BlacklineSafety G7 Getting Started Manual

G7 GETTING STARTED GUIDE

HARDWARE DETAILS

Cartridge (standard,
single-gas or multi-gas)
LCD screen
Up button
OK button
OK
Power button
Microphone
(G7c only)

POWERING ON

Press and hold the power
button for two seconds.
What does the green light mean?
Flashing
A flashing connectivity light indicates that your
G7 is storing data. It is not currently connected to
the network and will send
data when the light is solid.
Solid
A solid connectivity light indicates that G7 is
actively transmitting data and is connected to
the Blackline Safety Network.
©2023 BLACKLINE SAFETY CORP
Rev. 11
Top lights
Operational and low urgency
High urgency notification
LiveResponse
Connectivity light
Speaker
Down button
Latch pull
Latch push button
Charging light

MENU

To use G7's menu:
1. Press OK once to wake up G7' s screen
2. Press OK again to enter the main menu
3. Use the up and down arrow keys to
navigate to the selection you would like
4. Press OK to select a menu item
5. Repeat as necessary
OK button Up and down buttons

CHARGING

1. Insert the micro USB cable into the removable
charging clip
2. Slide the charging clip onto the charging port
at the bottom of your G7
3. A solid red light at the bottom of the device
confirms your G7 is charging

SOS ALERT

What is an SOS alert?
If you are in need of assistance, you can pull down
the red latch to signal for help.
This feature must be enabled by your safety
supervisor. They can contact Blackline Customer Care
for setup assistance.
G7 GETTING STARTED GUIDE
Charging port
Removable charging clip
Micro USB cable
| 1
