A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACE) TO COMBUSTIBLE
MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH
THESE INSTRUCTIONS.
Please read this entire manual before installation and use of this pellet fuel-burning appliance.
Failure to follow these instructions could result in property damage, bodily injury or even death.
Contact local building or fire officials about restrictions and inspection requirements in your area.
ASSEMBLY AND OPERATING
The Hooch
USG350
READ AND SAVE THESE INSTRUCTIONS
NOT FOR USE IN LIVING AREAS
FOR OUTDOOR USE ONLY!
Ce produit peut vous exposer à des produits chimiques, y compris le
CALIFORNIA PROPOSITION 65 WARNING:
monoxyde de carbone, qui est connu dans l'État de Californie pour causer
This product can expose you to chemicals including carbon monoxide, which
le cancer, des malformations congénitales et / ou d'autres problèmes de
is known to the State of California to cause cancer, birth defects and/or other
reproduction. Pour plus d'informations, visitez www.P65warnings.ca.gov
reproductive harm. For more information, go to www.P65warnings.ca.gov
Manufactured for:
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380
(423)750-2723
INSTRUCTIONS
The Cumberland
USG730
The Irondale
USG890
853351C-1403i
Advertisement
Table of Contents
Related Manuals for USSC Irondale USG890
Summary of Contents for USSC Irondale USG890
- Page 1 ASSEMBLY AND OPERATING INSTRUCTIONS The Irondale USG890 The Cumberland USG730 The Hooch USG350 A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACE) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
- Page 2 ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THESE INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL, LABEL, ETC. CONTACT USSC GRILLS at (423)750-2723. WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER, OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THE INSTRUCTIONS.
-
Page 3: Safety Information
• DO NOT PLACE CLOTHING OR OTHER COMBUSTIBLE POWER SOURCE. MATERIALS ON OR NEAR THIS GRILL. • DO NOT USE ACCESSORIES NOT SPECIFIED FOR USE WITH THIS GRILL BY USSC GRILLS. WARNING: WARNING: Do Not Tamper With The Heater. Have A •... - Page 4 Introduction The entire family of United States Stove Company would like to thank you for purchasing your new pellet burning grill. At U.S. Stove, we build all of our products with a hands-on approach to detail and quality. Our old world team of Craftsmen take great pride in their superior workmanship to ensure you have years of trouble free use out of your pellet grill.
- Page 5 WARNING: MINIMUM CLEARANCE TO COMBUSTIBLES Your pellet grill must be installed with clearance to combustibles as shown below. DO NOT OPERATE THIS GRILL UNDER A CEILING OR OVERHANG. FOR USE ON NON-COMBUSTIBLE FLOORING. REAR WALL 24” 12” 12” WARNING: RISK OF CARBON MONOXIDE POISONING •...
-
Page 6: Tools And Materials Needed For Installation
1. Remove the grill from the carton. 2. Remove all packing materials applied for shipping. 3. Remove and hold all parts and hardware. 4. Inspect for damage. Promptly inform USSC Grills at (423)750-2723 of damaged or missing parts. TOOLS AND MATERIALS NEEDED FOR INSTALLATION Parts List You will need one (1) #3 phillip screw driver for assembly and one (1) 5/8”... -
Page 7: Step 3 - Side Table
STEP 2 - GRILL BODY AND PEDESTAL ASSEMBLY THE ASSISTANCE OF A SECOND PERSON IS STRONGLY RECOMMENDED FOR THIS STEP Attach main grill body to the assembled pedestal with six (6) 1/4-20 x 3/4” bolts and six (6) 1/4" flat washers. - Page 8 Parts List 1 Flame Plate 2 Drip Pan 3 Main Grill 4 Searing Station WARNING: Never leave the grill unattended while operating. Disconnect the grill from its power source when not in use.
-
Page 9: Preparing To Use Your Grill
(Searing Station (if equipped) i Initial Firing Procedure 1. Open the pellet hopper lid and remove any objects in the hopper. 2. Plug the grill into a three-prong, grounded power source. 3. Press the power button to "ON". WARNING: DO NOT TOUCH THE AUGER 4. - Page 10 MODE TEMP PRIME SETPOINT SMOKE USSC GRILLS • USSCGRILLS.COM Adjust cook temperature Change temperature display Always make certain that the grill is setting level or is slightly tilted towards the drip bucket. STANDARD STARTUP SEQUENCE 1. Fill the hopper with pellets. Be sure to close and latch the hopper lid. Burn only pellets that are specifically manufactured for use in pellet grills and cookers.
-
Page 11: Shutdown Sequence
SHUTDOWN SEQUENCE 1. When you are ready to turn the grill off, make sure the searing station is off. The light will be off when the searing station is off. 2. Press the “Power” button. 3. The display will go blank and the grill will enter a shutdown mode. During the shutdown mode the blower will continue to run until the grill has reached a safe temperature. -
Page 12: Meat Probe
Note: These are suggested approximations only and intended as guidelines only. For best results please follow appropriate recipe. Meat Suggested Cooking Approximate Suggested Cook Time Type temp. Beef Hamburgers 425° F 10 min. on each side Beef T-Bone/Ribeye 450° F 10 to 20 min (depending on degree of doneness desired) turning once Beef Tenderloin... -
Page 13: Maintenance
Maintenance WARNING: Failure to clean and maintain this unit as indicated may result in poor performance and hazardous situations. The maintenance schedule must be adjusted based on use to insure proper operation and maximum efficiency of your pellet grill. When you are performing any maintenance on your grill, make sure the unit has been turned off. -
Page 14: Disposal Of Ashes
DISPOSAL OF ASHES ASHES SHOULD BE PLACED IN A METAL CONTAINER WITH A TIGHT-FITTIMG LID. THE CLOSED CONTAINER OF ASHES SHOULD BE PLACED ON A NON-COMBUSTIBLE FLOOR OR ON THE GROUND, AT LEAST 25 FEET FROM ANY COMBUSTIBLE MATERIALS, PENDING FINAL DISPOSAL. WHEN THE ASHES ARE DISPOSED BY BURIAL IN SOIL OR OTHERWISE LOCALLY DISPERSED, THE ASHES SHOULD BE RETAINED IN A CLOSED CONTAINER UNTIL ALL CINDERS HAVE THOROUGHLY COOLED. -
Page 15: Troubleshooting
Troubleshooting ERROR CODES Possible Causes Possible Remedies (Unplug grill first when possible) Error Code 1 - Over Temperature - The measured Call Customer service (800) 750-2723. temperature has exceeded the overtemp set point. Visually inspect the ignition system. Try to start the grill again. If Error Code 2 - No Start - The grill did not reach the warm the grill fails to start a second time call customer service (800) condition set point before the timer expired (15 Min.) - Page 16 Troubleshooting POWER FAILURE DURING USE Possible Causes Possible Remedies (Unplug grill first when possible) Observe the grill to make certain unsafe burning conditions do Power goes out during operation. not occur during the outage. Press the power and the prime button at the same time to To restart unit after power outage.
-
Page 17: Parts Diagram
Parts Diagram WARNING: Never leave the grill unattended while operating. Disconnect the grill from its power source when not in use. -15-... -
Page 18: Replacement Parts
Replacement Parts Description Model No. Part No. USG350 893118 Grilling Grate USG730 893119 USG890 893120 USG350 Searing Station USG730, USG890 USG350 893124 Drip Pan Assembly USG730 893125 USG890 893126 Temperature Probe 80826 USG350 29084 Flame Plate USG730, 29085 USG890 4” Bucket 892223 USG350 Switch... - Page 19 Wiring Diagram (With Searing Station) -17-...
- Page 20 Wiring Diagram (Without Searing Station) -18-...
-
Page 21: How To Order Repair Parts
How to Order Repair Parts This manual will help you obtain efficient, dependable service from your grill, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. The full model number is located on the nameplate attached to the grill. When ordering repair parts, always give the following information as shown in this list: 1.
