Kidde P4010ACSAQ-WF User Manual

Kidde P4010ACSAQ-WF User Manual

Smoke alarm with indoor air quality monitor
Hide thumbs Also See for P4010ACSAQ-WF:
Table of Contents

Advertisement

Quick Links

Download this manual
Kidde Smoke Alarm with Indoor
Air Quality Monitor
User Guide
Photoelectric Smoke Alarm
with Voice, Hardwire Interconnect,
Indoor Air Quality Monitoring (IAQ),
and Wi-Fi Compatibility
Model P4010ACSAQ-WF
wi-Fi CoMPATIBIlITY:
This model requires a home Wi-Fi router
and internet to connect to a mobile device.
( Requires 802.11b/g/n (2.4GHz) Wi-Fi )
noTe: wi-Fi features do not function without AC power.
KIdde wi-Fi AlArM
120V HArdwIre
10-YeAr BATTerY BACKUP
(AC Power reQUIred)
HArdwIre InTerConneCT
wi-Fi CoMPATIBle
VoICe AlArM
Indoor AIr QUAlITY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4010ACSAQ-WF and is the answer not in the manual?

Questions and answers

Related Manuals for Kidde P4010ACSAQ-WF

Summary of Contents for Kidde P4010ACSAQ-WF

  • Page 1 Kidde Smoke Alarm with Indoor Air Quality Monitor User Guide Photoelectric Smoke Alarm with Voice, Hardwire Interconnect, Indoor Air Quality Monitoring (IAQ), and Wi-Fi Compatibility Model P4010ACSAQ-WF wi-Fi CoMPATIBIlITY: This model requires a home Wi-Fi router and internet to connect to a mobile device.
  • Page 2 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm with Indoor Air Quality Monitor.”...

  • Page 3: Table Of Contents

    . 10 8. Locations To Avoid . . 13 9. Wiring Instructions and Mounting Bracket Installation . 14 10 Kidde App Instructions . . 18 11. Installation, Activation, and Wi-Fi Enrollment . . 19 11.1 Setting Up Wi-Fi Enrollment .

  • Page 4: Smoke Alarm: What To Do When The Alarm Sounds

    1. Smoke Alarm: What To Do When the Alarm Sounds The smoke alarm pattern is three long beeps with voice “Fire!,” a 1.5 second pause, and three long beeps repeating. The red LED blinks in time with the alarm pattern. •...

  • Page 5: Carbon Monoxide Alarm: What To Do When The Alarm Sounds

    2. Carbon Monoxide Alarm: What To Do When the Alarm Sounds NOTE: This is not a carbon monoxide (CO) alarm, but will receive and transmit a CO alarm signal (with voice message) from an interconnected CO or combination smoke / CO alarm.

  • Page 6: Other Alarm Visual And Audible Indicators

    3. Other Alarm Visual and Audible Indicators Operational Mode Visual Indications Audible Indications Action/Note: Normal (standby) AC power: Green LED on continuously during light conditions, or blink every 60 sec during dark conditions. DC power: Green LED blink approx every 60 sec. Test (button press when no •...

  • Page 7: Troubleshooting Guide

    If you are experiencing a problem with your alarm, or a fault, and are unsure of the next action, please contact product support at 1-877-542-5471 before discharging the battery. You may also write us at: Kidde, 1016 Corporate Park Drive, Mebane, NC 27302, or visit our internet address at www.kidde.com.

  • Page 8: Introduction, Product Features & Specifications

    5. Introduction, Product Features and Specifications Introduction This alarm detects products of combustion using photoelectric technology. The device also monitors the indoor air quality of the residence. Ten (10) years after the unit was activated, this unit will automatically alert you that it is time to replace the unit.

  • Page 9: Limitations Of Smoke Alarms

    6. Limitations of Smoke Alarms wArnInG: PleASe reAd CAreFUllY And THoroUGHlY • Life safety from fire in residential occupancies is based primarily on early notification to occupants of the need to escape, followed by the appropriate egress actions by those occupants. •...

  • Page 10: Recommended Locations For Smoke Alarms

    7. Recommended Locations For Smoke Alarms • Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms are usually farthest from the exit. If more than one sleeping area exists, locate additional alarms in each sleeping area. •...
  • Page 11 Note: measurements shown are to the closest edge NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than 1 ft in 8 ft (0.3m in 2.4 m) of the alarm. horizontally shall be located on the high side of the room.” NFPA 72 states: “A row of detectors shall be ot within 6 feet of appliances spaced and located within 3 ft (0.9m) of the peak of the ceiling measured horizontally.”...
  • Page 12 • For mobile home installation, select locations carefully to avoid thermal barriers that may form at the ceiling. For more details, see MOBILE HOME INSTALLATION section. • When mounting the alarm on the wall, use an inside wall with the top edge of the alarm at a maximum of 12” (30.5 cm) below the ceiling.

  • Page 13: Locations To Avoid

    8. Locations to Avoid (See Figures 7-A, 7-B, & 7-C for recommended locations) • In the garage. Products of combustion are present when you start your automobile. • Normal cooking may cause nuisance alarms. If a kitchen alarm is desired, it should have an alarm silence feature or be a photoelectric type.

  • Page 14: Wiring Instructions And Mounting Bracket Installation

    1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “ Smoke Alarm with Indoor Air Quality Monitor.”...
  • Page 15 • When alarms are hardwire interconnected, all interconnected units must be powered from a single circuit. • A maximum of 24 Kidde Safety devices may be interconnected in a multiple station arrangement. The intercon- nect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, Smoke/ CO Combination, heat, etc.).
  • Page 16 Kidde App, do not connect your Wi-Fi unit to the AC quick connect harness or mounting bracket yet. See Remove Section 10 for instructions on downloading the Kidde App. If you are not using the Wi-Fi function, then proceed with the following Install three steps.
  • Page 17 ONLY transmit smoke and CO alarm signals from these alarms to your mobile device (after the wi-Fi alarm is registered with the Kidde app). Other status notifications from non Wi-Fi alarms, such as low battery, end of unit life, or a fault condition, will NOT be transmitted to your mobile device through the Wi-Fi alarm.
  • Page 18 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm with Indoor Air Quality Monitor.”...

  • Page 19: Installation, Activation, And Wi-Fi Enrollment

    1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke Alarm with Indoor Air Quality Monitor.”...

  • Page 20: Adding Another Device To An Existing Wi-Fi Alarm Network

    B. Open the Kidde App and follow instructions on the App to finish Wi-Fi enrollment. noTe: If no further steps are taken within 15 minutes of initial power up, a voice prompt, “Not Connect- ed” will be heard once, and the Wi-Fi function will turn off. The unit will then perform as a standard hardwired alarm.

  • Page 21: Resetting A Device's Wireless Settings

    11.4 Amazon Alexa and Google Home Your WiFi alarm is compatible with Amazon Alexa and Google Home. Follow instructions in the Kidde app help section to link your WiFi alarm to Amazon Alexa and/or Google Home.* * AMAZON and ALEXA are trademarks of Amazon Technologies, Inc. or its affiliates.

  • Page 22: Operation And Testing

    When conditions in the residence move outside of the limits shown in the table, an alert is sent to your mobile device. You can also check the status of your indoor air quality using the Kidde app, after your alarm is registered with the app.
  • Page 23 Testing IMPorTAnT: Retail canned smoke products vary by manufacturer and produce inconsistent results. If the unit does not alarm when canned smoke is applied conduct a push-to-test to verify proper operation. Over-application of canned smoke can permanently damage the alarm. Test your alarm weekly by pressing and releasing the button quickly.

  • Page 24: Recognizing Nuisance Alarms

    13. Recognizing Nuisance Alarms Smoke nuisance HUSH : If you know why the alarm is sounding, and you can verify that it is not a life threatening situation, you can push the button on the initiating unit (green LED flashing every second) to silence the alarm for 8-10 minutes. If the smoke is not too dense, that unit, and all interconnected units will silence.

  • Page 25: Permanently Disable Alarm / Discharge Battery

    15. Permanently Disable Alarm / Discharge Battery wArnInG: FAIlUre To dISCHArGe AlArM BATTerY AS InSTrUCTed PrIor To dISPoSAl MAY CreATe PoTenTIAl For lITHIUM BATTerY relATed FIre or HAzArd. wArnInG: dISCHArGInG THe AlArM BATTerY IS PerMAnenT. • Once the alarm battery has been discharged, it cannot be reactivated! •...

  • Page 26: Cleaning Your Alarm

    16. Cleaning Your Alarm Your Alarm Should be Cleaned at least once a Year You can clean the interior of your alarm (sensing chamber) by using compressed air or a vacuum cleaner hose and blow- ing or vacuuming through the openings around the perimeter of the alarm. The outside of the alarm can be wiped with a damp cloth.

  • Page 27: Good Safety Habits

    17. Good Safety Habits develop and Practice a Plan of escape Prepare and practice a home escape plan twice a year, including drills at night. Know two ways out of every room (door & window) and identify a meeting place outside the home where everyone will gather once they have exited the resi- dence.
  • Page 28 Smoke detection – Are More Alarms desirable? For your information, the National Fire Protection Association’s Standard 72 reads: Where required The required number of smoke alarms might not by other governing laws, codes, or standards for provide reliable early warning protection for those a specific type of occupancy, approved single and multiple-station smoke alarms shall be installed as areas separated by a door from the areas protected by...
  • Page 29 FCC (Contains FCC Id: 2AC7z-eSPwrooM32Ue) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 30: Service And Warranty

    Kidde warrants that the enclosed alarm will be free from defects in material and workmanship or design under normal use and service for a period of ten years from the date of purchase. The obligation of Kidde under this warranty is...
  • Page 31 QUeSTIonS or For More InForMATIon Call Kidde Product Support line at 1-877-542-5471 or contact us at www.kidde.com Kidde 1016 Corporate Park Drive, Mebane, NC 27302 Kidde’s General Privacy Notice can be found at: https://www.corporate.carrier.com/legal/privacy-notice/ A Carrier Company ©2022 Carrier. All Rights Reserved.
