zanussi.com\register
EN User Manual | Dishwasher
ZDLN1522

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZDLN1522

Summary of Contents for Zanussi ZDLN1522

  • Page 1 EN User Manual | Dishwasher ZDLN1522...

  • Page 2: Table Of Contents

    VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................5 4. PRODUCT DESCRIPTION................7 5. CONTROL PANEL..................7 6. PROGRAMMES....................8 7.
  • Page 3 • Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •...

  • Page 4: Safety Instructions

    • If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.

  • Page 5: Installation

    complete. Some detergent may remain on • The following spare parts will be available the dishes. for 10 years after the model has been • Do not store items or apply pressure on discontinued: door hinge and seals, other the open door of the appliance. seals, spray arms, drain filters, interior •...
  • Page 6 3.2 Safety caps If the furniture panel is not installed, open the appliance door carefully to avoid the risk of injury. After installation, make sure the plastic covers are locked in position. Damage or removal of the plastic covers on the sides of the door may impact the functionality of the appliance and may cause an injury.

  • Page 7: Product Description

    4. PRODUCT DESCRIPTION Upper spray arm Cutlery basket Lower spray arm Lower basket Filters Upper basket Rating plate Salt container The graphic is a general overview. For Air vent more details, refer to other chapters or documents provided with the appliance. Rinse aid dispenser Detergent dispenser 5.

  • Page 8: Programmes

    Indicators Delay button Programme button 5.1 Indicators Indicator Description Drying phase indicator. It is on when you select a programme with the drying phase. It flash‐ es when the drying phase operates. Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐ gramme operates.

  • Page 9: Settings

    Programme Dishwasher load Degree of soil Programme phases • Prewash This programme offers the most efficient use of water and energy consumption for crockery and cutlery with normal soil. This is the standard programme for test institutes. This programme is used to assess compliance with the Ecodesign Comission Regulation (EU) 2019/2022.
  • Page 10 The saved settings remain valid until you flashes and the indicators change them again. 7.2 The water softener How to set the programme selection mode The water softener removes minerals from the water supply, which would have a The appliance is in programme selection negative effect on the washing results and on mode when the programme indicator the appliance.
  • Page 11 Regeneration process when it occurs at any point at the beginning For the correct water softener operation, the or in the middle of a programme. resin of the softener device needs to be regenerated regularly. This process is automatic and is the part of the normal All the consumption values mentioned in dishwasher operation.
  • Page 12 7.5 AirDry How to deactivate the rinse aid empty notification AirDry improves the drying results with less energy consumption. During the drying Make sure the appliance is in user mode. phase, the door opens automatically and remains ajar. 1. Press the programme button immediately. The indicator starts to flash.

  • Page 13: Before First Use

    4. Press the on/off button to confirm the setting. 8. BEFORE FIRST USE 1. Make sure that the current level of the water softener agrees with the hardness of the water supply. If not, adjust the level of the water softener. 2.

  • Page 14: Daily Use

    8.3 How to fill the rinse aid CAUTION! dispenser Only use rinse aid designed specifically for dishwashers. 1. Press the release button (D) to open the lid (C). 2. Fill the dispenser (A) until the rinse aid reaches the marking ''MAX''. 3.

  • Page 15: Hints And Tips

    9.2 Setting and starting a programme Do not try to close the appliance door within 2 minutes after AirDry Starting a programme automatically opens it as this may cause damage to the appliance. 1. Keep the appliance door ajar. If, afterwards, the door is closed for at 2.
  • Page 16 • Load the dishwasher to its full capacity to that you use tablets with long save water and energy. For best cleaning programmes. results, arrange items in the baskets as • Always use the correct quantity of instructed in the user manual and do not detergent.

  • Page 17: Care And Cleaning

    • Do not wash in the appliance items that • The spray arms are not clogged. can absorb water (sponges, household • There is enough salt and rinse aid (unless cloths). you use multi-tablets). • Put hollow items (cups, glasses and pans) •...
  • Page 18 • Do not use abrasive products, abrasive cleaning pads or solvents. 11.4 Cleaning the filters The filter system is made of 3 parts. 5. Make sure that there are no residues of food or soil in or around the edge of the sump.
  • Page 19 3. To install the spray arm back, press it CAUTION! downwards. An incorrect position of the filters can cause bad washing results and damage to the appliance. 11.5 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes.

  • Page 20: Troubleshooting

    12. TROUBLESHOOTING Refer to the below table for information on WARNING! possible problems. Improper repair of the appliance may With some problems, the dedicated indicator pose a danger to the safety of the user. flashes intermittently to indicate a malfunction Any repairs must be performed by and the alarm code.
  • Page 21 Problem and alarm code Possible cause and solution Malfunction of the wash pump or the drain • Switch the appliance off and on. pump. • The indicator flashes 5 times intermit‐ tently. • Acoustic signal sounds 5 times intermittent‐ The temperature of the water inside the appli‐ •...
  • Page 22 Problem and alarm code Possible cause and solution The appliance trips the circuit-beaker. • The amperage is insufficient to supply simultaneously all the appliances in use. Check the socket amperage and the capacity of the meter or turn off one of the appliances in use.
  • Page 23 Problem Possible cause and solution The dishes are wet. • For the best drying performance activate the function AirDry. • The programme does not have a drying phase or has a drying phase with low temperature. • The rinse aid dispenser is empty. •...

  • Page 24: Technical Information

    13. TECHNICAL INFORMATION Dimensions Width / height / depth (mm) 596 / 818 - 898 / 550 Voltage (V) 220 - 240 Electrical connection Frequency (Hz) Water supply pressure Min. / max. bar (MPa) 0.5 (0.05) / 10 (1) Water supply min.
  • Page 28 156816251-A-072023...
