Renesas SLG47003V Quick Start Manual

SLG47003V DIP Adapter
This user guide is intended to familiarize new users with the SLG47003V DIP Adapter. It consists of the
description of the board, lists its features, shows top and bottom views, as well as the board schematic.
Contents
1. Description ..................................................................................................................................................... 1
2. Features .......................................................................................................................................................... 1
3. Top View ......................................................................................................................................................... 2
4. Bottom View ................................................................................................................................................... 2
5. Board Schematic ........................................................................................................................................... 3
6. Revision History ............................................................................................................................................ 3
1. Description
The GreenPAK DIP Adapter is a small PCB that lets you adapt STQFN packages into a DIP footprint. This board
can speed up your design prototyping and testing. This small board 0.4 3x 2.00 inch uses 20 pins DIP footprint
with 0.3-inch width. You can also use this adapter for prototyping by making the STQFN-24 package compatible
with solder-free breadboards.
2. Features
■ Low cost
Simplifies prototyping of SMT IC's
■
Optional V LED indicator
■
DD
■ Decoupling capacitor included
2
■ Optional I C pull-up resistors
■ 0R 0805 resistor for disconnecting V
■ Optional 1-pin header for V
R12QS0053EU0100 Rev.1.00
Jun 4, 2024
and V
DD DDA
DDA
Note 1: All sizes in inches
Quick Start Guide
Page 1
