03 - Drive Belt

Introduction ....................................................
Health and Safety ..........................................
Component Identification
Check (Condition) ..........................................
Adjust ............................................................
Remove and Install .......................................
15 - 79
15-79
15-80
............................... 15-80
15-81
15-81
15-83
9813/2700-2
Introduction
Original Belt Configuration
The alternator adjusting lever makes sure that the
front end accessory drive belt (FEAD) is kept at the
correct tension.
Figure 143.
B
A Alternator
B Adjusting lever
Alternate Belt Configuration
A tensioning screw, which adjusts the tightening
pulley travel, makes sure that the front end accessory
drive belt (FEAD) is kept at the correct tension.
Figure 144.
A
A Tightening pulley
B Tensioning screw
15 - Engine
18 - Engine Belt
03 - Drive Belt
A
B
15 - 79
