- Page 1 G7 DOCK Technical User Manual...
-
Page 2: Table Of Contents
Gas inlet configuration ......................... OPERATING Requirements ............................. How it works ............................... FEATURES Charging G7 ..............................Bump test ..............................Calibration ..............................G7 Dock update ............................Multi Dock Set-up ............................ MOUNTING Wall-mounting ............................G7 DOCK CARE Maintenance............................... TROUBLESHOOTING Setup................................Calibration and bump tests ....................... - Page 3 SAFETY PRECAUTIONS Danger ................................Warning ................................. Legal notices .............................. SUPPORT Learn more ..............................Customer Care ............................
-
Page 4: Connected Gas Calibration And Bump Testing
G7 Dock is Blackline’s solution to gas sensor calibrating, bump testing and charging G7. It supports both G7c and G7x devices with single-gas or quad-gas cartridges. Simply insert G7, and G7 Dock will do the rest. It automatically charges G7 and places it into a test-ready mode to eliminate false alerts. -
Page 5: Blackline Safety Network
Blackline Live keeps track of alert history, gas calibrations and bump tests, and eliminates the need to manually retrieve data logs from the field. All G7 data is communicated in real-time. Blackline Live tailors user access depending on employee roles. This ensures that everyone has access to the right tools to accommodate their role in a comprehensive monitoring program. -
Page 6: What's In The Box
WHAT’S IN THE BOX Your G7 Dock comes with the following components: G7 Dock ƒ Tubing ƒ Quick-connects (four male, one female) ƒ Power components ƒ • USB cable • USB power adapter ƒ Dock filter Multi-lingual sticker sheet ƒ... -
Page 7: Hardware Details
HARDWARE DETAILS Dock lid Gas valves Wall mounting holes Power cable Power light Product label Charge clip Activation Code Release tabs Inlet stickers Gas Out exhaust Gas inlet quick-connects G7 DOCK TECHNICAL USER MANUAL || 7... -
Page 8: Gas Inlet Configuration
How are my inlets configured? When looking at the back of G7 Dock, the Gas Out exhaust is the connector on the far left side of the dock. It is used to transfer calibration gas to a safe exhaust location. - Page 9 50 PPM All four inlets are customizable and a multi-lingual sticker sheet is provided to label customized inlets. To make changes to your inlets, please contact our Customer Care team for over-the-air configuration updates. G7 DOCK TECHNICAL USER MANUAL || 9...
- Page 10 Inlet four is configured as a purge inlet, supplying clean air to remove residual gas from G7 Dock. When using dock in dusty or humid environments, you can attach the optional dock filter subassembly to the purge inlet to ensure dock is being purged with clean air.
- Page 11 How do I connect G7 Dock to a gas cylinder? G7 Dock provides quick-connects that attach to one end of tubing. Join the tubing to the configured inlet at the back of G7 Dock by connecting both quick-connect ends and twisting clockwise until it clicks securely into place.
-
Page 12: Operating
Gas cylinder with specific multi-gas mixture ƒ ƒ 120/240 VAC Power source and power components Blackline requires using the power components provided with your G7 Dock. NOTE: HOW IT WORKS How do I power G7 Dock? Insert the power cable into the port on the bottom of G7 Dock. - Page 13 How do I place my G7 device into G7 Dock? Slide G7 device into dock’s charge clip at an angle - ensure the charge clips of both devices are connected. Keeping the charge clips connected, lie G7 down into dock and push down until it clicks in place.
-
Page 14: Features
Press G7’s OK button to select Bump Test G7 Dock will perform the bump test G7 will let you know if the bump test has passed or failed and when it is ready to be removed from G7 Dock 14 || G7 DOCK TECHNICAL USER MANUAL... -
Page 15: Calibration
Press G7’s arrow buttons to navigate to Calibration on the LCD screen menu Press G7’s OK button to select Calibration G7 dock will perform the calibration G7 will let you know if the calibration has passed or failed and when it is ready to be removed from G7 Dock G7 DOCK UPDATE To make changes to your G7 Dock configuration, please contact our Customer Care team who can assist you with over-the-air configuration updates. -
Page 16: Multi Dock Set-Up
Multiple G7 Docks can be connected to a single gas cylinder by using tubes, check valves and T-connectors. One gas cylinder is able to support five G7 Docks at one time. -
Page 17: Mounting
WALL-MOUNTING How do I mount my G7 Dock on a wall? When mounting G7 Dock to a wall, ensure the location is within reach of a power source and gas cylinder. To mount G7 Dock, remove the mounting guide located on page 21. Place mounting guide on wall to plan where to place the mounting screws. -
Page 18: Troubleshooting
Why is my device unresponsive when I put it into G7 Dock? If your device does not respond when placed into G7 Dock, it may not be properly connected to the dock, or the dock may not be connected to a power supply. Remove your device from G7 Dock and check to see if the green power light is on. -
Page 19: Calibration And Bump Tests
Why are my calibrations and bump tests failing? Calibrations and bump tests can fail if there is not enough gas reaching the sensors. To ensure that gas is flowing from the gas cylinder to G7 Dock, check that: There are no kinks or crimps in the tubing ƒ... -
Page 20: Specifications
Optimized gas delivery Power Supply Blackline requires using the power supply provided with your G7 Dock. Input voltage: 5 VDC @ 1000 mA Power connector: Micro-USB 120/240 VAC power adaptor and USB cable included. 20 || G7 DOCK TECHNICAL USER MANUAL... -
Page 21: Danger
Warranty Your G7 Dock is warranted against defects in materials and workmanship for up to two year from date of purchase. For further details regarding your Blackline warranty, please refer to your Terms and Conditions of Service. Visit http://www.blacklinesafety.com for more information. -
Page 22: Learn More
SUPPORT LEARN MORE Visit support.BlacklineSafety,com to find support and training materials for G7 Dock. CUSTOMER CARE For technical support, please contact our Customer Care team. North America (24 hours) Toll Free: 1-877-869-7212 | support@blacklinesafety.com United Kingdom (8am-5pm GMT) +44 1787 222684 | eusupport@blacklinesafety.com... - Page 23 68 mm 2.677 in 120 mm 4.724 in...
- Page 28 0266/R5/2017-10-20...
