Summary of Contents for Euroscreen Linea TabTension
- Page 1 13 dec 2011, 15:12 Linea TabTension Made in Sweden...
- Page 2 Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation. Vi ® hoppas den kan ge er många timmar av underhållning och/eller utbildning, beroende på...
- Page 3 Limit setting / Gränslägen ENGLISH: Very important! Please read through these instructions completely before you start working on the screen. Although set in the factory we cannot guarantee that the screen limits have not changed during transportation. Even the slightest change in the limits can result in damage to the screen, possibly making it unusable. To avoid the risk of damaging the screen, the following procedure must be carried through.
- Page 4 Assembly / Montering ----- Width: 300cm (”Royal Case”) ----- > EN: The Euroscreen ® Royal case can be mounted in the ceiling or to the wall. Keep the screen horizontal at all times during installation. Sideways spacing isn’t crucial as it can slide, however,...
- Page 5 Assembly / Montering ----- Width: 300cm (”Linea Case”) ----- < EN: The Euroscreen ® Linea case can be mounted in the ceiling or to the wall. The wiring is done for ceiling installation as standard unless otherwise specified. Please see next page if rewiring needs to be done.
- Page 6 ----- Rewiring / Kabelomdragning ----- Make sure no live wiring is connected to the Control Box be- fore you start any work with it! fig 13 Locate the locking spring in each end of the lid (see fig 13). Press it in and lift the lid (see fig 14 and 15). Open control box - press both side locks and lilft the lid (see fig 16).
- Page 7 Wiring & Programming / Koppling & Programmering LED1 1. MOUNTING RECOMMENDATIONS: 1a. Do not install the receiver against or sheltered by a metallic part as this might affect the radio transmission. 1b. Minimum distance above floor: 150cm 1c. Minimum distance below ceiling: 30cm 1d.
- Page 8 Wiring & Programming / Koppling & Programmering LED1 1. REKOMMENDATIONER: 1a. Installera inte mottagaren bakom eller intill metalldelar då det kan störa radiokommunikationen. 1b. Lägsta höjd över golvet: 150cm 1c. Minsta avstånd nedanför taket: 30cm 1d. Minsta avstånd mellan sändare och mottagare: 30cm STOP 1e.
- Page 9 ning Tensioning / Trådspän EN: To keep the surface flat you may need to adjust the tensioning as the surface will change with time and temperature. This is done with the tensioning screw fig 20 marked in fig 20. It is adjustable with 1/6 turn increments. Only adjust it in a single increment at a time! 1.
- Page 10 Conformity of regulations ® Draper Europe AB manufactures AV equipment within the brand Euroscreen . These products are controlled and certified by the below listed regulations. REACH Registration, evaluation, authorisation and limitation of chemicals. Regulation (EC) No 1907/2006 of the European Parliament and of the European Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH).
- Page 11 Efterlevda reglement ® Draper Europe AB tillverkar AV utrustning under namnet Euroscreen . Dessa produkter är kontrollerade och certifierade enligt följande reglement: REACH “Registration, evaluation, authorisation and limitation of chemicals”. Reglement (EC) No 1907/2006 från Europaparlamenet och Europarådet för REACH.
- Page 12 Draper Europe AB Kristinebergsvägen 22 S-302 41 Halmstad Sweden www.drapereurope.se...
