Owner's Instruction and Operation Manual
Model Numbers:
USG730SS
USG890SS
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: FOR OUTDOOR USE ONLY! Please read this entire manual before
installation and use of this pellet fuel-burning appliance. Failure to follow these
instructions could result in property damage, bodily injury or even death. Contact local
building or fire officials about restrictions and installation inspection requirements in
your area. Save these instructions.
A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR
SPACE) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS
PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2021 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
(The Cumberland)
(The Irondale)
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to www.P65warnings.ca.gov
U.S. Patent No. 10,201,247
853636B-0902K
Ph. 800-750-2723

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USG730SS and is the answer not in the manual?

Questions and answers

Related Manuals for USSC USG730SS

Summary of Contents for USSC USG730SS

  • Page 1 Owner’s Instruction and Operation Manual Model Numbers: USG730SS (The Cumberland) USG890SS (The Irondale) U.S. Patent No. 10,201,247 * All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary. 853636B-0902K Save These Instructions In A Safe Place For Future Reference.

  • Page 2: Product Features

    INTRODUCTION Use only wood cooking pellets specified by the It is important to note that the ash content of the fuel and manufacturer. It is important to use only cooking pellets the frequency of operation will determine the frequency that is dry and free from dirt or other impurities. The of required cleaning for this pellet grill.

  • Page 3: Safety Information

    SAFETY INFORMATION • IMPORTANT: READ ALL INSTRUCTIONS BEFORE • Never block free airflow through the open vents of the INSTALLING AND USING THE APPLIANCE. Failure unit. to do so may result in property damage, bodily injury, or • Keep foreign objects out of the hopper. even death.

  • Page 4: Clearance To Combustibles

    This pellet grill must be installed with the clearance to REAR WALL combustibles as shown in this manual. 24” WARNING: DO NOT OPERATE THIS GRILL UNDER A CEILING OR OVERHANG. 12” 12” OVERALL DIMENSIONS USG730SS 45-1/2” 55-3/4” 28-5/16” USG890SS 45-5/8” 28-1/2” 61-11/16” © 2021 United States Stove Company...
  • Page 5 © 2021 United States Stove Company...
  • Page 6 ASSEMBLY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING pedestal panel using the provided washers and bolts. AND USING THE APPLIANCE Screw A Washer H TOOLS & MATERIALS NEEDED FOR Washer E INSTALLATION • #3 phillip screwdriver (use of a drill with a phillips bit will speed up the assembly process) Use proper assembly technique when installing bolts, start all bolts first and then tighten appropriately.
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 2 SIDE TABLE ASSEMBLY & INITIAL FIRING IMPORTANT: Attaching the Side Table DO NOT REMOVE THE SEARING STATION. THE • Attach the side table to the main grill body using the SEARING STATION IS NOT SHOWN IN THE IMAGES BELOW FOR CLARITY PURPOSES ONLY.
  • Page 8 ASSEMBLY INSTRUCTIONS 3. Drip Pan • Place the disposable pan into the drip pan holder and slide into place. • NOTE: Make sure that the pan is aligned with the drip hole • Press the power button to turn the unit off. 4.
  • Page 9 ASSEMBLY INSTRUCTIONS • Place the right drip pan. Make sure the drip pan slides STEP 4 PREPARING THE GRILL FOR USE into the grease drain. Seasoning The Grill IMPORTANT: THE GRILL MUST BE SEASONED BEFORE COOKING ANY FOOD ON IT FOR THE FIRST TIME.
  • Page 10 TEMP the auger PRIME SETPOINT SMOKE USSC GRILLS • USSCGRILLS.COM Make sure the grill is always sitting level. determine when the grill has preheated to the desired cooking temperature. STANDARD STARTUP SEQUENCE NOTE: During the startup, the grill temperature can Fill the hopper with pellet fuel.

  • Page 11: Operating Tips

    OPERATING TIPS screen. SEARING STATION • The searing station control is operable from the toggle • When the grill is turned on, there will be three flashing switch only (found next to the display board). Only turn lights found between the numbers of the display. The on the searing station for the needed time of use.
  • Page 12 OPERATING TIPS Note: These are suggested approximations only and intended as guidelines only. For best results please follow appropriate recipe. Meat Cooking Approximate Suggested Cook Time Type Temp. Beef Hamburgers 425°F 10 min on each side Beef T-Bone/Ribeye 450°F 10 to 20 min (depending on degree of doneness desired) turning once Beef Tenderloin 400°F...

  • Page 13: Maintenance

    MAINTENANCE 3. Replace the flame plate, drip pan, and grilling surface. WARNING: DISCONNECT POWER CORD BEFORE INSPECT HOPPER FOR FINES PERFORMING MAINTENANCE! NOTE: Note: Allow the unit to cool to ambient temperature TURNING THE “ON/OFF” SWITCH TO “OFF” before inspecting or cleaning the grill. DOES NOT DISCONNECT ALL POWER TO THE Periodically check the hopper for pellet dust (fines) build- ELECTRICAL COMPONENTS OF THE GRILL.

  • Page 14: Troubleshooting

    MAINTENANCE Open the service panel by removing the six screws. 2. Inspect the fan for dust or ash build-up and clean if necessary. 3. Close the service panel and reinsert screws. TROUBLESHOOTING ERROR CODES Possible Causes Possible Remedies (Unplug grill first when possible) Error Code 1 - Power Failure - The power failed while the grill was operating and Call Customer service (800) 750-2723 if the error doesn’t go away by...
  • Page 15 TROUBLESHOOTING GRILL ENTERS SHUTDOWN MODE UNEXPECTEDLY Possible Causes Possible Remedies (Unplug grill first when possible) The convection blower is overheating and Clean any dust off of the windings and fan blades. If oiling the blower does tripping the internal temperature shutoff not help, the blower may be bad.

  • Page 16: How To Order Repair Parts

    TROUBLESHOOTING GRILL WILL NOT FEED PELLETS Possible Causes Possible Remedies (Unplug grill first when possible) Wait for the grill to cool for about 30 - 45 minutes. Check the thermocouple Thermocouple is defective to see if it’s bad. Check resistance with volt meter. Remove the six retaining screws in the service panel.

  • Page 17: Replacement Parts

    REPLACEMENT PARTS © 2021 United States Stove Company...
  • Page 18 REPLACEMENT PARTS Key Description Model # Part # USG730SS 893119 Grilling Grate USG890SS 893120 Searing Station 80825 USG730SS 893191 Drip Pan Assembly USG890SS 893192 Temperature Probe 80826 Flame Plate 893193 Side Table Plate 893560 Grill Basket 893561 Drip Pan Holder...

  • Page 19: Wiring Diagram

    WIRING DIAGRAM WHITE WHITE IGNITOR FUSE YELLOW AUGER MOTOR PURPLE INDUCTION TEMPERATURE PROBE POWERED CONTROL BOARD SWITCH POWER SUPPLY BLACK 115 VOLTS AC WHITE BLACK BLACK SEARING STATION 853641 © 2021 United States Stove Company...
  • Page 20 NOTES © 2021 United States Stove Company...
  • Page 21 NOTES © 2021 United States Stove Company...
