Brighter Pixel Strobe IP
Pixel Mapping Strobe Light
60 Independent elements – RGBW Color Mixing – CRI 85Ra – IP65 Rating
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these instructio ns
carefully and keep this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
1
Advertisement
Table of Contents
Related Manuals for Brighter PIXEL
Summary of Contents for Brighter PIXEL
- Page 1 Brighter Pixel Strobe IP Pixel Mapping Strobe Light 60 Independent elements – RGBW Color Mixing – CRI 85Ra – IP65 Rating This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructio ns carefully and keep this manual in a safe place for future reference.
- Page 2 Brighter Pixel Strobe IP – • P i x e l S t r o b e x 1 Packing content Mount bracket x1 • All Needed Cables x1 •...
- Page 3 Brighter Pixel Strobe IP User manual x1 • WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit.
- Page 4 Brighter Pixel Strobe IP • The lamp (LED) shall be changed if it has become damaged or thermally deformed. • Never look directly at the light beam. Please note that fast changes in lighting, e. g. flashing light, may trigger epileptic seizures in photosensitive persons or persons with epilepsy.
- Page 5 1 - INTRODUCTION 1.1 DESCRIPTION Brighter Pixel Strobe is an exceptionally powerful IP65 graphic strobe, blinder and flood. Available in Full Colour version, and designed to deliver simply staggering light levels, this versatile fixture can pro- vide an unbelievable punch over a huge area.
- Page 7 Brighter Pixel Strobe IP PHYSICAL • Cooling: Forced air with low noise fan • Suspension And Fixing: Hanging bracket for floor positioning with “Quick-Lock” system • Signal Connection: 5p in/out, RJ45 in/out • Power Connection: Seetronic Powerkon True IP65 in/out •...
-
Page 8: Operating Elements And Connections
Brighter Pixel Strobe IP 1.3 OPERATING ELEMENTS AND CONNECTIONS LCD Display IP65 Power-Con IN IP65 Power-Con OUT IP65 RJ45 IN IP65 RJ45 OUT IP65 DMX 3PIN IN IP65 DMX 3PIN OUT KNOB FOR A SIDE KNOW FOR B SIDE Valve... -
Page 9: Installation
Brighter Pixel Strobe IP - 2 - INSTALLATION 2.1 MOUNTING may be set up on a solid and even surface. By means of the fixing facilities of the base plate, the unit can also be mounted upside down to a cross arm. The base plate is shown in fig.3. -
Page 10: Functions And Settings
3.2 BASIC The Brighter Pixel Strobe has a TFT display and 4 button used to access the control panel functions and manage them (fig.4). -
Page 11: Menu Structure
Brighter Pixel Strobe IP 3.3 MENU STRUCTURE SET UP Temperature C° / F° Screen Backlight Always On,10S,20S,30S Flip Display YES/NO ... - Page 12 Brighter Pixel Strobe IP ...
-
Page 13: Dmx Mode
For operation via light control unit with DMX512 protocol, is sufficient connect the controller to Brighter Picel Strobe. To able to operate the Brighter Pixel Strobe with a light controller, adjust the DMX start address for the first a DMX channel. If e. g. address 3 3on the controller is provided for controlling the function of the first DMX channel, adjust the start address 33 on the Pixel Strobe. - Page 14 Brighter Pixel Strobe IP DMX CONTROL Model: Channel Model 12 Channel Function DMX Value Master Dimmer 0-255 Strobing Timing 0-255/15-990ms Strobing Frequency 0-10/No function 11-255/Slow to fast Strobing Model Static 000-010 No effect 011-045 Ramp up 046-080 Ramp down 081-115...
- Page 15 Brighter Pixel Strobe IP Channel Model 28 Channel Function DMX Value Master Dimmer 0-255 Strobing Timing 0-255/15-990ms Strobing Frequency 0-10/No function 11-255/Slow to fast Strobing Model Static 000-010 No effect 011-045 Ramp up 046-080 Ramp down 081-115 Ramp up-down 116-...
- Page 16 Brighter Pixel Strobe IP Channel Model 244 Channel Function DMX Value Master Dimmer 0-255 Strobing Timing 0-255/15-990ms Strobing Frequency 0-10/No function 11-255/Slow to fast Strobing Model Static 000-010 No effect 011-045 Ramp up 046-080 Ramp down 081-115 Ramp up-down 116-150...
- Page 17 Brighter Pixel Strobe IP ETHERNET To enable Artnet mode, proceed as follows: • Press the ENTER button to access the main menu. • Press the UP/DOWN button to scroll the menu, select the Connect icon, then press the ENTER button to enter the next menu Ethernet.
-
Page 19: Lamp Settings
Brighter Pixel Strobe IP Dimmer 1 - Light intensity control is finer at low level and coarse at high levels. Dimmer 2 - Light intensity control is finer at high level and coarse at low levels. Dimmer 3 - Light intensity control is finer at low and high levels, and coarse to medium levels. - Page 20 Brighter Pixel Strobe IP • Press the UP/DOWN button to select the different modes of operation Master, Slave, and then press the ENTER button to confirm your choice. • Press the LEFT button repeatedly to exit the menu and save changes.
-
Page 21: Connection Of The Dmx Line
Brighter Pixel Strobe IP 3.11 CONNECTION OF THE DMX LINE DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped- ance and low capacity. The following diagram shows the connection mode: Pin1 : Massa - Schermo Pin2 : - Negativo... -
Page 22: Maintenance And Cleaning The Unit
Brighter Pixel Strobe IP - 4 - MAINTENANCE 4.1 MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • Switch off the unit, unplug the main cable and wait until the unit has cooled down. -
Page 23: Troubleshooting
4.3 TROUBLESHOOTING Problems Possible causes Checks and remedies No mains supply Check the power supply voltage • • Dimmer fader set to 0 Increase the value of the dimmer channels • • All color faders set to 0 Increase the value of the color channels •...
