- Page 1 INSTALLATION MANUAL FRAME SCREEN LEONARDO FR14 ORIGINAL INSTRUCTIONS IN ITALIAN LANGUAGE Translation into English language This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 2 Warnings Warranty - General information Screen labels FRAME SCREEN DESCRIPTION General description ASSEMBLY Packaging content Structural frame assembly Projection cloth mounting Thin bezel assembly INSTALLATION Wall mounting This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
-
Page 3: General Information
It also contains the information about the technical features and safe use of the product. The installation manual is composed from: General information Frame screen description Assembly Installation This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited... - Page 4 PVC could be damaged and make waves for the explanations given above. The PVC cloth is very sensitive to temperature range. We advise to mount the screen in environments with an ambient temperature in the range of 20°-25°C. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 5 Serial number Motor power Operating frequency Power consumption * Not applicable to frame screens. “A” SERIAL N. MANUFACTURED BY EUROSCREEN SRL-ITALY MADE IN ITALY “B” “C” “D” This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
-
Page 6: General Description
The figures below describe the main elements of the product. Frame front view Velvet covered thin bezel Projection surface Frame rear view Thin bezel Mounting brackets Structural frame This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited... - Page 7 Mod. LEONARDO FR14 Installation manual Profiles combination Thin bezel covered with velvet Thin bezel aluminium profile Structural frame aluminium profile Mounting bracket Projection surface ø6 ø18 This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
-
Page 8: Packaging Content
Metal corners (C) Projection surface (D) Pcs. 01 Pcs. 16 Galvanized rods (E) Rubber bands (E) Pcs.04 Protective cloth Screws + wall plugs (G) Pcs. 01 Pcs. 02 This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited... - Page 9 Place the metal corners (C) near the slots n. 1 e n. 3 of one long structural frame segment (A). Step 1b Insert the metal corners (C). This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 10 Mod. LEONARDO FR14 Installation manual Step 2a Put the short structural frame segments (A) close to the metal corners (C). Step 2b Insert the short structural frame segments (A). This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 11 Step 3a Place the remaining metal corners (C) close to the remaining long structural frame segment. Step 3b Insert the metal corners (C) to this frame segment. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 12 Before tightening all the dowels, in order to perfectly close the metal corners to the structural frame segments, check that the measurements L1 and L2 are the same. The maximum tolerance is 2 mm. L1 = L2 This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 13 Inside the structural frame Mistake B External corner OPEN Mistake B Outside the structural frame Check carefully as above and proceed with tightening the dowels on each corner. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 14 Do not move the projection surface once it is layed down. Projection surface Projection side Check that the area where you are laying the projection cloth is perfectly clean. Protective cloth This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 15 Now, lay the pre-assembled structural frame on the projection surface, making sure that the rear side of the frame is facing upwards. Correct position Wrong position cursors facing upwards cursors facing downwards This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 16 At the end of this procedure, you will notice that the rubber band is softer and its length is increased of about 5 mm. This procedure has the aim to make the screen fixing and eventual regulations easier. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 17 This operation has to be carried out by at least two professional people, taking care that the surface is very delicate and any damage on it will be permanent. Step 1 Step 2 Step 3 Step 4 Step 5 This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 18 Last Last Last Last This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 19 This time is necessary because, after the bezel is mounted on the structural frame, it is not possible to make adjustments on the rubber bands any more. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 20 With a suitable Allen key, loose the dowels turning Correct position counterclockwise. Wrong position This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 21 The figure below indicates how to fix the thin bezel profile to the structural profile. Before fixing thin bezel, make sure that it is PERFECTLY aligned with the structural frame. Now tighten the dowels. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 22 (C) to be fixed. Insert the metal corners without tightening them, making sure that the dowel is loose and but not completely unscrewed. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
- Page 23 Insert the metal corners carefully to the short sides and place the long thin bezel profiles close in order to complete the frame mounting. At this point, screw the dowels tightly. This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
-
Page 24: Installation
Fix the wall plugs with the screws to the wall and hang the screen. Front view Rear view Wall mounting Wall mounting brackets brackets This document is property of Euroscreen Srl. Any reproduction without authorization is prohibited...
