11. Installation, Activation, and Wi-Fi Enrollment

For best Wi-Fi enrollment results, follow these steps:
1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app.
2. Open the Kidde app. Create and login to your account. Tap "Add a device." Select "Smoke + Carbon Monoxide
Alarm with Indoor Air Quality Monitor." Follow in-app steps.
3. Scan your unique QR code, shown in STEP 3 of the Quick Start Guide, or on back of your alarm. Setup and
connect alarm to the app. This will include the wiring and installation steps shown in sections 9, 10, and 11.
4. Complete setup by following in-app steps.
noTe: wi-Fi features do not function without AC power.
wI-FI CoMPATIBIlITY:
This model requires a home Wi-Fi router and internet to connect to a mobile device.( Requires 802.11b/g/n (2.4GHz) Wi-Fi )
IMPorTAnT: These alarms are hardwire interconnected, but do not communicate between alarms using
Wi-Fi. Wi-Fi functionality is only between alarms and a mobile device.
noTe : At any time during Wi-Fi enrollment, if you have a problem, you can push and hold the button on any
problem unit until you hear three (3) beeps (approx 8 sec), and then release the button. The unit will reset the
unit's wireless settings (described in Section 11.3). Once wireless settings are reset, the unit will prompt the
user to follow Quickstart instructions and start over.
NOTE: The IAQ product takes a minimum of 5 minutes to warm up before air quality information is available.
However, the device can take up to 4 days to achieve full accuracy and will undergo a device calibration at
device startup and setup.

11.1 Setting Up Wi-Fi Enrollment

A. Activate the backup battery, apply AC power, install alarm. noTe: wi-Fi features do
not function without AC power.
• Locate the red wheel on the back of the device. Turn the red wheel to the "ON" position
on the device using a standard screwdriver. (Figure 11.1-A)
• Once the battery is activated, the device will emit a power on sound and blink green
once every two minutes.
• Connect the AC Quick Connector Harness. When AC power is connected, the alarm
will announce "Ready to connect, follow quick start instructions".
• When AC power is connected, the light rings will glow fading red.
• Install the alarm fully on the mounting bracket by rotating the alarm in a clockwise direction.
20
Figure 11.1-A
