Smart 280
Spot-Beam-Wash
This
product
manual
installation
and
carefully
and
keep
User manual
Please read the instructions carefully before use
contains
important
use
of this
projector.
this
manual
in a safe
1
information
about
Please
read
and
follow
place
for
future
the
safe
these
instructio
ns
reference.
Advertisement
Table of Contents
Related Manuals for Brighter Smart 280
Summary of Contents for Brighter Smart 280
- Page 1 Smart 280 Spot-Beam-Wash This product manual contains important information about safe installation of this projector. Please read follow these instructio carefully keep this manual in a safe place future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
ONTENTS 1. Precautions and installation .................... 3 1.1 the statement ......................1 1.2 Maintenance ......................1 1.3 Product Precautions....................1 1.4 Product Introduction ....................1 1.5 Connecting signal Cables ..................2 1.6 Installation of Lamps ....................2 2. Control panel ........................4 2.1 Key Description ...................... -
Page 3: Precautions And Installation
Precautions and Installation Precautions and installation The statement Thank you for choosing our products!When this product leaves the factory, the performance is intact, the package is complete.In order to use this product safely and effectively, please read this instruction manual carefully and completely before using this product.This manual contains important installation and use information, please install and operate according to the requirements of the manual, at the same time, please keep this manual properly for use at any time.Our company does not assume any responsibility for the damage of the lighting or other performance caused by... - Page 4 Rotation gobo wheel: 7 glass gobos + white light, each glass gobos can independently rotate forward and backward Prism: 3 prisms, independent rotation forward and backward Working mode: DMX512 control, Auto mode, master/slave mode RDM Display: LCD Control signal: international standard DMX512.With the RDM function, you can upgrade software online and dial address codes Cooling: Active fan Material: Aluminum, copper, steel, plastic...
-
Page 5: Installation Of Lamps
1.5 Signal line connection Lamps feature standard DMX input and output 3-core or 5-core XLR sockets.Please use shielded twisted-pair signal cable specially for DMX 512;The signal line is generally connected at a distance of 150 meters. When long-distance signal is transmitted, DMX512 signal amplifier must be added. -
Page 6: Control Panel
The control panel FUNCTIONS OF BUTTONS Confirms the displayed value, or activates the displayed function, or enters the successive menu. Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu. Increases the value displayed (with auto-repetitions) or passes to the previous item in a menu. -
Page 7: Set
2.2 Menu Description FIG. 4 Schematic diagram of main menu 2.2.1 setting options instructions Run Mode Slave status: receive DMX signal from controller or master AUTO Sound Master status: auto run, send DMX signal to slave DMX address 1-512 Press "OK" to enter editing mode.At this time, select hundreds and press the "up"... -
Page 8: Information
Gobo adjustment range is -128~+127, +0 means no adjustment. Focus Dimmer Prism 1 cal Prism 2 zero Prism 2 cal Frost Clear 2.2.4 information options instructions Hall state 0000000 0 when magnetic is detected, 1 otherwise Pan wheel step In the positive direction, the step value should increase, in the opposite direction, the step value 0000 should decrease.The same value is normal every time... -
Page 9: Channel Function
Channel function 3.1 The 17 channel Detail Pan fine Tilt Tilt fine Pan tilt speed Dimmer Shutter/ strobe Color plate Fixed gobo Glass gobo Glass Gobo rotation Focusing Zoom Prism Prism rotating Frost Reset 17 DMX Channel Details Channel Function Value Detail 000-255. - Page 10 000-255. From dark to bright Dimmer Brake light off 000-003. Shutter/ Strobe from slow to fast 004-250. Light switch open → (controlled by dimming strobe 251-255. channel) The white light 000-002 White light + color 1 003 -005 Color 1 006- 008 Color 1 plus color 2 009 - 011...
- Page 11 000 - 009 White 010 - 019 Fixed gobo 1 020 - 029 Fixed gobo 2 030 - 039 Fixed gobo 3 040 - 049 Fixed gobo 4 050 - 059 Fixed gobo 6 060 - 069 Fixed gobo 7 070 - 079 Fixed gobo 8 080 - 089...
-
Page 12: Common Faults
000-127. Angle adjustment Glass Gobo 128-191. Reverse from fast to slow rotation 192-255. Forward from slow to fast 000-255. Gobo clarity from far to near Focusing 000-255. Zoom From big to small 000-127. None Prism 128-255. Prism 000-127. Prism Angle adjustment Prism 128-191. - Page 13 When working, the action of X or Y axis of the lamp is abnormal Check one by one according to the previous step; Check whether the transmission belt corresponding to X and Y axis direction in the lamp falls off and breaks;...
