- Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions For 5UPR54XXD Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 Insert downrod into yoke on top of Loosen the 2 set screws in yoke for the Fan Body. Align the hole in the downrod to slip into yoke. Downrod with the hole in the Yoke. Insert the Pin through the Yoke and Downrod until the point appears on Install the Keeper Pin the other side.
- Page 4 Safety cable installation Safety Cable Lag Screw Remote Transmitter Dip swtiches Lag Screw Safety Cable Remote Receiver Dip switches Washer Set dip switches on the Remote T ransmitter and Remote Lock Washer Receiver to the same settings. This must be done so the Install remote receiver into mounting For Canadian installation in both flush and downrod units will communcate properly .
- Page 5 HAND HELD INSTALL Reverse function for this fan is a switch on the top housing of the fan Remove cover by snaping off from top or bot- body. Turn fan off and wait for fan to tom. Remove battery cover. Install 12V battery stop then loosen the set screw of the Place face plate over battery compartment and into wall remote.
-
Page 6: Fan Speed
Remote Control Transmitter Features: LED LIGHT MEDIUM SPEED HIGH SPEED LOW SPEED UPLIGHT ON/OFF SET- TING AND DIMMER (Press and hold to dim FAN OFF SETTING light infinitively) (Turns fan off only) DOWNLIGHT ON/OFF SETTING AND DIMMER (Press and hold to dim light infinitively) FAN SPEED Depress “l dot”... -
Page 7: Troubleshooting
ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check thisTroubleShooting Chart.
