- Page 1 ETL model no. :5VSR60 ’ WNER ANUAL Ceiling Fan Installation Instructions Install with or without the light kit. For 5VSR60XXD Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight...
-
Page 2: Installation
ETL model no. :5VSR60 Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 ETL model no. :5VSR60 C C a a n n a a d d i i a a n n m m o o u u n n t t i i n n g g o o n n l l y y House Safety Cable Lag Screw...
- Page 4 ETL model no. :5VSR60 Connect white wire from fan to white Install the fitter to the light kit plate wire from light fixture. Then plug Loosen 2 screws and remove 1 screw by twisting clockwise, add 1 screw blue wire from fan to black wire from from the light kit plate, save the removed from step 18 and tighten screw for future use.
- Page 5 ETL model no. :5VSR60 NOTE: If you have more than 1 fan with a remote, you will have to change the DIP switch settings located above the battery of the remote. There are no DIP switch- es on the fan. Only change the FAN OFF SETTING remote DIP switches then press (Turns fan off only)
- Page 6 ETL model no. :5VSR60 Setting the dip switch and learning function of the Remote controller Turn the power on of the fan and press " set " within 60 seconds ( press and hold the set button for at least 5 seconds ). If the fan includes a light, the light will flash twice indicating the success of the learning function setting.
-
Page 7: Troubleshooting
ETL model no. :5VSR60 ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
