  • Page 1 www.BlacklineSafety.com...
  • Page 2 INTRODUCTION WHO IS BLACKLINE SAFETY? § Headquartered in Calgary, Alberta, Canada § Global connected safety technology leader behind G7 § Our talented team of designers and engineers create and manufacture everything in-house § In-house Safety Monitoring Center and Customer Care §...
  • Page 3 INTRODUCTION Standard Quad WHAT IS G7? Single § Work-everywhere, wearable, personal safety monitor with gas detection § 18 hours battery § 2-way texting § Deliver instant situational awareness § Manage fastest response § Intrinsically Safe...
  • Page 4 Works with G7x to monitor your safety even when out of cell range § Delivers mass notifications § Is capable of connecting to up to five G7x devices with a range of 2km § 50 hours of battery -20 to 55C...

  • Page 5: Service Plans

    INTRODUCTION SERVICE PLANS Self-monitored Blackline Monitored § Your team monitors your Blackline § Blackline Safety’s in-house Live account monitoring personnel monitor your team 24/7, 365 days a year § 99.5% of alerts responded to in under 1 minute...
  • Page 6 HARDWARE DETAILS – G7x...
  • Page 7 HARDWARE DETAILS – G7 BRIDGE Speaker Weatherproof Charging light enclosure SureSafe ™ OK button Power button Up button Down button LCD screen Product label Base Charging port Sealing plug (removable) Side lights Alarm light...
  • Page 8 MOUNTING Top of vehicle Dash On-site ALWAYS MAKE SURE G7 BRIDGE HAS A CLEAR VIEW OF THE SKY, ESPECIALLY WHEN OUTSIDE CELL COVERAGE...
  • Page 9 Press the power button on G7 Bridge to Press the power button once on G7x to turn the turn the device on. device on. Always ensure that G7 Bridge is powered on before G7x.
  • Page 10 BUMP TEST / CALIBRATION Bump Test Calibration G7 will let you know it’s time to bump or calibrate upon start up. What do I do? Press and hold the up and down arrows to silence this reminder. Then, bump or calibrate using one of the methods on the next slide.
  • Page 11 BUMP TEST / CALIBRATION You can bump and calibrate in one of two ways: With G7 Dock: Manually: Place G7 in dock Press OK to access the menu Close the lid Use the up and down arrows to Select bump test/calibration navigate to bump test from the menu Select bump test...
  • Page 12 WEARING Belt Chest DO NOT LEAVE G7 UNATTENDED WHEN POWERED ON, THIS CAN LEAD TO FALSE RED ALERTS...
  • Page 13 YELLOW PENDING ALARM YELLOW PENDING ALARM Fall detection No-motion Check-in timer What do I do? Are you OK? If yes, press the latch to return the device to normal function.
  • Page 14 YELLOW PENDING ALARM What happens if you don’t tell the device you’re OK? YELLOW PENDING ALARM RED ALERT If you don’t confirm you’re OK, the Yellow Pending Alarm escalates into Red Alert and notifies monitoring personnel. What do I do? Press and hold the up and down arrows to mute the device.

  • Page 15: Sos Alert

    SOS ALERT If you need to request help right away, you can trigger a SOS Alert. How do I silence What do I do? the alarm? Pull the latch! Press and hold the up and down arrows. Remember – this does not cancel the alert.
  • Page 16 RED GAS ALERT STEL (TIME HIGH (SHORT TERM WEIGHTED (OVER LIMIT) ALERT EXPOSURE AVERAGE) LIMIT) G7 is informing you of something dangerous in your environment. For real-time customers, certain gas alerts will automatically generate a red alert and notify monitoring personnel. What do I do? Evacuate the area.
  • Page 17 LIVE RESPONSE LIVERESPONSE The LiveResponse light will flash blue when monitoring personnel respond to your Alert using your company’s alert response protocol. When it shines on your device, it means someone will be contacting you to confirm you are OK. What do I do? Nothing! Wait for monitoring personnel...
  • Page 18 YELLOW WARNING ALARM YELLOW WARNING ALARM Low battery New message Network Bump Test • Low warning Calibration Connection alarm for gas Interruption • Sensor error • Under limit What do I do? After you’ve read the screen, press and hold the up and down arrows to silence the device Remember –...

  • Page 19: Sending A Message

    MESSAGING SENDING RECEIVING Sending a message: Receiving a message: Press OK Read your message Press and hold the up and down Select send message Scroll to the message you want arrows for 3 seconds to send, press OK.

  • Page 20: Configuration Modes

    CONFIGURATION MODES ENTERING A MODE Available Modes What is seen on your device is dependent on your configuration profile in Blackline Live • Normal mode G7’s default for everyday operation • Pre entry For checking an atmosphere before entering, with or without pump. •...
  • Page 21 CONFIGURATION MODES EXTENDING A MODE When a mode timeout is reached, G7 will confirm that you’d like to stay in this mode. What do I do? Press the up arrow to extend the mode. Press the down arrow to exit the mode.
  • Page 22 G7 MULTI-PUMP CARTRIDGE Tubing Quick-connect Pump TURNING PUMP ON Attach a multi-gas pump cartridge to G7 Enter a pumped mode, such as pre-entry or leak check Perform a block test, following the steps on G7’s screen. Pump will start automatically NOTE: if the block test fails, the device will not enter the mode and pump won’t start.
  • Page 23 BLOCK TESTS Block tests are performed to ensure your equipment is working properly before using pump to test the gas levels in an environment. Blackline’s G7 multi-pump cartridge has two types of block tests: AUTOMATIC BLOCK TEST MANUAL BLOCK TEST This is the block test that you can perform This is the block test that G7 runs through anytime a pump is running.

  • Page 24: Secondary Menu

    PUMP MENU OPTIONS When a G7 multi-pump cartridge is attached, a new secondary menu and main menu option appear. PUMP OPTIONS MENU Pump options The pump options menu is available from Back G7’s main menu, under settings. Sample time ON Hose length This is where you will set things such as: •...

  • Page 25: Power Off

    Press and hold G7 Bridge’s power button 3 seconds to turn the device off. for 3 seconds to power off. Always ensure that all connected G7x’s have been powered off before G7 Bridge. Before powering down, ensure you When all lights have stopped have a solid SureSafe light.
  • Page 26 CHARGING G7x has an 18 hour battery life Remember to charge after every shift! What do I do? Put the clip into the base of the G7, then plug in the micro USB.
  • Page 27 CHARGING G7 Bridge has a 50 hour battery life Remember to charge after every shift! What do I do? Put the clip into the side of G7 Bridge then plug in the micro USB.
  • Page 28 QUESTIONS?

  • Page 29: Customer Care

    SUPPORT support.BlacklineSafety.com CUSTOMER CARE For technical support, please contact our Customer Care team. International (24 hours) North America (24 hours) +1-403-452-0327 Toll Free: 1-877-869-7212 support@blacklinesafety.com support@blacklinesafety.com...
