FRONT LOADING WASHING MACHINE
Suited model:
MANUAL CODE：
Front Load Washer
MODEL：TEL5FL
Service Manual
Features：
●Free selection for cold or hot washing
●Selecting washing temperature according
to the type of fabrics
●
18 washing programs
●
Spin speed 850rpm
●
Capacity—5kg
●
HA Aesthetic design,elegant and beautiful
Haier Group
Contents
Model:TEL5FL
No.20030120001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEL5FL and is the answer not in the manual?

Questions and answers

Related Manuals for Haier TEL5FL

Summary of Contents for Haier TEL5FL

  • Page 1 Front Load Washer Model:TEL5FL MODEL：TEL5FL FRONT LOADING WASHING MACHINE Service Manual Suited model: Features： ●Free selection for cold or hot washing ●Selecting washing temperature according to the type of fabrics ● 18 washing programs ● Spin speed 850rpm ● Capacity—5kg ●...

  • Page 2: Table Of Contents

    Front Load Washer Model:TEL5FL 1、 Content------------------------------------------------------------------------------------------1 2、 Product code illumination and series introduction------------------------------------2 3、 Features ----------------------------------------------------------------------------------------3 4、Specification --------------------------------------------------------------------------------4-5 5、 Safety caution ------------------------------------------------------------------------------6-7 6、Installation ----------------------------------------------------------------------------------8-9 7、 Net dimention --------------------------------------------------------------------------------10 8、 Names of the parts--------------------------------------------------------------------------11 9、 Functions----------------------------------------------------------------------------------12-13 10、Function Schedule------------------------------------------------------------------------14 11、TroubleShooting-----------------------------------------------------------------------15-20 11、 Wiring Circuit -------------------------------------------------------------------------------21 13、...

  • Page 3: 2、 Product Code Illumination And Series Introduction

    Front Load Washer Model:TEL5FL Product code illumination and series introduction model code rule description Model identification： HA 800 T A：Serial code B：Max spin speed C：Temprature adjustive Examples： HA800T It represents HA series appearance，850rpm spin speed,temprature is also adjustive.Outer drum is plastic...

  • Page 4: 3、 Features

    Front Load Washer TEL5FL Features： ● Free selection for cold or hot washing Selecting washing temperature according to the type of fabrics ● 18 washing programs, ● Three types of laundry: cotton, synthetic and wool ● Spin speed 850rpm ● Changeable washing function: cold wash and hot wash,speed button and economic wash ●...

  • Page 5: Specifications

    TEL5FL Front Load Washer Model: Specifications Front loaders washing machines, push button opening door ＴＥＬ５ＦＬ Last update 2002-5-13 Product identification Description of appliance Washing machine Type of appliance (FS = standing, BI = built-in) Supplier own brand Haier Supplier bar code...
  • Page 6 Front Load Washer Model:HA800T Adjustable feet n° Safety systems Auto door lock Motor overheating protection No heating without water Auto water cool-down (before drain 90°C boiled water) Water return protection Acqua Stop kit Child protection Programs n° 1) Strong action /cotton cycles 2) Normal action / synthetics n°...

  • Page 7: 5、 Safety Caution

    Front Load Washer Model:TEL5FL Safety caution：...
  • Page 8 Front Load Washer Model:TEL5FL...

  • Page 9: 6、Installation

    Front Load Washer Model:TEL5FL Installation...
  • Page 10 Front Load Washer Model: TEL5FL...

  • Page 11: 7、 Net Dimention

    Front Load Washer Model:TEL5FL Net dimention height: 850mm / width: 595mm / depth: 575mm...

  • Page 12: 8、 Names Of The Parts

    Front Load Washer Model: TEL5FL Names of the parts...

  • Page 13: 9、 Functions

    Front Load Washer Model: TEL5FL Functions...
  • Page 14 Front Load Washer Model: TEL5FL...

  • Page 15: 10、Function Schedule

    TEL5FL Front Load Washer Model: Function Schedule...

  • Page 16: 11、Troubleshooting

    Front Load Washer Model: TEL5FL Troubleshooting I .The appliance does not work. Possible causes 1.The socket is not the required one or the connection is loose. 2.The door is not properly closed or the switch of micro delay is in poor contact.
  • Page 17 Front Load Washer Model: TEL5FL 2).Check whether the program is properly selected. 3).Connect the power cable to the drainage pump to check whether the operation is normal. If not, make necessary replacement. IV .Unusual noise Possible causes 1.The packing screws should be disassembled.
  • Page 18 Front Load Washer Model: TEL5FL Possible causes 1.Gas leakage at pressure system of water supply. 2.The pressure switch is broken. Troubleshooting 1.Check whether the pipeline of pressure system is blocked or there is gas leakage. The pressure system includes: (1) Gas-collecting valve (2) Rubber pipe (3) Pipe clip2.Blow on the pressure switch and "click, click"...
  • Page 19 Front Load Washer Model: TEL5FL 8).Dispenser 9)Condenser 10) Hose connecting condenser to hose of outer cylinder 2.For leakage resulting from the welding defect of outer cylinder, replace the outer cylinder. 3.Wipe off the foreign object from the cushion of sight window.

  • Page 20: Unpack And Installation

    Front Load Washer Model: TEL5FL Possible causes 1.The motor of program controller loses or the stub is sealing-off. 2.The knob of program controller is stuck. 3.Poor contact of wiring of program controller. 4.Poor contact at inner contacts of program controller (even after the all the plug wires are tightened.) Troubleshooting 1.Reassemble the motor of program controller and make spot welding of the stubs (the operation of...

  • Page 21: Cleaning And Maintenance

    Front Load Washer Model: TEL5FL 1).Connect one end of the filling hose to the faucet and the other to the water electromagnetic valve of the washer. 2).If the pipe of tap water is new or has not been used for a long time, turn on the faucet until the water is clean.

  • Page 22: 11、 Wiring Circuit

    Front Load Washer Model: TEL5FL Wiring circuit...

  • Page 23: 13、 Exploded View

    Front Load Washer Model:TEL5FL Exploded view...
  • Page 24 Front Load Washer Model: TEL5FL...

  • Page 25: 14、List Of Parts

    TEL5FL PART DESCRIPTION 0020202074 DISTRIBUTION HANDLE ENGLISH 00221125302012 DISTRIBUTION BOX 0020200717 THE COVER OF GLASS 00215200024102 THE AXIS OF PORTHOLE HANDLE 0020102723 THE SPRING OF PORTHOLE HANDLE 0020102508 THE HOOK OF PORTHOLE 0020202080 PORTHOLE FRAME MANUAL OP. 0020600093 PORTHOLE INNER FRAME SCREW...
  • Page 26 TEL5FL PART DESCRIPTION 0020300027 RUBBER PIPE 0020300128 RUBBER PIPE 0020300028 RUBBER PIPE 0020300129 RUBBER PIPE 00215240000600 DISTRIBUTE FITTING 00211500001100 DISTRIBUTE FITTING 0020300061 SOFTEN RUBBER PIPE 0020300060 WASH RUBBER PIPE 0020300059 PREWASH RUBBER PIPE 0020800141 GROOVE 00215000022202 GROOVE FASTENING SCREW 0020400174...
  • Page 27 TEL5FL PART DESCRIPTION 0020100071 BRACKET FOR FRONT WEIGHT 0020202025 TUB FRONT FLANGE 0020100245 U-BOLT 0020300071 SEALING RING 00217690020008 FASTENING NUT FOR U-BOLT 00215000008800 FASTENING BOLT FOR U-BOLT 0020801662 DRUM ASSEMBLY 0020102351 SPRING 00214800503000 SPRING SUPPORT 00213500002500 THE BRACKET OF UPPER WEIGHT...
  • Page 28 TEL5FL PART DESCRIPTION 0022150033660401 DRAIN PUMP 00217030310111 DRAIN PIPE FIXING SCREW (BACK) 00221120363014 DRAIN PIPE CLIP (BACK) 0020600050 DRAIN PIPE CLIP PUMP) 0020300148 DRAIN HOSE 0020300393 PORTHOLE GASKET 0020600062 FASTENING FRONT RING 0020300158 INTLET HOSE...
