SLG47105V GreenPAK DIP Adapter
Quick Start Guide
1. Description
The GreenPAK DIP Adapter is a small PCB that lets you adapt
STQFN packages into a DIP footprint. This board can speed
up your design prototyping and testing. This small board
0.90x2.20 inch uses 20 pins DIP footprint with 0.3 inch width.
You can also use this adapter for prototyping by making
STQFN package compatible with solder free breadboards.
2. Features
•
Low cost
•
Simplifies prototyping of SMT IC's
•
Four high voltage high current output GPOs
•
Current up to 1 A per HV GPO
•
Current sensing resistors
Variable current sensing configurations
•
Optional V
•
Decoupling capacitor included
•
Screw terminals for high voltage high and current
lines
•
Optional I
Note 1 All sizes in millimeters (mm).
Revision 1.1
1 of 2
LED indicator
DD
2
C pull-up resistors
© 2022 Renesas Electronics Corporation
18-Mar-2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Renesas SLG47105V
Summary of Contents for Renesas SLG47105V
- Page 1 SLG47105V GreenPAK DIP Adapter Quick Start Guide 1. Description 2. Features • The GreenPAK DIP Adapter is a small PCB that lets you adapt Low cost • Simplifies prototyping of SMT IC’s STQFN packages into a DIP footprint. This board can speed •...
- Page 2 SLG47105V GreenPAK DIP Adapter Quick Start Guide 3. Top View 4. Bottom View LED current limit resistor (optional) VDD LED indicator (optional) Pins Pins Pins Pins Not connected PIN1 (VDD) PIN1 (VDD) Not connected PIN3 (GPI) Not connected PIN3 (GPI)
