4. PRODUCT DESCRIPTION

10
Upper spray arm
1
Lower spray arm
2
Filters
3
Rating plate
4
Salt container
5
Air vent
6
Rinse aid dispenser
7
Detergent dispenser
8

5. CONTROL PANEL

On/off button / Reset button
1
11
9
8
7
1
6
5
4
3
Cutlery basket
9
Lower basket
10
Upper basket
11
The graphic is a general overview. For
more details, refer to other chapters or
documents provided with the appliance.
2
5
4
Programme indicators
2
1
2
3
ENGLISH
