- Page 1 PCA7429G02 PROM Programming Adapter for M37272E8SP/M37272EFSP User's Manual Rev.1.00 September 1, 2003 REJ10J0249-0100Z...
- Page 2 • These materials are intended as a reference to assist our customers in the selection of the Renesas Technology product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corporation, Renesas Solutions Corporation or a third party.
-
Page 3: Table Of Contents
Contents 1. Precautions for Safety ... 4 1.1 Safety Symbols and Meanings ... 4 2. Introduction ... 6 2.1 Things to Check When Unpacking ... 6 3. Specifications ... 7 4. How to Write the Program ... 8 4.1 Programming Procedure ... 8 4.2 Attaching Adapter to PROM Programmer ... -
Page 4: Precautions For Safety
Chapter 1. Precautions for Safety In both the user's manual and on the product itself, several icons are used to insure proper handling of this product and also to prevent injuries to you or other persons, or damage to your properties. This chapter describes the precautions which should be taken in order to use this product safely and properly. -
Page 5: Cautions To Be Taken For This Product
Warnings for Use Environment: • This equipment is to be used in an environment with a maximum ambient temperature of 35˚C. Care should be taken that this temperature is not exceeded. • Select the proper programming mode of the PROM programmer. Cautions to Be Taken for This Product: •... -
Page 6: Introduction
PROM programmer. This manual describes the specifications and operational procedures of PCA7429G02. Figure 2.1 shows the external view of the PCA7429G02 and its constituent parts. Figure 2.1 External view and constituent parts of PCA7429G02 2.1 Things to Check When Unpacking This product consists of following parts. -
Page 7: Specifications
3. Specifications Table 3.1 lists specifications of the PCA7429G02. Table 3.1 Specifications of PCA7429G02 Operating clock frequency Power supply MCU socket Board configuration MCU type M37272E8SP, M37272EFSP 8MHz (Supplied by the ceramic oscillator mounted on the adapter) Supplied from V IC59-4206-G4 (Yamaichi Electronics Co., Ltd.) -
Page 8: How To Write The Program
4. How to Write the Program This chapter describes procedures you need to follow when writing a program. For details on how to operate the PROM programmer, refer to the user's manual included with the PROM programmer. 4.1 Programming Procedure Follow procedures (1) to (8) to write a program. -
Page 9: Attaching Adapter To Prom Programmer
4.2 Attaching Adapter to PROM Programmer As shown in Figure 4.1, attach the adapter's bottom board (PCA7402E) to the IC socket of PROM programmer, with the pin No. 1 of the adapter matched to the pin No. 1 of the IC socket . Be careful when attaching to the PROM programmer because incorrect insertion can cause fatal damage to the MCU. -
Page 10: Setting Jumper Switches
4.3 Setting Jumper Switches Switch settings for SW1 is shown in Table 4.1 and Figure 4.2 below. Table 4.1 Switch settings for SW1 MCU type name M37272E8SP M37272EFSP Figure 4.2 Switch settings for SW1 4.4 Inserting MCU into Adapter As shown in Figure 4.3 insert the MCU into the IC socket, with the pin No. 1 of the MCU matched to the pin No. -
Page 11: Precautions When Handling Adapter
4.5 Precautions When Handling Adapter Don't touch the connector in the IC socket and the pins on the PROM programmer connector. Otherwise it can cause an electrical insulation failure because of dirt. When not using, attach the connector pins of this product to the conductive sponge as it was shipped from the factory. -
Page 12: Memory Map
6. Memory Map Figures 6.1 and 6.2 show the MCU and the PROM programmer memory maps (programming areas). 00000 013FF 01400 03BFF 03C00 07FFF 08000 0FFFF Figure 6.1 Memory map (M37272E8SP) OSD ROM 256 kinds Internal ROM area (32K bytes) (M37272E8SP) ( 12 / 16 ) 00000... -
Page 13: Memory Map
00000 00FFF 01000 Internal ROM area (60K bytes) 0FFFF 10000 113FF 11400 OSD ROM 256 kinds 13BFF 13C00 1FFFF (M37272EFSP) Figure 6.2 Memory map (M37272EFSP) Programming OSD ROM 256 kinds PROM programmer (M5M27C101 mode) ( 13 / 16 ) 00000 00FFF 01000 area... -
Page 14: How To Request For Support
7. How to Request for Support After checking this manual, fill in the following information and email to your local distributor. For prompt response, please specify the following information: (1) Contact address • Company name • Department • Responsible person •... - Page 15 PCA7429G02 User's Manual Rev.1.00 September 1, 2003 REJ10J0249-0100Z COPYRIGHT ©2003 RENESAS TECHNOLOGY CORPORATION AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED...
