Summary of Contents for Haier THERMOCOOL TLSA13B
- Page 1 Twin-tub Washing Machine User's manual Model: TLSA13B Please read this manual carefully before using. Retain it for future reference. 0030511358G...
-
Page 2: Table Of Contents
Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing The musts in washing Usage of the detergent Washing sequence Disposal after washing Trouble-Shooting *Answer to question Packing list *Specification... -
Page 3: Names Of The Parts
Names of the parts Wash selector Wash timer Drain selector Control panel Water-filling entrance Spin tub cover Water-filling translation Buzzer Wash tub cover Spin timer Inner cover of the spin Wash tub Overflow filter Spin tub Water level adjusting lever 9.5、7.5kg MAX 9.5、7.5kg MAX Power cord... -
Page 4: Safety Precautions
Safety precautions Customers should protect the cables do not to over-bend, pulled, intertwine or tie up the power cable, and also not to put any heavy stuff on the power cable. Do not put the machine at damp Do not use water hotter than 50 C . place like the bathroom . - Page 5 Safety precautions Do not decompose, repair or alter the Do not stretch hands into the working machine by yourself. machine. It is dangerous even if the rotation is slow. Take special care of the children. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and...
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter Put the underside of the lint filter into overflow filter overflow filter then push the upside into overflow filter lint filter... - Page 7 How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Back Extend the drain hose from the side of spin tub Front Figure 1 Put soft items on the ground. Lean the machine down gently with the front surface facing the ground.
-
Page 8: Preparation Before Washing
Pre parat ion before w ashing Preparation before washing 1.Connect the water inlet hose. 2.Confirm that the washing machine is earthed reliably . Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe. 3.Put down the drain hose . -
Page 9: The Musts In Washing
The musts in washing The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spined in one time. Laundries quantity in one washing cycle shall be lower than the rated capacity. -
Page 10: Washing Sequence
Washing sequence Wash timer Wash selector Spin timer Drain selector (The washing machine running If to set less than 1 min, in order Wash selector can be Do not set drain selctor under below process:1-15Minutes, to ensure long service life,please soft current standard on Drain position during Keeping washing,15-45minutes... - Page 11 Midway spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Push Proper The laundries Proper No gland are slanting (2) Close the inner and outer cover of the spin tub.
- Page 12 Rinsing Rinse with water-filing OVERFIOW 1.Put the laundries into the wash tub. Select suitable current according to the laundries. If you find water flo- wing out here,please twist the water tap to 2.Adjust the water level limit the water filling. Set the water level with water level adjusting lever according to the laundries quantity.
- Page 13 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
-
Page 14: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing. - Page 15 Cleaning the overflow filter 2. Take off the corrugation pipe. Water level Dismantle the upper part of the adjusting lever corrugation pipe inside Corrugation overflow filter ( as indicated in pipe Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water.
-
Page 16: Trouble-Shooting Answer To Question
Trouble-shooting Answer to question When the remained water is frozen Prevent the freezing (be sure to discharge the water completely after using) After complete draining, set the "DRAIN SELECTOR" Below 50 at "OFF" . If it is set at "DRAIN", it will be rather 2~3L difficult for the frozen water to melt. - Page 17 Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
- Page 18 Packing list Quantity Name One piece User's manual Water inlet hose One piece One piece Gland Twin-tub washing machine One set Specification Water level Water quantity about (L) Maximum/100 Medium/79 Minimum/72 Injection pressure(MPa) 0.02~0.2 Rated washing/spinning 13.0/7.0 capacity(kg)
