Soundoff Signal PINNACLE EPL71M+ Series Quick Installation Manual

EPL7100 MINI LIGHTBAR MAGNET MOUNT
EPL71M+(xx)
WARNING
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner's Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
1.800.338.7337 / www.soundoffsignal.com
1
Please see next page for Technical Specifications
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
S U P E R I O R C U S TO M E R R E L AT I O N S H I P S . S M A RT LY D E S I G N E D L I G H T I N G & E L E C T R O N I C S O L U T I O N S .
NOTICE:
Improper use or installation may void warranty coverage.

INSTALLATION:

1) Detemine a clean, flat location (typically the roof) on
the vehicle to mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes equipped
with four magnetic feet. It is the responsibility
of the installer and end user to determine
whether it is safe to use magnetic mounting
hardware for your application. A Permanent
Mount version (EPL7PD(x)C)
Note: The magnetic character of roof steel varies
from vehicle to vehicle. Be sure that your vehicle
is capable of providing enough magnetic force to
safely secure the PINNACLE Mini Lightbar to the
roof.
2) A Protective Film has been
with the PINNACLE Mini Lightbar kit that
can be applied to the bottom of each
magnet. This film will protect the paint
of the vehicle. Apply one donut shaped
decal to the bottom of each magnetic foot.
Be sure to cover the magnet entirely for
maximum protection to the paint finish.
Note: Protective film can
magnetic force by as much as 10%.
Caution: Do not install this product or route any
wires in the air bag deployment zone. Refer to
your vehicle Owner's Manual for the location of
any air bag deployment zones.
WARNING
!
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into the
light beam at close range.
is available.
provided
reduce the
EPL71M+(xx) 0221
