Component Identification
Figure 158.
A
A Oil Filter
B Element
Figure 159.
A
B
C
D
A Cartridge holder cover
B Oil filter support
C Oil returning into the circuit
D Oil returning to the crankcase
15 - 89
H
B
E
F
A Cartridge holder cover
B Oil filter support
E Oil filter cartridge
F Outgoing fitting from filter
G Water/oil heat exchanger
H Crankcase
9813/2700-2
15 - Engine
21 - Oil Filter
00 - General
Figure 160.
G
A
B
15 - 89
