BOILER WITH DOMESTIC HOT WATER STORAGE
Vaduri, 25 Zorelelor Street, Alexandru Cel Bun commune, Neamt 617511, Romania
Tel .: +40.233.24.17.46, +40.233.24.19.33, Fax: +40.233.24.19.29
© KÖBER SRL VADURI BRANCH
INSTALLATION, USE MANUAL
NAME OF EQUIPMENT / MACHINE
DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1
TYPE BA120L-V1
TECHNICAL MANUAL
INSTALLATION AND SERVICE
www.motan.ro
Edition: 1
Revision: 3
Date: 02.11.2021
Page:1from24
Advertisement
Table of Contents
Related Manuals for Kober BA120L-V1
Summary of Contents for Kober BA120L-V1
- Page 1 INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 NAME OF EQUIPMENT / MACHINE VADURI BRANCH Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code form F-POV-05-07 Page:1from24 BOILER WITH DOMESTIC HOT WATER STORAGE TYPE BA120L-V1 TECHNICAL MANUAL INSTALLATION AND SERVICE Vaduri, 25 Zorelelor Street, Alexandru Cel Bun commune, Neamt 617511, Romania Tel .: +40.233.24.17.46, +40.233.24.19.33, Fax: +40.233.24.19.29...
- Page 2 KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:2from24 05-07 Dear Customer: Congratulations on your decision to use our product. The MOTAN brand has been on the market since 2002, offering you quality and performance at a reasonable price.
-
Page 3: Table Of Contents
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (DIRECTIVE 2002/96 / EC - WEEE) ....17 HYDRAULIC INSTALLATION SCHEME, COVERED BY WARRANTY ..............18 10.1 BA120L-V1 water tank with mixing valve ......................18 10.2 BA120L-V1 water tank with mixing valve and temperature sensor ..............19 SPARE PARTS ..............................20 HISTORICAL INTERVENTIONS ..........................20 Annexes - High-performance boiler....................... -
Page 4: Generals
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:4from24 05-07 GENERALS 1.1 Applicable standards and directives - SR EN 60335-1 "Safety of household and similar electrical appliances. -
Page 5: Mixing Valve Specification
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:5from24 05-07 Table no. 1 - The main constructive elements COMPONENT NAME ROLE OF COMPONENT CHARACTERISTICS 1. - Page 6 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:6from24 05-07 For example, at 55°C the partial burn will take place in approx. 30 seconds, while at 60 ° C the partial burn occurs in approx.
-
Page 7: Technical Specifications
INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:7from24 05-07 TECHNICAL SPECIFICATIONS Product code: BA120L-V1 Where: BA - appliance type: storage boiler;... -
Page 8: Main Dimensions
INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:8from24 05-07 MAIN DIMENSIONS Fig.2 - Main dimensions © KÖBER SRL VADURI BRANCH... -
Page 9: Installation Instructions
Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:9from24 05-07 INSTALLATION INSTRUCTIONS Installation, commissioning, maintenance and repair will be performed by personnel with competences in this field. -
Page 10: Connecting The Boiler To The Hydraulic Circuit
Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:10from24 05-07 Caution! In order to grant and keep the warranty, the hydraulic installation for cold water supply, to which the boiler is connected, must contain: - water softener filter and impurity filter;... -
Page 11: Setting The Operation Of The Boiler With A Thermal Plant From The Motan Range
Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:11from24 05-07 Setting the operation of the boiler with a thermal plant from the MOTAN range 1) Boiler operation setting with thermostat - see hydraulic diagram chap.10... -
Page 12: Thermostat Controlled Boiler Electrical Connections
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:12from24 05-07 Figure 5. Wiring diagram of the boiler with temperature sensor 5.3.2 Thermostat controlled boiler electrical connections •... -
Page 13: Hydraulic Connection Scheme
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:13from24 05-07 HYDRAULIC CONNECTION SCHEME R1 - cold water inlet to the plant; R2 - cold water inlet to the boiler;... - Page 14 Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:14from24 05-07 Careful! In order to obtain the maximum efficiency at the plant, the flow restrictor and...
-
Page 15: Instructions For Use
INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:15from24 05-07 INSTRUCTIONS FOR USE Control panel Fig.10 - Control panel 1. Adjustable thermostat- has the role of controlling the pump, with which the boiler is equipped, depending on the temperature set on it. -
Page 16: Operating Characteristics
In winter, if the product is not used for a long time, it is recommended to empty the boiler - risk of frost. Caution! Any defect must be checked exclusively by an authorized technician, approved by the company KOBER SRL Vaduri Branch. For warranty interventions, original parts delivered by KOBER SRL Vaduri Branch will be used. Operating characteristics... -
Page 17: Annual Replacement Of The Magnesium Anode
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:17from24 05-07 8.2 Annual replacement of the magnesium anode Caution! During the warranty period, it is mandatory to perform annual maintenance and replacement of the magnesium anode. -
Page 18: Hydraulic Installation Scheme, Covered By Warranty
KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:18from24 05-07 Proper disposal of the product avoids possible consequences for the environment and health. -
Page 19: Ba120L-V1 Water Tank With Mixing Valve And Temperature Sensor
Revision: 3 Date: 02.11.2021 DOMESTIC HOT WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:19from24 05-07 10.2 BA120L-V1 water tank with mixing valve and temperature sensor A. CH outlet One way valve DHW outlet 10. Pressure gauge C. Gas inlet 11. -
Page 20: Spare Parts
INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 HOUSEHOLD WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:20from24 05-07 SPARE PARTS Call the manufacturer's SERVICE center. HISTORICAL INTERVENTIONS Intervention advice... -
Page 21: Annexes - High-Performance Boiler
INSTALLATION, USE MANUAL KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 HOUSEHOLD WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:21from24 05-07 Annexes - High-performance boiler Boiler thermostat operation: The legend: Delta T... - Page 22 KÖBER SRL Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 HOUSEHOLD WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:22from24 05-07 Operation with boiler sensor and boiler pump fed from the central plate: Delta T...
- Page 23 Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 HOUSEHOLD WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:23from24 05-07 Example of operation with thermostat Tset 50 ° C - Tset 40 ° C: Figure 13.7 Tset = 50°C, T cold water = 18°C, flow rate 20 l / min Performance: - P = 42kW, ΔT = 30°C for 10 minutes...
- Page 24 Edition: 1 VADURI BRANCH NAME OF EQUIPMENT / EQUIPMENT Revision: 3 Date: 02.11.2021 HOUSEHOLD WATER STORAGE BOILER, TYPE BA120L-V1 Code formulated F-POV- Page:24from24 05-07 Example of operation with temperature sensor Tset 50 ° C - Tset 40 ° C: Figure 13.9 Tset = 50°C, T cold water = 20°C, flow 20l / min Performance: - P = 38kW, ΔT = 28°C for 20 min...
