 Proper handling of the Battery Pack ......3-13 Audio Features .............2-10 Battery FAQ ..............3-14 Adding a Printer ............2-11 Drivers & Utilities USB Printer ..............2-11 Parallel Printer ............2-11 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-4...
Page 19 Preface BIOS Utilities Set Supervisor Password (Security Menu) ....5-11 Set User Password (Security Menu) ......5-12 Overview ................5-1 Password on boot: (Security Menu) ......5-12 The Power-On Self Test (POST) ........5-2 Boot Menu ..............5-13 Failing the POST ............5-3 Exit Menu ..............5-14 Fatal Errors ..............5-3 Non-Fatal Errors ............5-3 Upgrading The Computer The Setup Program ............5-4...
Page 20 Preface HSPA Modem Interface ..........7-24 ATI Video Driver Controls HSPA Modem Interface Installation ......7-24 ATI Video Driver Installation ........B-1 HSPA Modem Interface ...........7-25 ATI Catalyst® Control Center ........B-2 Adding a Profile ............7-27 Attaching Other Displays ..........B-4 Contacts ..............7-29 Display Modes ..............
Page 21 Preface Power Management ............C-3 The Power Sources ............. D-21 Power ................C-3 AC/DC Adapter ............D-21 Security ................. C-3 Battery................D-21 Operating System ............C-3 Turning On the Computer ........... D-22 Environmental Spec ............C-3 Power Schemes ............D-23 Dimensions & Weight ..........C-3 System Power Options ..........D-25 Optional ................
Page 22 Preface...
Page 23: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 24: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 25: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/Windows XP) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 26: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 27: Operating System Setup
Quick Start Guide Operating System Setup If you are installing new system software, or are re-configuring your computer for a different system, make sure you configure the appropriate OS setting in the BIOS before installing a new operating system (Note: If you have installed the Windows Vista operating system with AHCI mode enabled, DO NOT disable AHCI mode or you will need to reinstall the Windows Vista OS).
Page 28: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.
Page 29: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types. The models differ as indicated in the table below however all other features, modules and specifications are identical (see Appendix Feature Model A Model B Display Type 14.1"...
Page 30: System Map: Lcd Panel Open - Model A
Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 3 LCD Panel Open (Model A) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic transmission devices aboard aircraft is Speakers usually prohibited.
Page 31: System Map: Lcd Panel Open - Model B
Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 4 LCD Panel Open (Model B) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic transmission devices aboard air- Speakers craft is usually prohibited.
Page 32: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful Orange DC Power is Plugged In information about the current status of the computer. Green The Computer is On The Computer is in Sleep Icon Color Description...
Page 33: Hot Key Buttons
Quick Start Guide Hot Key Buttons These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press. Hot Key Function Activate the Default E-Mail Browser Activate the Default Internet Program Toggle *Silent Mode (for power saving) Table 1 - 5 - Hot Key Buttons...
Page 34: Keyboard - Model A
Quick Start Guide Keyboard - Model A The keyboard has a numerical keypad for easy numeric data input, and features func- Other Keyboards tion keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 14 for full function key combination details.
Page 35: Keyboard - Model B
Quick Start Guide Keyboard - Model B The keyboard has a numerical keypad on the right for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 14 for full function key combination details.
Page 36: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Fn Keys Function Fn Keys...
Page 37: System Map: Front & Left Views
Quick Start Guide System Map: Front & Left Views Figure 1 - 7 Front & Left Views LED Indicators DC-In Jack External Monitor Port RJ-45 LAN Jack Vent/Fan Intake/ Outlet 2 * USB 2.0 Ports ExpressCard Slot (see page 7-in-1 Card Reader 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /...
Page 38: System Map: Right & Rear Views
Quick Start Guide System Map: Right & Rear Views Figure 1 - 8 Right & Rear Views S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack USB 2.0 Port Optical Device Drive Bay (for CD/DVD Device) Security Lock Slot CD/DVD Emergency Eject Changing DVD Regional Codes Battery Go to the Control Panel and double-click Device If you need to manually eject a CD/...
Page 39: System Map: Bottom View - Model A
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 9 Bottom View (Model A) Battery Information Battery Bluetooth Module Always completely dis- Cover charge, then fully charge, a new battery before using it. RAM & CPU Bay Completely discharge and Cover charge the battery at least...
Page 40: System Map: Bottom View - Model B
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 10 Bottom View (Model B) Battery Information Battery RAM & CPU Bay Always completely dis- Cover charge, then fully charge, a new battery before using it. Vent/Fan Intake/ Completely discharge and Outlet charge the battery at least...
Page 41: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 42: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “ATI Video Driver Controls” on page B - 1.
Page 43: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device. Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported.
Page 44: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 17) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 45: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...
Page 46: Hard Disk Drive
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page C - 2) with a height of 9.5 mm.
Page 47: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...
Page 48: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 49: Dvd Regional Codes
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 50: 7-In-1 Card Reader
Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 51: Expresscard Slot
Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...
Page 52: Touchpad And Buttons/Mouse
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...
Page 53: Audio Features
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon bring up an audio menu).
Page 54: Adding A Printer
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Page 55: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 56: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Silent Mode AC/DC Adapter Use the key to tog- gle Silent Mode to re- Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ duce fan noise and save DC adapter will damage the computer and its components.
Page 57: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 58: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 59 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). ATI PowerPlay ™...
Page 60: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 61: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Hibernate Mode In power failure occurs the system can restore your work from the hard disk; if a power Windows Vista SP1 failure occurs when work is saved only to memory, then the work will be lost.
Page 62: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 63: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
Page 64: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 65: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 66: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 67: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 68: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 69 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 70 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 71: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 72: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers/Option Drivers (button).
Page 73 Drivers & Utilities Manual Driver Installation Click Browse CD (button) in the Drivers Installer ap- Driver - Windows Vista with Service Pack 1 Page plication and browse to the executable file in the ap- Video Page 4 - 5 propriate driver folder. Audio Page 4 - 5 Windows Update...
Page 74: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 75: New Hardware Found
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc and click Install Drivers (button). lined in the driver install procedure), click Cancel Video to close the window, and follow the installation proce-...
Page 76: Lan
Drivers & Utilities 1. Click 3.Install LAN Driver > Yes. 2. Click Install. Windows Update 3. Click Finish. After installing all the drivers make sure you enable Win- 4. The network settings can now be configured. dows Update in order to get all the latest security up- dates etc.
Page 77: Optional Drivers
Drivers & Utilities Optional Drivers Bluetooth Module Note: The operating system is the default setting for See the pages indicated for the driver installation pro- Bluetooth control in Windows Vista, and does not re- cedures for any modules included in your purchase op- quire a driver.
Page 78 Drivers & Utilities 4 - 8...
Page 79: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 80: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 81: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 82: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...
Page 83: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 84: Main Menu
BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 M ai n Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [05/23/2009] <Tab>, <Shift Tab>, or <Enter> selects field. SATA Port 1 [FUJITSU MHY2120BH-(S] SATA Port 2 [HL-DT-ST DVDRAM GSA-]...
Page 85: Sata Port 1/2 (Main Menu)
BIOS Utilities SATA Port 1/2 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of an HDD/optical de- vice on the computer’s SATA Port 1/2. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 86: Advanced Menu
BIOS Utilities Advanced Menu PhoenixBIOS Setup Utility Main A A dvanced Advanced Security Boot Exit Item Specific Help Advanced Chipset Control Installed O/S: [VISTA] Select the operating SATA Class ID: [AHCI] system installed Legacy USB Support: [Enabled] on your system which Boot-time Diagnostic Screen: [Disabled] you will use most...
Page 87: Installed O/S (Advanced Menu)
BIOS Utilities Installed O/S (Advanced Menu) This setting tells the computer what kind of operating system you’re using. Make sure you choose the correct setting for your O/S in order to prevent system problems. SATA Class ID Note: If you select the Vista O/S then the SATA Mode Selection menu will become If you have installed the available.
Page 88: Reset Configuration Data (Advanced Menu)
BIOS Utilities Reset Configuration Data (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 89: Security Menu
BIOS Utilities Security Menu PhoenixBIOS Setup Utility Security Menu Security Main Advanced S S e e c c u u r r i i t t y y Boot Exit Item Specific Help changes Supervisor Password Is: Clear make here affect the User Password Is: Clear Supervisor Password...
Page 90: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the PhoenixBIOS Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you Password Warning choose to set a Password on Boot (see below). Many menu items in the Phoenix- If you set a boot pass- BIOS Setup Utility cannot be modified in user mode.
Page 91: Boot Menu
BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: IDE CD: HL-DT-ST DVDRAM GSA-T50N-( Keys used to view or IDE 4: FUJITSU MHY2120BH-(S1) configure devices: USB FDC: Up and Down arrows USB KEY:...
Page 92: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to Discard Changes CMOS.
Page 93: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 94: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 95: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Page 96: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see...
Page 97 Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow Lift the hard disk out of the bay Model A Figure 6 - 3 HDD Assembly Removal Model B Upgrading the Hard Disk Drive 6 - 5...
Page 98 Upgrading The Computer Remove the screw(s) and the adhesive cover Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers). Hard Disk Screws & Cover The hard disks and cov- Figure 6 - 4 ers pictured here may appear slightly different...
Page 99: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Model A: Locate the RAM & CPU bay cover and remove screws Fan Cable & Cover Carefully (a fan and cable are attached to the under side of the cover) lift up Make sure you recon- the bay cover.
Page 100 Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device (make sure you replace the bay cover for Model A computers and align the cover correctly - see “Model A Cover Alignment”...
Page 101: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). Turn off the computer, and turn it over and remove the battery.
Page 102 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Fan Cable & Cover Make sure you recon- Model A nect the fan cable before screwing down...
Page 103 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30°...
Page 104 Upgrading The Computer 10. Press the module in and down towards the mainboard until the slot levers click into place to secure the module. 11. Replace the bay cover (see sidebar and below for Model A Computers) and Cover Pins screws (make sure you reconnect the fan cable before screwing down the bay cover).
Page 105: Modules & Options
Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 106: Bluetooth Module
Modules & Options Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows Vista, and therefore does not require a driver. Use Operation Aboard the Fn + F12 key combination (see “Function/Hot Key Indicators”...
Page 107: Bluetooth Configuration In Windows Vista
Modules & Options Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On...
Page 108 Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
Page 109 Modules & Options To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...
Page 110: Wireless Lan Module
Modules & Options Wireless LAN Module If you have included a 802.11b/g/n WLAN module in your purchase option, make Wireless Device sure that the Wireless LAN module is on before installing the driver. Use the Fn + Operation Aboard F11 key combination (see “Function/Hot Key Indicators”...
Page 111: Connecting To A Wireless Network
Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 5 Taskbar Menus Click icon...
Page 112 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
Page 113 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...
Page 114: Windows Mobility Center
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 115: Pc Camera Module
Modules & Options PC Camera Module If you have included a PC Camera module in your purchase option, make sure that Latest PC Camera the PC Camera module is on before installing the driver. Use the Fn + F10 key com- Driver Information bination (see “Function/Hot Key Indicators”...
Page 116: Pc Camera Driver Installation
Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3.
Page 117 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click Sound (Hardware and Sound).
Page 118 Modules & Options Figure 7 - 11 Audio Setup for PC Camera Right-click 7 - 14 PC Camera Module...
Page 119 Modules & Options BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate the process - see Set Capture File below).
Page 120 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 121 Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 122 Modules & Options Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 13 Zoom/Setting Taking Still Pictures Snapshot Folder The BisonCap program allows you to take still pictures. The Snapshot folder’s Run the BisonCap program.
Page 123: 3.75G/Hspa Module
Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 3 for specification details) in your purchase op- 3.75G/HSPA Module Options tion, you will have the appropriate application (HSPA Modem Interface or Mobile Partner) provided for your particular module.
Page 124 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
Page 125 Modules & Options Turn off the computer, and turn it over and remove the battery. Locate the RAM & CPU bay cover and remove screws (the SIMLOCK is located at point ), then carefully (a fan and cable are attached to the under side Power Safety of the cover) lift up the bay cover.
Page 126 Modules & Options Insert the USIM card as you would into your mobile phone. Slide the SIMLOCK towards the hinge in order to release the lock and lift it up. Insert the USIM card as illustrated in (Figure 7 - 15) and close the SIMLOCK.
Page 127 Modules & Options Replace the bay cover (see sidebar) and screws (make sure you reconnect the fan cable before screwing down the bay cover). Cover Pins Note that Model A com- puters have four cover pins and Model B com- puters have five cover Model B Model A...
Page 128: Hspa Modem Interface
Modules & Options HSPA Modem Interface With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem In- Wireless Device terface allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft HSPA Modem Interface Installation...
Page 129: Hspa Modem Interface
Modules & Options HSPA Modem Interface The connection information is stored on the USIM card supplied by the service pro- vider. HSPA Modem Help Power on the 3.75G/HSPA module using the Fn + key combination. To get help on 3.75G/ Access the HSPA Modem Interface from the Start menu (Start >...
Page 130 Modules & Options Click Connect to connect to your service provider. Figure 7 - 19 Connecting to Network The message “Network is connected” will be displayed when the network connection is successful. Figure 7 - 20 Network is Connected You can then access the internet, download e-mail etc. as per any internet connection.
Page 131: Adding A Profile
Modules & Options While you are connected the upper right corner of the HSPA Modem interface will display the upload and download rates, and the taskbar icon will display the connection speed. Figure 7 - 21 Uploading/ Downloading Rates and Speed 10.
Page 132 Modules & Options Click Add (button) and input any Network Settings required by your service provider. Click OK to save the profile. Figure 7 - 23 Network Settings & Profiles You can Edit or Delete profiles from the Profiles tab. To use a profile click to select it, and then click Apply (button) and the settings will be transferred to Connection Manager.
Page 133: Contacts
Modules & Options Contacts Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. Click Contacts (button). Figure 7 - 24 Network Settings & Profiles Click Refresh (button) to download the contacts from the USIM card to the computer.
Page 134: Messages
Modules & Options Messages Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. SMS Service Click Messages (button). In addition to standard in- ternet services you may also send and receive SMS text messages us- ing the HSPA Modem In-...
Page 135: Settings
Modules & Options Click to select a contact from the list and then click Add (button) and the phone number will automatically be added to the recipient field. Type the message information into the message body and click Send (button) to send it, or Save to draft (button) to save the message.
Page 136 Modules & Options Click OK alongside any of the options to configure the settings. The Network can be configured for an Automatic (usually from the USIM card) or Manual connection. The Network Mode can be configured for any appropriate mode required. Figure 7 - 27 Settings - Network/ Network Mode...
Page 137: Mobile Partner
Modules & Options Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
Page 138: Mobile Partner Application
Modules & Options Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 139 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
Page 140 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 31 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 141 Modules & Options 11. The module will still be on, and you will need to press the Fn + key combination to turn it off. 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection.
Page 142 Modules & Options 7 - 38...
Page 143: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 144: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 145: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 146: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 147: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 148 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 149: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 150 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 151 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 152 Troubleshooting Problem Possible Cause - Solution Unwelcome numbers appear when If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on typing. page 1 - 10). Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.
Page 153 Troubleshooting Problem Possible Cause - Solution Wireless LAN/Bluetooth/3.5G The modules are off. Check the LED indicator and/or function key indicator modules cannot be detected. to see if the WLAN/Bluetooth/3.75G/HSPA module is on or off (see “LED Indicators” on page 1 - 10).
Page 154 Troubleshooting Problem Possible Cause - Solution The Hibernate function has disappeared. You have a computer with 4GB of RAM and have installed Windows Vista Serv- ice Pack 1. This is a known issue if your computer has 4GB of RAM and is run- ning Windows Vista Service Pack 1.
Page 155: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
Page 156 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 14 Screen Resolution Error...
Page 157: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 158: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 159 Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1”...
Page 160 Interface (Ports & Jacks) A - 4...
Page 161: Ati Video Driver Controls
Appendix B: ATI Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card ATI Video Driver Installation Options Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - Note that card types, Insert the Device Drivers &...
Page 162: Ati Catalyst® Control Center
ATI Catalyst® Control Center Adjust the video settings from the ATI Catalyst Control Center. ® ATI Taskbar Icon Open the Display Settings (see page 20) control panel. The ATI Catalyst Control Click Advanced Settings (button). Center can be accessed as Click Catalyst(R) Control Center (tab) and then click ATI Catalyst Control above or by double-clicking Center (button) to start the control center...
Page 163 The ATI Catalyst® Control Center provides additional video configuration con- trols and tools which allow quick access to features such as display options, 3D Set- tings, color and Help menus etc. Adjust settings from the options in the Graphics Help Menus Settings Tree View pane.
Page 164: Attaching Other Displays
Attaching Other Displays Configuring an External Display in Windows Vista Display Devices Attach your external display to the external monitor port and turn it on. Besides built-in If a New Display Detected window does not appear in Windows Vista, go to the LCD, you can also use Windows Mobility Center control panel (Mobile PC >...
Page 165 Configuring an External Display using the ATI Catalyst Control Center Alternatively you can use the ATI Catalyst Control Center to configure any at- tached displays. Detect Displays Attach your external display to the external monitor port and turn it on. Click Detect Displays Go to ATI Catalyst Control Center (see “ATI Catalyst®...
Page 166: Display Modes
Display Modes Single Function Keys Only one of your displays is used. You can use the Fn + F7 key combination to tog- Clone Mode gle through the display Clone Mode simply shows an exact copy of the Main display desktop on the other options: display(s).
Page 167: Clone Mode
Clone Mode Clone Mode simply shows an exact copy of the Main display desktop on the other display(s). This mode will drive multiple displays with the same content. Use this Selecting Display Modes feature to display the screen through a projector for a presentation. Right-click tached display...
Page 168: Extended Mode
Extended Mode In Extended Mode each monitor can be configured separately with the Windows desktop stretched between the two monitors (except the taskbar). This configuration Selecting Display Modes is recommended if you are using two monitors of different size, as you may config- ure the best resolution, refresh rates and color quality for each display.
Page 169 Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Display Settings Windows Mobility Center control panel (Mobile PC > Adjust commonly used Extended Desktop mobility settings) and click Connect display.
Page 170 Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port and turn it on. Open Display Settings (see “Video Features” on page 1 - 20) control panel. Display Settings Click the monitor icon (e.g. ), and make sure you have checked “Extend the Extended Desktop desktop onto this monitor”...
Page 171: Theater Mode
Theater Mode Theater Mode enables you to display video playback in full screen on a secondary monitor. Theater Mode can be configured from the Avivo Video > Theater Mode ™ tab in the Graphics Settings Tree View pane. Figure B - 9 Theater Mode Theater Mode B - 11...
Page 172: Powerplay
PowerPlay™ PowerPlay in the Graphics Settings Tree View pane allows you to set your ™ graphics processor settings for higher performance or longer battery life. Figure B - 10 PowerPlay ™ B - 12 PowerPlay™...
Page 173: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 174: Processor
Specifications Processor Video Adapter Keyboard & Pointing Device AMD® Athlon ™ 64 Processor: ATI Radeon ™ X1200 Graphics On Board Full Size WinKey Keyboard TF20 (1.6GHz) High Preference 3D/2D Graphic Built-in TouchPad (integrated scrolling Accelerator key functionality) 65nm (65 Nanometer) Process Technology, 512KB L2 Cache &...
Page 175: Communication
Specifications Communication Power Dimensions & Weight Built-In 10/100Mb Base-TX Ethernet LAN Full Range AC/DC Adapter Model A Computers: 802.11b/g/n Wireless LAN Half Mini-Card AC input 100 - 240V, 50 - 60Hz, 336mm (w) * 250mm (d) * 24.8 - 35.7mm (h) Module with PCIe interface (Option) DC Output 19V, 3.42A OR 18V, 3.5A (65 2.2 kg With 6 Cell Battery &...
Page 176 Specifications C - 4...
Page 177: Windows Xp Information
Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 178: D - 2 Operating System Setup
Operating System Setup If you are installing new system software, or are re-configuring your computer for a different system, make sure you configure the appropriate OS setting in the BIOS before installing a new operating system. 1. Start-up the computer and press <F2> to enter the BIOS. 2.
Page 179: Dvd Regional Codes
DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 180: Windows Xp Start Menu & Control Panel
Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 181: Touchpad And Buttons/Mouse
TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. Once you have installed the TouchPad driver (see “TouchPad”...
Page 182: Function/Hot Key Indicators
Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Fn Keys Function Fn Keys...
Page 183: Audio Features
Audio Features You can configure the audio options on your computer from the Sounds and Audio Devices Windows con- trol panel, or from the Realtek HD Audio Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus). The volume may also be adjusted by means of the Fn + F5/F6 key com- bination.
Page 184: Video Features
Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “ATI Catalyst® Control Center” on page D - 10. To access Display Settings in Windows: To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel).
Page 185: Display Devices & Options
Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device. Video Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported.
Page 186: Ati Catalyst® Control Center
ATI Catalyst® Control Center Adjust the video settings from the ATI Catalyst Control Center. ® ATI Taskbar Icon 1. Open the Display Settings (see page 20) control panel. The ATI Catalyst Control 2. Click Advanced Settings (button). Center can be accessed as 3.
Page 187 The ATI Catalyst® Control Center provides additional video configuration con- trols and tools which allow quick access to features such as display options, 3D Set- tings, color and Help menus etc. Adjust settings from the options in the Graphics Help Menus Settings Tree View pane.
Page 188: Attaching Other Displays
Attaching Other Displays Besides the built-in LCD, you can also use an external VGA monitor (CRT) or ex- Display Devices ternal Flat Panel Display as your display device. A VGA monitor/Flat Panel Dis- play connects to the external monitor port. The following display modes are You can use the Fn + F7 key combination to toggle available.
Page 189 Configuring an External Display (ATI Catalyst Control Center) You can use the ATI Catalyst Control Center to configure any attached displays. Detect Displays Attach your external display to the external monitor port and turn it on. Go to ATI Catalyst Control Center (see page 10).
Page 190: Clone Mode
Clone Mode Clone Mode simply shows an exact copy of the Main display desktop on the other Selecting Display display(s). This mode will drive multiple displays with the same content. Use this Modes feature to display the screen through a projector for a presentation. Right-click tached display...
Page 191: Extended Mode
Extended Mode In Extended Mode each monitor can be configured separately with the Windows desktop stretched between the two monitors (except the taskbar). This configuration Selecting Display Modes is recommended if you are using two monitors of different size, as you may configure the best resolution, refresh rates and color quality for each display.
Page 192: Stretched Mode
Stretched Mode In Stretched Mode the desktop can be though of as equal to the sum of the two indi- vidual monitors, depending on the stretch mode chosen. Therefore if the monitors are Selecting Display Modes stretched horizontally, and both are running at 1024 (H) * 768 (V), then the desktop area can be considered as 2048 (H) * 768 (V).
Page 193 To Enable Extended Desktop (Windows Display Properties) Attach your external display to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes). Double-click Display (icon).
Page 194: Theater Mode
Theater Mode Theater Mode enables you to display video playback in full screen on a secondary monitor. Theater Mode can be configured from the Avivo Video > Theater Mode ™ tab in the Graphics Settings Tree View pane. Figure D - 14 Theater Mode D - 18 Theater Mode...
Page 195: Powerplay
PowerPlay™ PowerPlay in the Graphics Settings Tree View pane allows you to set your graph- ™ ics processor settings for higher performance or longer battery life. Figure D - 15 PowerPlay™ PowerPlay™ D - 19...
Page 196: Power Management Features
Power Management Features To conserve power, especially when using the battery, your computer uses the ACPI OS Note power management system. Power management conserves power by controlling in- dividual components of the computer (the monitor and hard disk drive) or the whole Power management functions...
Page 197: The Power Sources
The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
Page 198: Turning On The Computer
Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and...
Page 199: Power Schemes
Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press a key on the key- the system reads or writes data, the hard disk motor will be turned back on).
Page 200 Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 201: System Power Options
System Power Options You can use the system power options to stop the computer’s operation and restart Stand by/Hibernate where you left off. This system features Stand by and Hibernate sleep mode levels or Shutdown Error (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - see “Hibernate”...
Page 202 Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed. All open applications are retained in memory. When you are not The system can resume using your computer for a certain length of time, which you specify in the operating from Stand by mode by:...
Page 203: Configuring The Power Button
Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- Sleep Button nate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter). If you are in a power saving You may also configure mode set to save power through individual components (e.g.
Page 204: D - 28 Battery Information
Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- on page D - 31 for instructions on how to do this).
Page 205: Recharging The Battery With The Ac/Dc Adapter
Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you need to remove the battery for any reason, “Removing the Battery”...
Page 206: Battery Guidelines
Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 207: Battery Faq
Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the bat- Danger of explosion if tery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...
Page 208: D - 32 Driver Installation
Driver Installation 1. Check the driver installation order from Table D - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu Insert the Device Drivers & Utilities + User’s Manual below.
Page 209: Updating/Reinstalling Individual Drivers
Updating/Reinstalling Individual Drivers WinXP SP2 Driver Page # If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go Video Page D - 34 to the Control Panel in the Windows OS and double- AMD CPU Page D - 34 click the Add/Remove Programs item.
Page 210: Driver Installation Procedure
Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button). Windows XP Service Pack 3 Make sure you install Windows XP Service Pack 3 (or a Video Windows XP version which includes Service Pack 3) be- 1.
Page 211 Audio CardReader 1. Click 3.Install Audio Driver > Yes. 1. Click 6.Install CardReader Driver > Yes. 2. Click Next. 2. Click Install. 3. Click Finish to restart the computer. 3. Click Finish. Hot Key 1. Click 4.Install LAN Driver > Yes. 1.
Page 212: Module Drivers
Module Drivers Wireless LAN, Bluetooth & 3.75G/HSPA Modules See the following pages for the driver installation pro- cedures for any of the optional modules included in your purchase configuration. Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited.
Page 213: Bluetooth Module
Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Bluetooth settings in Windows XP, and therefore does not require a driver. Use the Fn + F12 key combination (see “Function/Hot Key Indi- cators” on page D - 6) to toggle power to the Bluetooth module.
Page 214 Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Wireless Device Operation Aboard 1. Access the Network Connections control panel in Windows (Start > Settings > Aircraft Network Connections OR Start >...
Page 215: Bluetooth Configuration In Windows Xp
Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the Bluetooth icon in the Press the Fn + F12 key combination to power on the Bluetooth module.
Page 216: To Add A Bluetooth Device
To Add a Bluetooth Device 1. Access the Bluetooth Devices control panel. 2. Click Options (tab), and make sure that Allow Bluetooth devices to connect to Passkey Options this computer check box (Connections) has a tick inside it. 3. Click Devices (tab), and then click Add. You can allow the sys- tem to choose a pass- 4.
Page 217 To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: • Change the name of the device (click General, type a new name and click OK). •...
Page 218: Wlan Module
WLAN Module Before installing the optional 802.11b/g USB WLAN module driver use the Fn + Wireless Device F11 key combination to toggle power to the module. Operation Aboard Aircraft 802.11b/g WLAN Driver Installation The use of any portable 1. Make sure the module is powered on, then insert the Device Drivers & Utili- electronic transmission de- ties + User’s Manual disc into the CD/DVD drive.
Page 219 Network Connection Use the Windows Net- work Connections control panel to access available wireless net- works (Start > Settings > Network Connec- tions or Start > Con- nect To > Show all Connections). Figure D - 6 Wireless Network Control Panels WLAN Module D - 43...
Page 220: D - 44 Pc Camera Module
PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key com- Taking Still Pictures bination to toggle power to the module. The PC Camera module uses the BisonCap application to capture video files. Double-click Computer icon on the PC Camera Driver Installation...
Page 221 PC Camera Audio Setup (all camera modules) If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 222 BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space 1. Run the BisonCap application from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
Page 223 Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g.
Page 224 Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the BisonCap program. 2. Go to Options and scroll down to select Video Capture Filter..3.
Page 225 Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Figure D - 8 Zoom/Setting Snapshot Folder Taking Still Pictures The BisonCap program allows you to take still pictures. The Snapshot folder’s default location is on the Run the BisonCap program.
Page 226 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module 3.75G/HSPA Module in your purchase option, you will have the appropriate application (HSPA Modem Options Interface or Mobile Partner) provided for your particular module. Follow the in- structions on page 7 - 21 to install the USIM card (supplied by your service provid-...
Page 227: G/Hspa Module
Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators” on page D - 6) to toggle power to the 3.75G/HSPA module.
Page 228 HSPA Modem Interface Installation With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem Interface allows you to directly access your HSPA internet service from the computer. 1.
Page 229 Mobile Partner Application Installation With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner application allows you to directly access your HSPA in- ternet service from the computer. 1.
Page 230 D - 54...

Clevo W760K User Manual

Quick Start Guide

Features & Components

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

ATI Video Driver Controls

Specifications

Windows XP Information

Quick Links

Need help?

Questions and answers

Related Manuals for Clevo W760K

Summary of Contents for Clevo W760K
