Altronix LINQ2 network module is designed to interface with eFlow Series, MaximalF Series, and Trove Series
power supply/chargers . It enables power supply status monitoring and control of two (2) eFlow power supply/
chargers over a LAN/WAN or USB connection . LINQ2 provides values on demand for AC fault status, DC cur-
rent and voltage, as well as Battery fault status, and reports conditions via email and Windows Dashboard Alert .
LINQ2 can also be used as a standalone network controlled relay powered from any 12VDC to 24VDC power
supply . Two separate networked relays can be used for variety of applications, such as: reset an access control
system or gate operator, CCTV camera power, trigger camera to start recording, initiate remote test sequence of
security system, or trigger HVAC system .
Agency Listings:
• UL Listings for US Installations:
UL 294*
UL 603
UL 1481
• UL Listings for Canadian Installations:
ULC-S318-96
ULC-S318-05
Input:
• Current consumption 100mA to be subtracted from
the eFlow power supply's output .
• [COM1] & [COM0] ports are currently disabled,
reserved for future use .
Visit www .altronix .com for latest software updates .
Outputs:
• Power output(s) can be locally or remotely controlled .

Features:

• Management interface for up to two (2) eFlow
power supply/chargers .
• Two (2) network controlled Form "C" relays
(contact rated @ 1A/28VDC resistive load) .
• Management interface software included
(USB flash drive) .
• Includes interface cables and mounting bracket .
*Access Control Performance Levels:
Destructive Attack - N/A (sub-assembly); Endurance - IV; Line Security - I; Stand-by Power - I .
1 . Using the mounting bracket mount the LINQ2 network module to the desired location on the enclosure .
Secure the module by tightening the longer screw on the front edge of the mounting bracket (Fig. 2, pg. 5) .
2 . Connect one end of the supplied interface cable(s) to the ports marked [Power Supply 1] and [Power Supply 2]
on LINQ2 (Fig. 1, pg. 4) . When connecting to one power supply use the connector marked [Power Supply 1] .
3 . Connect the other end of the interface cable to the interface port of each eFlow power supply board .
4 . Connect Ethernet cable (CAT5e or higher) to the RJ45 jack on the LINQ2 network module .
For access control, burglary, and fire alarm signalling applications the cable connection has to terminate is
the same room .
5 . Refer to the programming section of this manual to setup the LINQ2 network module for proper operation .
6 . Connect appropriate devices to [NC C NO] relay outputs .
LED Color
1
2
BLUE
3
4
LINQ2
Access Control System Units .
Power Supplies for Use with
Burglar-Alarms Systems .
Power Supplies for Fire
Protective Signaling Systems .
Power Supplies for Burglar
Alarm Systems . Also suitable
for Access Control .
Power Supplies for Electronic
Access Control Systems .

Installing LINQ2 Board:

LED Diagnostics:

State
ON/STEADY
Heartbeat STEADY/Blinking for 1 second
Power Supply 1 ON/OFF
Power Supply 2 ON/OFF

Overview:

Features:
Features (cont'd):
• Three (3) programmable input triggers .
- Control relays and power supplies via external
hardware sources .
• Access control and user managment:
- Restrict read/write
- Restrict users to specific resources
Status Monitoring:
• AC status .
• Output current draw .
• Unit's temperature .
• DC output voltage .
• Low Battery/Battery presence detection .
• Input trigger state change .
• Output (relay and power supply) state change .
• Battery service required .
Programming:
• Battery service date indication .
• Programmable via USB or web browser .
• Automated timed events:
- Control output relays and power supply via
flexible timimng parameter .
Reporting:
• Programmable dashboard notifications .
• E-mail notification selectable by event .
• Event log tracks history (100+ events) .
Environmental:
• Operating temperature: 0°C to 49°C (32°F to 120 .2°F) .
• Storage temperature: -30ºC to 70ºC (-22ºF to 158ºF) .
Status
Power
