HBM MGCplus ML85C Operating Manual

Amplifier system, press-fit monitoring module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Manual
Amplifiersystem
MGCplus
Press-fit monitoring
module ML85C
B0541-5.3 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MGCplus ML85C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HBM MGCplus ML85C

Summary of Contents for HBM MGCplus ML85C

  • Page 1 Operating Manual Amplifiersystem MGCplus Press-fit monitoring module ML85C B0541-5.3 en...

  • Page 3: Table Of Contents

    Contents Contents A Introduction Safety instructions ............Notes on the documentation .
  • Page 4 Contents Setting up measurement parameters ........C-20 System of coordinates .
  • Page 5 Contents D Measure LED display on front panel ..........Amplifier plug-in units .
  • Page 6 Contents E Menu structure Measuring mode ............Setup mode .

  • Page 7: A Introduction

    Introduction Ý Safety instructions Introduction ML85C...
  • Page 8 Introduction Ý Safety instructions ML85C...

  • Page 9: Safety Instructions

    1); Protection Class I. To ensure adequate immunity from interference, use only Greenline shielded ducting (see HBM offprint ”Greenline shielding design, EMC-compliant measuring cable; G36.35.0) The insulation resistance of the connecting cables (v50 V) must be a minimum of 350 V (AC).
  • Page 10 Introduction Ý Safety instructions To ensure adequate immunity from interference, use only Greenline shielded ducting (see HBM offprint ”Greenline shielding design, EMC-compliant measuring cable; G36.35.0) Use in accordance with the regulations The press-fit controller and its connected transducers are to be used exclusively for measurement tasks and directly related control tasks.
  • Page 11 Introduction Ý Safety instructions Conditions on site Protect the desktop and plug-in devices from moisture or atmospheric influences such as rain, snow, etc. Make sure that the ventilation slots on the side and the power pack ventilation slots on the back of the device are not covered up.
  • Page 12 Introduction Ý Safety instructions Any risk of residual dangers when working with the press-fit controller is pointed out in this introduction by means of the following symbols: DANGER Symbol: Meaning: Maximum danger level Warns of a decidedly dangerous situation in which failure to comply with safety requirements will lead to death or serious physical injury.
  • Page 13 Introduction Ý Safety instructions Symbols indicating application notes and useful information: NOTE Symbol: Means that important information about the product or its handling is being given. Symbol: Meaning: CE mark The CE mark enables the manufacturer to guarantee that the product complies with the requirements of the relevant EC guidelines (see Declaration of conformity at the end of this Operating Manual).
  • Page 14 In particular, any repair or soldering work on motherboards is prohibited. When exchanging complete modules, use only original parts from HBM. Qualified personnel This instrument is only to be installed and used by qualified personnel strictly in accordance with the Specifications and with the safety rules and regulations which follow.

  • Page 15: Notes On The Documentation

    Introduction Ý Notes to the documentation Notes on the documentation The full documentation for the press-fit controller consists of the following publications: The Operating Manual explains how to operate the device manually and use it for taking measurements. If the system device is equipped with the CP22 or CP42 communications processor, there is also a CD-ROM containing the following documentation: Operation with computer or terminal, contains the commands for programming and measuring with a computer or terminal.
  • Page 16 A-10 Introduction Ý Notes to the documentation This manual holds all the information you need to operate the ML85C. There are still more guidelines available: • The header tells you which chapter or sub-section you are currently reading. Example: Connections Mains connection C-12 Ý...

  • Page 17: What Does A Press-Fit Monitoring Module Do

    Introduction ➝ Mechanical construction A-11 What does a press-fit monitoring module do? The ML85C press-fit monitoring module was specifically developed to monitor press-fit processes, with the aim being to safeguard quality even during the production process. The module monitors two physical quantities (e.g. force and displacement) and their relation to one another. The two measured quantities can also be displayed as the functions of time (force-time or displacement-time diagram).
  • Page 18 Introduction ➝ Mechanical construction A-12 Power pack, communications processor, display and control panel Fig.3.2: Use of one or two AP75 connection boards If the AP75 connection board is located directly behind the ML85C module, the inputs and the outputs are identified in the set-up menus and in the display by A.

  • Page 19: B Connecting

    Connections Connecting ML85C...
  • Page 20 Connections ML85C...

  • Page 21: Inputs And Outputs, Remotes

    Connections Ý I/Os Inputs and outputs, remotes Outputs and AP75 remotes The AP75 connection board makes available control inputs and outputs, LIV outputs and a warning output with 24 V levels for direct connection to the I/Os of programmable controllers. Control inputs and outputs are potential-separated by optical couplers.

  • Page 22: Ap75 Connection Board

    Connections Ý I/Os AP75 connection board The AP75 connection board has eight digital inputs and eight digital outputs. The inputs and the outputs are individually electrically isolated and have separate grounding systems (GND OUT: ground for outputs; GND IN: ground for inputs). The outputs of the connection plate can be programmed with any function.
  • Page 23 Connections Ý I/Os Outputs Terminal Labeling Function GND OUT GND OUT Ground output AP−A: OUT1 BUSY BUSY AP−A: OUT2 NOK message (summation message) AP−A: OUT3 OK message (summation message) AP−A: OUT4 /ALARM Alarm window for force or displacement overshoot or incorrect Outputs measured value (overload, calibration error, other error)
  • Page 24 Connections Ý I/Os ML85C...

  • Page 25: C Commissioning

    Commissioning Commissioning ML85C...
  • Page 26 Commissioning ML85C...

  • Page 27: Instructions In Brief

    Commissioning Ý Instructions in brief Instructions in brief This section describes the major settings which will help the first-time user to start taking successful measurements quickly. Measuring mode Check Diagram Statistics Status 1. Call factory setup Setup mode System Display Amplifier Press fit 1.
  • Page 28 Commissioning Ý Instructions in brief 2. Setting up transducers Check Diagram Statistics Status Example: System Display Amplifier Press fit (data from data sheet or from the identification plate of the transducer) Force transducer: 2 mV/V 2 kN ( 2000 N) Transducer type: SG full bridge Displacement transducer: 80 mV/V...
  • Page 29 Commissioning Ý Instructions in brief 9. Use to switch to the ”Zero point” edit field and in the left−hand Check Diagram Statistics Status edit field, enter the value ”0”. Confirm this choice with System Display Amplifier Press fit 10. Use to select the button in the ”Zero point”...
  • Page 30 Commissioning Ý Instructions in brief Setting up the displacement channel: Check Diagram Statistics Status 1. Put the transducer to the zero position. 2. Press (amplifier). System Display Amplifier Press fit 3. Use to select ”Transducer: Displacement” and confirm with Transducer: Force Transducer: Displacement 4.
  • Page 31 Commissioning Ý Instructions in brief 3. Checking transducer settings 1. Press (Service). Check Diagram Statistics Status 2. Use to select ”Current values” and confirm with 3. Load the transducer with a known force. 4. Simulate a known displacement. Current values Verify the measured values displayed against reference values.
  • Page 32 Commissioning Ý Instructions in brief 4. Setting up the range window Check Diagram Statistics Status The range window defines the area in the force-displacement diagram System Display Amplifier Press fit within which the curve of the press-fit task will be contained. 1.
  • Page 33 Commissioning Ý Instructions in brief Case A Continue with case A or case B depending on the start and end position: Case A: start position < end position Range window Channel3 min. 0.0... max. 2000... The following criteria must be met 0.0...
  • Page 34 C-10 Commissioning Ý Instructions in brief Case A Case B: start position > end position Range window Channel3 In this case the coordinates of the range window and the alarm limits min. 0.0... max. 2000... need to be changed. 50.0... 0.0...
  • Page 35 C-11 Commissioning Ý Instructions in brief The displacement alarm limit must be less than or equal to the right-hand displacement coordinate of the range window (s right). Change alarm limits: System Display Amplifier Press fit 1. Press (amplifier). 2. Use to select ”Alarm limits”...
  • Page 36 C-12 Commissioning Ý Instructions in brief Record first measurement curve of a press-fit process 1. Press (Diagram). 2. Use to select ”Force - displ.” and confirm with 3. Start the measurement using (Start/Stop). Your press-fit task must take place within the next 10 seconds. 4.
  • Page 37 C-13 Commissioning Ý Instructions in brief 6. Analyze curve 1. Press (Cursor) 2. Use the cursor keys to read the measured values. 3. Use to enlarge the curve in the display. Check Diagram Statistics Status 4. Note important points (end position, end force, ...). The further step are described only in principle, since they depend on System Display...
  • Page 38 C-14 Commissioning Ý Instructions in brief 8. Check method and window coordinates After setting the end window and the method the measurement should be ended by the press-fit module automatically. Start measurement recording as in step 5.. In measuring mode (Diagram) and use to select “Force - displ.”, then to start the measurement (the message ”measure”...
  • Page 39 C-15 Commissioning Ý Instructions in brief Setting up alarm limits The alarm limits are designed to protect the transducer and the machine from overload. For setting the limits see page C-27ff. Connect PLC I/Os For wiring diagrams see page C-44. Test automatic mode ML85C...

  • Page 40: Basic Set Up Of The Amplifier

    C-16 Commissioning Ý General notes − Basic set up of the amplifier ML85C press-fit module Check Diagram Statistics Status 1. Use shift key to choose setup mode. 2. If necessary, set up the language preferred for the menus in the System Display Amplifier...

  • Page 41: Setting Up The "Force" And "Displacement" Measuring Amplifiers

    C-17 Commissioning Ý General notes Setting up the “force” and “displacement“ measuring amplifiers Use shift key to choose setup mode. After selecting “force transducer” or “displacement transducer”, the menus for both single-channel measuring amplifiers appear on the Check Diagram Statistics Status left of the press-fit monitoring module.

  • Page 42: Evaluation Methods

    C-18 Commissioning Ý Evaluation channel Evaluation methods The two measured physical quantities are displayed in the x−y diagram. A check is made to establish whether the resultant curve lies within the square window specified by the user. For example, the two measured physical quantities could be: force/displacement torque/angle of rotation force/angle of rotation...

  • Page 43: Tolerance Window Procedure

    C-19 Commissioning Ý Evaluation channel Tolerance window procedure First define a range (i.e. the ”Window”) in the x-y diagram within which, for example the force-displacement trend will be measured. You have the option to define up to 8 tolerance windows for force and displacement tolerance ranges.

  • Page 44: Setting Up Measurement Parameters

    Setting up ➝ Coordinates C-20 Setting up measurement parameters System of coordinates The displacement coordinates in the force-displacement diagramcan be entered in absolute or relative terms. Relative displacement is specified in relation to either a start position (Fig. 4.1) or an end position (Fig. 4.3). Relative window, relative to start position The start position for the relative reference of the displacement coordinates is defined by undershooting the minimum force value for the thread-in window.
  • Page 45 Setting up ➝ Coordinates C-21 Press-fit process 1 The relative system of coordinates is used when the absolute position of the insertion pieces (bearing/shaft) is not always consistent (P Start position In the case of relative displacement coordinates, only the relative movement of the two insertion pieces from the start position is measured, making the process independent of their absolute position.
  • Page 46 Setting up ➝ Coordinates C-22 Example: Check Diagram Statistics Status Press-fitting a bearing onto a shaft. The target position is reached at 40mm from the left-hand chamfer of the shaft. When the target position is reached, the display should show the value zero. System Display Amplifier...
  • Page 47 Setting up ➝ Coordinates C-23 Relative window relative to end position The end position for the relative reference is defined by the last recorded displacement coordinates. F (Force) End window End force Block force Absolute, displacement transducer (mm) Relative displacement coordinates End position Fig.
  • Page 48 Setting up ➝ Coordinates C-24 Example: Check Diagram Statistics Status Press-fitting a bearing into a hole. The end position is 40 mm from the left-hand edge of the hole. When the end position is reached, the display should show the value zero. System Display Amplifier...
  • Page 49 Setting up ➝ Coordinates C-25 Evaluation of curves with force-relative windows Example: locking lever for steering column adjustment Fitting window 2 Relative to F fitting window 2 Fitting window 3 Fitting window 4 Fitting window 2 is defined absolutely. Fitting window 3 is defined relative to F or F of fitting window 2 Fitting window 4 is defined relative to F...

  • Page 50: Setting Up The Coordinate System

    Setting up ➝ Coordinates C-26 4.1.1 Setting up the coordinate system Check Diagram Statistics Status 1. Use the shift key to return to setup mode. 2. Press System Display Amplifier Press fit 3. Use the cursor keys to select ”Coordinates” from the pull-up menu and confirm with Coordinates Range window...

  • Page 51: Alarm Window

    Setting up ➝ Coordinates C-27 Alarm window Alarm window The alarm window is monitored continuously and quite independently of Alarm Alarm limits the progress of any measurement run. If the set limit values (F max, min, ) are exceeded, this triggers a signal at the output from the AP75 right connection board (/ALARM), and the current measurement run is window...

  • Page 52: Range Window

    Setting up ➝ Coordinates C-28 Range window Range window force-displacement Range window Use the range window to define the range of the diagram ; the thread-in window and the fitting window must lie within this range. The range window is a rectangular window with 4 coordinates (F ).

  • Page 53: Thread-In Window

    Setting up ➝ Coordinates C-29 Thread-in window Thread-in window Use the thread-in window to define the range of the force-displacement diagram which is intended to supervise the fitting process for the insertion pieces. The thread-in window is a rectangular Thread-in window with 4 coordinates (F ).
  • Page 54 Setting up ➝ Coordinates C-30 2. Lower left-hand corner of range window and thread-in window do not coincide: The window is pronounced OK if the characteristic curve enters the window from the left and exits the window from the right. Within the window, the trend line may not touch the upper or lower border.
  • Page 55 Setting up ➝ Coordinates C-31 Setting up the thread-in window Check Diagram Statistics Status 1. Use the shift key to return to setup mode. System Display Amplifier Press fit 2. Press 3. Use the cursor keys to select ”Thread-in window” from the pull-up menu and confirm with Coordinates Range window...

  • Page 56: Fitting Window

    Setting up ➝ Coordinates C-32 Fitting window The fitting window supervises the actual press-fit task for insertion pieces. The specified range of values is evaluated after the press-fit task (offline). Fitting window, rectangle Fitting window You may define a maximum of 6 fitting windows, and these may overlap.
  • Page 57 Setting up ➝ Coordinates C-33 Type of window Fitting windows can take the following forms: Fitting window, trapezium 1. Rectangular window with 4 coordinates (F left right left,max right,max 2. Trapezium window with 6 coordinates (F left,min left,max right,min right,min right,max left right...
  • Page 58 Setting up ➝ Coordinates C-34 Check Diagram Statistics Status Enable ”Yes” switches the fitting window on, ”No” switches it off. System Display Amplifier Press fit Setting up the fitting window 1. Use the shift key to return to setup mode. Coordinates Range window 2.

  • Page 59: End Window And Method

    Setting up ➝ Coordinates C-35 End window and method End window F-s diagram Use the end window to define the range for the in which you want the press-fit task to end. The end window is a rectangular window window with 3 coordinates (F block left right...
  • Page 60 Setting up ➝ Coordinates C-36 Method: Standstill recognition Standstill recognition This method is used when it is necessary to ensure that the part which is to be press-fitted will remain under load in the end position for a certain length of time. Standstill is automatically indicated when no window change of displacement is detected within the specified time.
  • Page 61 Setting up ➝ Coordinates C-37 Method: External stop signal External stop signal The end position is detected by an external signal generator (such as a proximity switch). window Evaluation The window is pronounced OK if the end position (E) lies within the end window.
  • Page 62 Setting up ➝ Coordinates C-38 Target pos.+settling time Method: Target pos.+settling time The end position is detected by the displacement channel. Evaluation window The window is pronounced OK if the characteristic curve ends within the window. s-target l s-target right I/Os Input START...
  • Page 63 Setting up ➝ Coordinates C-39 Check Diagram Statistics Status Setting up end window and supervision method 1. Use the shift key to return to setup mode. System Display Amplifier Press fit 2. Press 3. Use the cursor keys to select ”End window + method” from the Coordinates Range window pull-up menu and confirm with...

  • Page 64: Transducer Test

    Setting up ➝ Coordinates C-40 Transducer test This function makes it possible to check preset values on displacement Check Diagram Statistics Status and force transducers (for example zero point). Enter the required values in the ”Transducer test” setup window or measure them directly on the transducer.

  • Page 65: Data Acquisition (Cp42 Only)

    USB HOST approved grounding wristband. YE SLAVE To set the measurement series parameters, use either display RD ERROR ETHERNET and control panel AB22A/AB32, or the PC software HBM GN MASTER MGCplus Assistant. SYNC CTRL I/O GND 1 2 ML85C...
  • Page 66 Setting up ➝ Coordinates C-42 During a data acquisition you save the results of the press fit cycles − Check Diagram Statistics Status these are the extreme values of the thread-in, fitting and end windows. A binary file is created on the hard disk which you can convert to ASCII using the auxiliary program “Presconv.exe”...

  • Page 67: Printing The Press-Fit Results

    Setting up ➝ Coordinates C-43 Printing the press-fit results The ”Print” function lets you print out the settings for the AB22A or for Check Diagram Statistics Status the selected amplifier plug-in unit together with the relevant data. For printing the measurement data, you can specify the required signals under ”Select”;...

  • Page 68: Plc Link

    C-44 Setting up Ý PLC integration PLC link Basic wiring In order to integrate a programmable logic controller, basic wiring must be made up. Expansions are optional; you can also make up several at the same time. The wiring options shown here relate to the pin assignment according to the factory settings of the ML85C. Module A User side PLC input module...
  • Page 69 C-45 Setting up Ý PLC integration 1) Time diagram for external stop signal I/Os Input START Output BUSY Outputs OK Task OK OK−24 V; NOK−0 V Task NOK OK−0 V; NOK−24 V Evaluation time If ALARM=0 switch off motor (EMERGENCY OFF) Output ALARM ALARM Force or displacement too large...
  • Page 70 C-46 Setting up Ý PLC integration 3) Interrupt by PLC I/Os Input START Output BUSY Outputs OK Task OK OK−24 V; NOK−0 V Task NOK OK−0 V; NOK−24 V ML85C...

  • Page 71: Expansion Options For Basic Wiring

    C-47 Setting up Ý PLC integration Expansion options for basic wiring 5.2.1 Online supervision of thread-in process Module A User side PLC input module AP75 Ground outputs GND OUT BUSY OUT1 OUT2 OUT3 ALARM OUT4 OUT5 OUT6 24 V OUT7 OUT8 24 V GND Vo1...
  • Page 72 C-48 Setting up Ý PLC integration Time diagram when thread-in process NOK I/Os Output Thread-in window NOK Output BUSY Measuring interrupted Output ML85C...

  • Page 73: Transducer Test

    C-49 Setting up Ý PLC integration 5.2.2 Transducer test When the CHECK input is enabled, force and displacement signals are compared with the specified tolerance limits (see also page C-40). Module A User side PLC input module AP75 Ground outputs GND OUT BUSY OUT1...
  • Page 74 C-50 Setting up Ý PLC integration Time diagram for transducer check Input CHECK Situation OK Output OK 0 or 1 0 or 1 Transducer test (Minimum time 100 ms) Situation NOK 0 or 1 0 or 1 Output NOK ML85C...

  • Page 75: Autocalibration

    C-51 Setting up Ý PLC integration 5.2.3 Autocalibration You can increase the precision of the measuring system by a factor of 5 or 10 by activating the internal calibration on the device every now and then. Module A User side PLC input module AP75 Ground outputs...
  • Page 76 C-52 Setting up Ý PLC integration Time diagram for calibration I/Os Input Output WARN Calibration running (may last up to 3 seconds de- pending on the filter setting) ML85C...

  • Page 77: Identification Of Wiring Problems

    C-53 Setting up Ý PLC integration 5.2.4 Identification of wiring problems In the output indicates problems in the wiring between transducer and amplifier (a break in the cable or a WARN defective transducer). Module A User side PLC input module AP75 Ground outputs GND OUT...
  • Page 78 C-54 Setting up Ý PLC integration Time diagram for error message Output WARN Problems in wiring between transducer and amplifier Note: The output is similarly set to zero in the event of internal calibration (see also page C-51). WARN ML85C...

  • Page 79: Zero Balance Before The Press-Fit Process

    C-55 Setting up Ý PLC integration 5.2.5 Zero balance before the press-fit process For applications with greater zero point changes, we recommend running a zero balance before each press-fit process. Module B Module A User side PLC input module AP75 AP75 Ground outputs GND OUT...
  • Page 80 C-56 Setting up Ý PLC integration Time diagram for zero balance Inputs Min. 50 ms Input START If the zero balance time is a decisive factor, the AP13 can be used instead of the AP75 (zero balance time depending on amplifier module: about 250 ms with AP75; about 50 ms with AP13). ML85C...

  • Page 81: Trigger Print Task

    C-57 Setting up Ý PLC integration 5.2.6 Trigger print task The print task is triggered by a pulse. Module A User side PLC input module AP75 GND OUT BUSY OUT1 OUT2 OUT3 ALARM OUT4 WARN OUT5 OUT6 24 V OUT7 OUT8 24 V GND Vo1...
  • Page 82 C-58 Setting up Ý PLC integration Time diagram for print enabling Input Min. PRINT 50 ms ML85C...

  • Page 83: Coding Windows With Errors

    C-59 Setting up Ý PLC integration 5.2.7 Coding windows with errors In the event of NOK tasks, outputs No.1 ... No.8 encode the number of the window that triggered the NOK evaluation. Module B Module A User side PLC input module AP75 AP75 Ground outputs...
  • Page 84 C-60 Setting up Ý PLC integration No. 1 No. 2 No. 4 No. 8 Defective window All windows OK Window 1 NOK (thread-in window) Window 2 NOK (fitting window) Window 3 NOK (fitting window) Window 4 NOK (fitting window) Window 5 NOK (fitting window) Window 6 NOK (fitting window) Window 7 NOK (fitting window) Window 8 NOK (end window)

  • Page 85: Selecting Data Sets

    C-61 Setting up Ý PLC integration 5.2.8 Selecting data sets You may predefine up to 8 data sets; remote contacts P1, P2 and P4 select the active data set. Module A User side PLC input module AP75 GND OUT BUSY OUT1 OUT2 OUT3...
  • Page 86 C-62 Setting up Ý PLC integration Active data set Note: Preferably use data sets 2 to 8, since in the case of data set 1 a break in the cable or an incorrect assignment will not be recognized. The data set can only be modified in status START=0 (input). ML85C...
  • Page 87 C-63 Setup Ý Troubleshooting Troubleshooting In the event of faults we recommend that you check the basic functions using the menu options Current values, I/O status and Diagnosis. These menu options may be found in the Service group (key F1 in measuring mode). Current values I/O status Diagnosis...
  • Page 88 C-64 Setup Ý Troubleshooting Fault Cause and remedy Call up F4 Status ◊ Total ↵ Lots of NOK messages Analyze the cause of NOK messages. Check settings for the critical windows Measuring is stopped too soon Using F1(Service) > Diagnosis find cause of measurement ending Possible causes: Alarm limit passed...
  • Page 89 Measure Measure ML85C...
  • Page 90 Measure ML85C...

  • Page 91: Led Display On Front Panel

    Measure ➝ Front panel display LED display on front panel Amplifier plug-in units The amplifier plug-in units operate independently, i.e. They have no effect on one another. For instance, if an amplifier fails, this has no effect on how the other Remaining amplifiers operate. Amplifiers are parameterized via the display and control panel.

  • Page 92: Evaluation Channel Ml85C

    Measure ➝ Front panel display Evaluation channel ML85C Color Label Meaning ML85C of LED yellow CHAP. Select channel CHAP. ERROR Error ERROR WARN. red/yellow OK, NOK OK, Not OK yellow Start/Stop Start/Stop signal START STOP BUSY yellow BUSY Measuring running No.

  • Page 93: Ab22A/Ab32 In Measuring Mode

    Measure Ý Display and control panel AB22A/AB32 in measuring mode The measuring functions of the press-fit monitoring module are collected in function-specific groups in the lower part of the display. AB22A Channel 1−3 DISPL.-TIME Display in measuring mode Measure Check Diagram Statistics Status...

  • Page 94: Display

    Measure Ý Display and control panel Display The first display When the mains voltage is on, initialization of the AB22A/AB32 is indicated in the display by a horizontal progress bar. MGCplus start-up After the opening display the force-displacement diagram is displayed as standard (factory setup).

  • Page 95: Display In Measuring Mode

    Measure Ý Display and control panel Display in measuring mode The display during measuring mode depends on the function which has been selected (using the F-keys). Each time the device is switched off and on again, the force-displacement diagram is displayed as the standard factory setup.
  • Page 96 Measure Ý Display and control panel If you choose another function with the F-keys and then return to the menu with F4, the most recent display remains active until you choose another function and confirm with Display before Display after Channel1−3 Transducer test Channel 1−3...

  • Page 97: Possible Displays

    Measure ➝ Current values Possible displays 3.3.1 Current values The display shows the current measured values. The left-hand display Check Diagram Statistics Status field shows the measured force values. The right-hand display field shows the measured displacement values. The header also gives the amplifier identification.

  • Page 98: I/O Status

    D-10 Measure Ý I/Os 3.3.2 I/O status Displays current I/O status (0=low; 1=high). Check Diagram Statistics Status Abbreviation Function START Start/stop measurement Switch data set (2 I/O status Switch data set (2 Switch data set (2 PRINT Trigger print task I/O status Channel 1−3 CHECK...

  • Page 99: Diagnosis

    D-11 Measure Ý Diagnosis 3.3.3 Diagnosis You can use the “Diagnosis” function to establish why a measurement Check Diagram Statistics Status was ended and how many measured values were stored. The following processes end a measurement: 1. maximum measurement duration reached Diagnosis 2.

  • Page 100: Transducer Test

    Measure ➝ Transducer test D-12 3.3.4 Transducer test You can use the ”Transducer test” function to check the zero point Check Diagram Statistics Status setting (Displ. and Force). The result of the target/actual comparison is displayed as OK/NOK. Enter the permitted deviation in the ”Transducer test”...

  • Page 101: Force-Displacement Diagram

    D-13 Measure Ý Force-displacement diagram 3.3.5 Force-displacement diagram You can use the ”Force vs. Displ.” function to plot the Check Diagram Statistics Status force-displacement trend as a curve in the range window. 1. Press Force − displ. 2. Select ”Force − displ.” from the pull-up menu and confirm with 3.
  • Page 102 D-14 Measure Ý Force-displacement diagram Cursor Zoom You may use function key to switch on a cursor in the display, and factor Channel1−3 you can then use cursor keys to move it up, down and from side to FORCE-DISPL. Cursor 122N side.
  • Page 103 D-15 Measure Ý Force-time diagram 3.3.6 Force-time diagram Check Diagram Statistics Status 7. Use to select ”Save/Load” and confirm with You are now in the ”Save/Load Setup” setup menu. You can plot the force trend with the ”Force-time diagram” function. Force −...

  • Page 104: Displacement-Time Diagram

    D-16 Measure Ý Displacement-time diagram 3.3.7 Displacement-time diagram Use the ”Displ.-time Diagram” function to plot the displacement-time Check Diagram Statistics Status trend as a curve. 1. Press Displ. − time 2. Select ”Displ. − time” from the pull-up menu and confirm with 3.

  • Page 105: Statistics

    Measure ➝ Statistics D-17 Statistics The Statistics function gives you the ability to assess the quality of your press-fit processes. It produces min/max force histograms for each window and continuously calculates the mean value and standard deviation. You can make statistical records for a maximum of 65000 press-fit processes.

  • Page 106: Statistics: Total

    D-18 Measure Ý Statistics: Total Statistics: Total The function ”Statistics: Total” displays the total number of press-fit Check Diagram Statistics Status processes together with the number of OK and NOK processes. Total Statistics Channel1−3 Total number of cycles: OK cycles: NOK cycles: Check Diagram...

  • Page 107: Statistics: Windows

    D-19 Measure Ý Statistics: windows Statistics: windows Fitting window Check Diagram Statistics Status The statistical data for a fitting window starts being acquired when the force trend for the press-fit process has at least one point within the specified displacement limits. Histograms are produced for force minima and maxima.

  • Page 108: Statistics: End Position

    D-20 Measure Ý Statistics: end position Statistics: end position End position Check Diagram Statistics Status A statistical record of the end window is made for each measurement. A histogram of the end position is produced. The histogram is divided into nine displacement classes; five of these classes are within displacement limits, with a further two out-of-range classes on each End position side.

  • Page 109: Calculation Formulae

    D-21 Measure Ý Statistical formulae Calculation formulae Class number Class number + 2 ) 5 @ extreme = extreme value (to be included in the histogram) extreme = in range minimum = in range maximum Mean-value calculation Mean value + 1 n · + 1 n ·...
  • Page 110 D-22 Measure Ý Statistical formulae ML85C...
  • Page 111 Menu structure Ý Measuring mode Menu structure ML85C...
  • Page 112 Menu structure Ý Measuring mode ML85C...
  • Page 113 Menu structure Ý Measuring mode The menu structure that follows is intended to help you find the setup menus you are looking for more quickly. To begin with, the F-key assignment is displayed after you switch on the device and you are then informed of the se- quence of keys you can use to call the various menus.
  • Page 114 Menu structure Ý Measuring mode Symbols mV/V ↓ Selection field 0.000000... Edit field measure Button Check boxes Cursor keys Arrows show the direction in which the keys work ML85C...
  • Page 115 Menu structure Ý Measuring mode Measuring mode Selection bar Service Diagram Statistics Status Current values I/O status Channel 1−3 I/O status Force Displ. START 1 CHECK 1 NF 0 BUSY 1 /THR 0 CLEAR 1 0 NO1 5.342 mm 4.118 kN 0 CAL 1 NO2 0 F−0...
  • Page 116 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Diagnosis Transducer test Diagnosis Channel 1−3 Channel 1−3 Transducer test Target values 0.000 N 23.69 mm Meas. stopped: by software command Last measured value: Actual values 1.236 N 19.38 mm Number of buffered val.: Start/Stop Menu...
  • Page 117 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Force-Displ. Channel 1−3 FORCE-DISPL. Cursor Start/Stop Menu Channel 1−3 FORCE-DISPL. 2184 kN ABSOLUTE Cursor Zoom in Zoom out Menu Channel1−3 FORCE-DISPL. 2184 kN ABSOLUTE Cursor Zoom in Zoom out Menu The F4 key (menu) takes you back to the selection bar from any menu.
  • Page 118 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Force-Time Displ.-Time Channel1−3 Channel1−3 FORCE-TIME DISPL.-TIME Cursor Start/Stop Menu Cursor Start/Stop Menu Channel1−3 Channel1−3 FORCE-TIME DISPL.-TIME 2184 kN ABSOLUTE ABSOLUTE Cursor Zoom in Zoom out Menu Cursor Zoom in Zoom out Menu Channel1−3...
  • Page 119 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Total Window End position Statistics Channel1−3 OK: 4 NOK: 1 Fitting window Distribution of F-end OK: 4 NOK: 1 Average value 0.000kN Displ. limits: min. Total number of cycles: Std.
  • Page 120 E-10 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Total Target values Actual value Channel1−3 Target values Thread-in window Actual value Thread-in window Thr. in win. NOK Window 5 ... Window 2 NOK Window 6 ... 0.010 max.
  • Page 121 E-11 Menu structure Ý Measuring mode Service Diagram Statistics Status Selection bar Data acquisition Recording on hard disk Press-fit tasks File name MPV21 Status Acquisition disabled 54,554 MB OF 162,500 MB FREE Menu The F4 key (menu) takes you back to the selection bar from any menu. ML85C...
  • Page 122 E-12 Menu structure Ý Measuring mode ML85C...
  • Page 123 E-13 Menu structure Ý Setup mode Setup mode Selection bar Check Diagram Statistics Status System Display Amplifier Press fit Password PASSWORD new... delete... User: change... Password: Access: Authorization of the operator Password protection Off↓ SystemPassword Save/Load Add user Data acquisition Change password Interface User:...
  • Page 124 E-14 Menu structure Ý Setup mode Selection bar Check Diagram Statistics Status System Display Amplifier Press fit Save/Load SAVE/LOAD SETUP Save... Load... Factory setup Copy... Load parameter Channel 1 2 3 4 5 6 7 8 10111213141516 Param.set 1 1 1 Load setup from disk: Cancel COPY SETUP...
  • Page 125 E-15 Menu structure Ý Setup mode Selection bar Check Diagram Statistics Status System Display Amplifier Press fit Data acquisition Data acquisition Channel Channel selection File name Cancel Auto start ML85C...
  • Page 126 E-16 Menu structure Ý Setup mode Selection bar Check Diagram Statistics Status System Display Amplifier Press fit Interface Interface setup RS232... RS485... IEC ... Ethernet ... AB locked during computer control RS485-setup IEEE488-setup Address 1... Control slave: Address: 4 ... ↓...
  • Page 127 E-17 Menu structure Ý Setup mode Check Diagram Statistics Status System Display Amplifier Press fit Language Time Print PRINT DATE/TIME SETUP LANGUAGE RS232 ↓ Print setup through : Language: English ↓ Day ... Month Year ... Date: Amplifier ↓ Friday Day: Setup of the signals to be printed Select...
  • Page 128 E-18 Menu structure Ý Setup mode Check Diagram Statistics Status System Display Amplifier Press fit Display format F-keys Channel names 0...9 DISPLAY FORMAT one value F-KEYS SETUP Level 1 0 ... Number: CHANNEL NAME Channel 1 Level 1 ... one value ↓ Type: free F1: Zeroing ↓...
  • Page 129 E-19 Menu structure Ý Setup mode Check Diagram Statistics Status System Display Amplifier Press fit Force transducer Displ. transducer Signal conditioning: Force TRANSDUCER Channel1 CONDITIONING Channel1 TRANSDUCER Channel2 0.0000 ... Type SG full bridge Type IND half bridge Zero reference: Excitation: 5V↓...
  • Page 130 E-20 Menu structure Ý Setup mode Check Diagram Statistics Status System Display Amplifier Press fit Signal conditioning: Display: Force Display: Displacement Displacement DISPLAY Channel 2 CONDITIONING Channel2 DISPLAY Channel 1 mm ↓ N ↓ 0.0000 ... Unit Zero reference: Unit Decimal places −>0<−...
  • Page 131 E-21 Menu structure Ý Setup mode Check Selection bar Diagram Statistics Status System Display Amplifier Press fit Coordinates Range window Alarm window Coordinates Channel 3 Range window Channel 3 relative to end pos. # Relative window min. 60... max. 300... End position 0.00...
  • Page 132 E-22 Menu structure Ý Setup mode Selection bar Check Diagram Statistics Status System Display Amplifier Press fit Thread-in window Fitting window Fitting window Channel 3 Fitting window disabled Function absolute Reference Displ. absolute Reference Force rectangle Type of window Thread-in window Channel 3 min.
  • Page 133 Status Check System Display Amplifier Press fit End window + method Transducer test Version VERSION Channel1−3 Identification: HBM,RD002−ML85/3,0,P4.12 Comments: Serial and revision number... System Display Amplifier Press fit End window + method Channel 3 10.000 Total time Transducer test Channel 1−3 Target pos.
  • Page 134 E-24 Menu structure Ý Setup mode ML85C...
  • Page 135 Specifications Specifications ML85C...
  • Page 136 Specifications ML85C...
  • Page 137 Specifications Amplifier modules ML85C Max. number of force values Max. number of displacement values Max. measurement duration Sampling rate 2400 Evaluation max. number of evaluation windows Type of window trapezium or rectangle 4 evaluation methods per window (from Version P4.00) Evaluation of the curve Evaluation of the minimum force in the window Evaluation of the maximum force in the window...
  • Page 138 Specifications Statistics Number of statistics buffers 64 (1 for each parameter set) Maximum number of cycles 65000 Number of histogram classes for force maximum 9 per fitting window Number of histogram classes for force minimum 9 per fitting window Number of histogram classes for end position Mean value calculation of F and F over all fitting...
  • Page 139 Specifications AP75 connection board ML85C + connection board AP75 Digital inputs Max. number of digital inputs 8 (16) Input voltage range 0 ... 24 Electrical isolation Typically 500 Low potential < 5 High potential >10 Grounding systems 1, separated from the digital output Control functions for groups of MGCplus channels Autocalibration ON/OFF;...
  • Page 140 Specifications ML85C...
  • Page 141 Keywords Keywords current values, D-9 displacement-time diagram, D-16 display in measuring mode, D-7 AB22/AB32, measuring mode, D-5 first display, D-6 alarm limits, C-19 force-displacement diagram, D-13 force-time diagram, D-15 alarm window, C-27 I/O status, D-10 amplifier, set up, C-16 relative, C-20–C-23 transducer check, D-12 block force, C-35 edit field, E-4...
  • Page 142 Stichwortverzeichnis I/O, status display, D-10 range window, C-19 , C-28 inputs, B-4 remotes, B-3 AP75 assignment, B-3 inputs and outputs, B-3 Safety instructions, A-3 maintenance and cleaning, A-5 selection field, E-4 measurement parameter, setting up, C-20–C-24 setting up the coordinate system, C-26 Measuring amplifier, setup, force and displacement, C-17 settling time, C-35...
  • Page 143 Keywords target pos.+settling time, C-38 window relative to end position, C-23 thread-in window, C-19 , C-29 relative to start position, C-20 setting up, C-31 tolerance window procedure, C-19 total time, C-35 transducer check, C-40 zero balance, D-9 Troubleshooting, C-63 zoom, D-14 ML85C...
  • Page 144 Stichwortverzeichnis ML85C...
  • Page 145 Certificate of conformity Certificate of conformity ML85C...
  • Page 146 Certificate of conformity ML85C...
  • Page 147 Certificate of conformity ML85C...
  • Page 148 Certificate of conformity ML85C...
  • Page 150 They are not to be understood as express warranty and do not constitute any liability whatsoever. Im Tiefen See 45, D-64293 Darmstadt, Germany Tel.: +49 6151 8030; Fax: +49 6151 803 9100 E−mail: support@hbm.com www.hbm.com B0541-5.3 en...

Table of Contents
