Soundoff Signal ETSSVBK02 Installation Instructions page 2

100N / 100J / 100U SERIES SPEAKER BRACKET (only - no drill)
for the Chevrolet Silverado 1500 2019.5 - 2022, Bumper Mount
FIG. 1
Passenger Side
bolts to be
removed
1.800.338.7337 / www.soundoffsignal.com
2
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
FIG. 2
Driver Side
bolts to be
removed
NOTICE:
Improper use or installation may void warranty coverage.
E N H A N C I N G S A F E T Y T H R O U G H I N N O VAT I O N
INSTALLATION:
1. With the hood open, remove the vented, upper plastic
piece on the front of the vehicle (Fig. 1) in order to access
the space in front of the radiator for speaker bracket
installation. For additional room, it is recommended
that the grill also be removed. Consult a local Chevrolet
service center for best disassembly method. Keep all
hardware.
2. Selecting the desired side, remove the two bolts from the
radiator support from the appropriate side, as shown in
Fig. 2.
ETSSVBK02_ETSSVBK03 1021
